DIRECTOR EC OFFICE PUBLISHER WITH OptiEC PRO PRINTER
DIRECTOR EC OFFICE PUBLISHER -- PC MINIMUM REQUIREMENTS
•
A Pentium® 4 or compatible personal computer @ 2 GHz or faster.
•
Windows 2000 Professional (service pack 4.0 or higher) or Windows XP (service pack 1.0a or higher)
•
1GB RAM
•
One (1) Hard Disk Controller Adaptec BRAND Ultra 29160
•
One (1) 18 GB SCSI 15,000rpm Ultra 160 SCSI Hard Drive (formatted NTSF) as follows:
•
One (1) Basic Partition for System (C:)
•
Two (2) 9GB NTFS Partitions (D:)(E:) – Temp folder in root on each partition
•
One (1) Free PCI slot
•
One (1) internal USB port for the Software Identifier Card (DKI-011-0107)
•
One (1) external USB port for OptiEC PRO printer
•
One (1) PCI Firewire B Card, IEEE-1394B, (supplied by MF DIGITAL)
•
One (1) DKI011-0107 (supplied by MF DIGITAL) PC needs a free 3.5" floppy drive power cable for DKI card.
•
One (1) External COM port (COM1 or COM2)
•
Network 10/100Mbs on Board
•
Video 1024 x 768
THE DIRECTOR EC SOFTWARE MUST BE INSTALLED in "C:\" DIRECTORY
Director EC Office Publisher
with OptiEC PRO Printer

Installation Guide

INSTALLATION GUIDE
MF DIGITAL
121 Carolyn Blvd.
Farmingdale, NY 11735
001 631 249 9393
www.mfdigital.com
Document Revision: 12/28/2004
