Director EC Office Publisher with OptiEC
Printer Installation Guide
DIRECTOR EC OFFICE PUBLISHER WITH OptiEC PRINTER
DIRECTOR EC OFFICE PUBLISHER -- PC MINIMUM REQUIREMENTS
•
A Pentium® III or compatible personal computer @ 933 MHz or faster with Three (3) Free PCI slots.
•
Windows 2000 Professional (service pack 4.0 or higher) or Windows XP (service pack 1.0a or higher)
•
1GB RAM (PC 133 specification - SDRAM or DDRAM)
•
1 Hard Disk Controller Adaptec BRAND Ultra 29160
•
1 18 GB SCSI 15,000rpm Ultra 160 SCSI Hard Drive (formatted NTSF) as follows:
•
1 Basic Partition for System (C:) & 2 5GB NTFS Partitions (D:)(E:) – Temp folder in root on each partition
•
1 Firewire 1394 Card (Supplied by MF DIGITAL)
•
1 Software Identifier Card (Supplied by MF DIGITAL) Computer needs 3.5" power connector for this card
•
1 external COM port (COM1 or COM2) - 2 ports needed if using Prism Plus or Spectrum2
•
Network 100/10Mbs on Board
•
Video 1024 x 768
•
One Parallel Port
THE DIRECTOR EC LOADER MUST BE INSTALLED ON COM PORT 2
THE DIRECTOR EC SOFTWARE MUST BE INSTALLED ON C:\ DRIVE

INSTALLATION GUIDE

MF DIGITAL
121 Carolyn Blvd.
Farmingdale, NY 11735
001 631 249 9393
www.mfdigital.com
Document Revision: 2/21
