- Page 1 YTA Series User’s Temperature Transmitters Manual (Hardware) Manual Change No. 08-013 Please use the attached sheets for the pages listed below in the following manuals. IM 01C50B01-01E (12th) Page and Item Contents of Correction Page 2-6, 7-6 Change Marking Code for CENELEC ATEX Type of ATEX Documentation Protection “n”.
- Page 2 Caution for CENELEC ATEX (KEMA) Intrinsically • All wiring shall comply with local installation safe type requirements. (Refer to the installation diagram) Note 1. Model YTA110/KU2, YTA310/KU2 and Note 4. Maintenance and Repair YTA320/KU2 temperature transmitters for • The instrument modification or parts replacement by...
- Page 3 Dust Ignition Proof Type Caution for CENELEC ATEX (KEMA) Flameproof Caution for CENELEC ATEX Type of Protection “n” Type and Dust Ignition Proof Type Note 1. Model YTA110/KU2, YTA310/KU2 and Note 1. Model YTA110/KU2, YTA310/KU2 and YTA320/KU2 temperature transmitters for YTA320/KU2 temperature transmitters...
-
Page 4: Model And Suffix Codes
7. GENERAL SPECIFICATIONS Factory setting ( ) Tag No. Left blank if not specified in order Input sensor type “Pt100, 3-wire” if not specified in order Lower bound of calibration range “0” if not specified in order Upper bound of calibration range “100”... - Page 5 7. GENERAL SPECIFICATIONS [For Explosion Protected Types] For FOUNDATION Fieldbus explosion protected type, see IM 01C50T02-01E. Descriptions Code Item CENELEC ATEX (KEMA) Intrinsically safe, Flameproof approval and Type n combination [Intrinsically safe approval] Applicable standard: EN 50014, EN 50020, EN 50284 Certificate: KEMA 02ATEX1026X II 1G EEx ia IIC T4,T5 Ambient Temerature: -40 to 70°C for T4, -40 to 50°C for T5 Supply/Output circuit: Ui=30V, Ii=165mA, Pi=900mW, Ci=20nF, Li=660 H...
