Fiery EX2101 for Xerox 2101
USER SOFTWARE INSTALLATION GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Fiery EX2101 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Fiery Fiery EX2101

Summary of Contents for Fiery Fiery EX2101

  • Page 1 Fiery EX2101 for Xerox 2101 USER SOFTWARE INSTALLATION GUIDE...
  • Page 2 User Software Installation Guide describes how to install software from the User Software CD to enable users to print to the Fiery EX2101 for Xerox 2101, and also describes setting up printing connections to the Fiery EX2101 for Xerox 2101.
  • Page 3 Copyright © 2003 Electronics for Imaging, Inc. All rights reserved. This publication is protected by copyright, and all rights are reserved. No part of it may be reproduced or transmitted in any form or by any means for any purpose without express prior written consent from Electronics for Imaging, Inc.
  • Page 4 FCC Information WARNING: FCC Regulations state that any unauthorized changes or modifications to this equipment not expressly approved by the manufacturer could void the user’s authority to operate this equipment. Class B Declaration of Conformity This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 5 License EFI grants you a non-exclusive license to use the Software and accompanying documentation (“Documentation”) included with the Product. The Software is licensed, not sold. You may use the Software solely for your own customary business or personal purposes. You may not rent, lease, sublicense or lend the Software or use the Software in any time sharing, service bureau, or similar arrangement.
  • Page 6 Limitation of Liability TO THE MAXIMUM EXTENT PERMITTED BY LAW, EFI AND ITS SUPPLIERS SHALL NOT BE LIABLE FOR ANY DAMAGES, INCLUDING LOSS OF DATA, LOST PROFITS, COST OF COVER OR OTHER SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES ARISING FROM THE SALE, INSTALLATION, MAINTENANCE, USE, PERFORMANCE OR FAILURE OF THE SOFTWARE, HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY.

  • Page 7: Table Of Contents

    Completing the Windows 2000/XP/Server 2003 printer connection 1-33 Installing Fiery EX2101 software 1-42 Adobe Acrobat 1-43 Using Fiery EX2101 software for the first time 1-44 Configuring the connection for Fiery utilities 1-45 Configuring the connection for Fiery Downloader, Fiery Spooler, and Command WorkStation 1-45 Configuring the connection for Fiery VDP Resource Manager...
  • Page 8 Reinstalling the Adobe PostScript Printer Driver on Windows 98/Me Problems with the Fiery utilities on Windows computers On Mac OS computers Setting up the Fiery EX2101 in the Mac OS 9 Chooser Setting up the Fiery EX2101 in the Mac OS X Print Center Index...

  • Page 9: About This Manual

    WorkStation (Windows only) or Command WorkStation LE (Mac OS X only), which enables an operator to manage all jobs sent to the Fiery EX2101. Although it may not be the case at all sites, the documentation for this product assumes the presence of an operator who controls and manages jobs sent by users from remote workstations.

  • Page 10: Specifications

    x Introduction Specifications • 1 GHz Intel Pentium III CPU • 256MB RAM • 60GB hard disk drive • An internal CD-ROM drive • A 250MB ZIP drive for removable media • Supports AppleTalk, TCP/IP, and IPX/SPX protocols simultaneously • Supports Port 9100 •...

  • Page 11: User Software

    User software User software Fiery EX2101 user software is provided on the User Software CD. Adobe PostScript Enables you to print to the Fiery EX2101 from Printer Driver Windows 98/Me, Windows NT 4.0, and Mac OS computers; also supports Fiery EX2101 and PostScript 3 features.
  • Page 12 MRJ installer is automatically launched. You can install PostScript and PCL printer drivers and printer description files from the User Software CD or from the Fiery EX2101 with the Installer WebTool. For instructions, see “Using the Installer WebTool”...

  • Page 13: Fiery Webtools

    Fiery WebTools Fiery WebTools Fiery WebTools allow you to manage the Fiery EX2101 remotely from the Internet or from your company’s intranet. You access Fiery WebTools from the Fiery WebTools home page. To find out which Fiery WebTools are supported, see “Specifications”...

  • Page 15: Chapter 1: Installing User Software On A Windows Computer

    Setting up PostScript or PCL printing with Windows 98/Me To set up the Fiery EX2101 as a PostScript or PCL printer, you must install the PostScript or PCL printer driver for Windows 98/Me and the corresponding printer description files. You must also configure either a local connection for printing directly or a network connection for printing over the network.

  • Page 16: Installing The Postscript Or Pcl Printer Driver For Windows 98/Me

    1-2 Installing User Software on a Windows Computer Installing the PostScript or PCL printer driver for Windows 98/Me The following procedure describes installing the printer driver from the User Software CD. Subsequent procedures describe configuring installable options and setting up the printer connection. The following procedures use Windows 98 illustrations.

  • Page 17: Configuring Installed Options

    10. Enter a name for the Fiery EX2101 in the Printer Name box. 11. Specify whether you want to make the Fiery EX2101 the default printer and click Next. 12. Select No to printing the Test Page and click Finish.
  • Page 18 O CONFIGURE OPTIONS MANUALLY FOR INDOWS 1. Click Start, choose Settings, and then choose Printers. 2. In the Printers window, right-click the Fiery EX2101 printer driver icon and choose Properties. 3. Click the Installable Options tab. 4. Select an installed option from the Available Options list.
  • Page 19 When the printer driver is first installed, the options have default settings that were set up in Fiery EX2101 Setup. When you update the printer driver with the Two-Way Communication feature, you allow the Fiery EX2101 to complete the actual setting.

  • Page 20: Completing The Windows 98/Me Printer Connection

    To print from Windows 98/Me, you must: • Set up network servers, if any. • Set up the Fiery EX2101 to accept print jobs from your computer. • Configure a port on each Windows 98/Me computer for the network type.
  • Page 21 1-7 Setting up PostScript or PCL printing with Windows 98/Me IPX/SPX O SELECT A FRAME TYPE FOR PRINTING 98/M INDOWS 1. Click Start, choose Settings, and then choose Control Panel. 2. Double-click the Network icon. Make sure that IPX/SPX-compatible Protocol is listed in the Installed Network Components section.
  • Page 22 PRINTING WITH INDOWS 1. Click Start, choose Settings, and then choose Printers. 2. In the Printers window, right-click the Fiery EX2101 printer icon and choose Properties. 3. Click the Details tab and click Add Port. A list of connection options is displayed.
  • Page 23 7. In the Add Port dialog box, verify that the network path is updated and click OK. Your print jobs are transmitted to the specified print queue on the Novell file server. The Fiery EX2101 polls the file server, and if jobs are present, they are transmitted to the Fiery EX2101.
  • Page 24 Click Start, choose Find, and then choose Computer. Enter the name of the printer, and click Find Now. If you cannot locate your Fiery EX2101, contact your network administrator. 3. Double-click the name of the printer to display enabled print connections.
  • Page 25 10. Verify the path is correct and click OK. Setting up IPP printing with Windows 98/Me With Internet Printing Protocol (IPP), print jobs are sent to the Fiery EX2101 over the Internet. IPP printing is supported on Windows 2000/XP/Server 2003 but can be enabled on Windows 98/Me computers by installing the “wpnpins.exe”...
  • Page 26 PRINTING WITH INDOWS 1. Click Start, choose Settings, and then choose Printers. 2. In the Printers window, right-click the icon for the Fiery EX2101 PostScript printer driver and choose Properties. 3. Click the Details tab and click Add Port. The Add Port dialog box appears.

  • Page 27: Setting Up Postscript Or Pcl Printing With Windows Nt

    Setting up PostScript or PCL printing with Windows NT 4.0 To set up the Fiery EX2101 as a PostScript or PCL printer, you must install the PostScript or PCL printer driver for Windows NT 4.0 and the corresponding printer description files. You must also configure the print connection between the computer and the Fiery EX2101.
  • Page 28 1-14 Installing User Software on a Windows Computer 5. Select LPT1: and click Next. This is a general installation that works for the parallel port connection. You can add a network port later, according to your network type. 6. In the dialog box displaying lists of manufacturers and printers, click Have Disk. The Install From Disk dialog box prompts you for the disk.

  • Page 29: Configuring Installed Options

    10. In the Printers box, select the Fiery EX2101 printer driver appropriate for your printer and click Next. 11. Type a name for the Fiery EX2101 in the Printer name field and specify whether you want to make it the default printer. Click Next.
  • Page 30 CRIPT PRINTER DRIVER FOR INDOWS 1. Click Start, choose Settings, and then choose Printers. 2. In the Printers window, right-click the Fiery EX2101 icon and choose Properties. 3. Click the Installable Options tab. 4. Select an installed option from the Available Options list.
  • Page 31 1-17 Setting up PostScript or PCL printing with Windows NT 4.0 For Windows NT 4.0, you cannot specify Installable Options in the Advanced tab of the Fiery EX2101 Document Properties dialog box when printing from an application. To correctly specify Installable Options, install the printer driver from the User Software CD.
  • Page 32 When the printer driver is first installed, the options have the default settings that were set up in Fiery EX2101 Setup. When you update the printer driver with the Two-Way Communication feature, you allow the Fiery EX2101 to complete the actual setting.

  • Page 33: Completing The Windows Nt 4.0 Printer Connection

    After you have installed the PostScript or PCL printer driver and printer driver files, complete the setup for the TCP/IP and LPR connection as follows: • Prepare the Fiery EX2101 to accept print jobs using TCP/IP and LPR protocols. For details, see the Configuration...
  • Page 34 Before you continue, contact the system administrator for the IP address assigned to the Fiery EX2101, as well as the subnet mask and the gateway address, if they are used. The TCP/IP protocol should already be installed on the Windows NT computer.
  • Page 35 1-21 Setting up PostScript or PCL printing with Windows NT 4.0 5. Press Tab and type the name of the Fiery EX2101 connection you want to print to. print hold direct This name is case-sensitive; type it exactly as shown.
  • Page 36 To see the print connections, you may have to log in to the file server. 4. Double-click the print connection defined for the Fiery EX2101. 5. If the NetWare server does not have a suitable driver for the Fiery EX2101, you may be prompted to set up the printer on your computer. Click Yes.
  • Page 37 The Test Page remains listed in the queue window until it is printed. The Fiery EX2101 polls the NetWare server for print jobs in the print connection defined for the Fiery EX2101. When you print, your PostScript files are spooled to...
  • Page 38 SMB printing (also known as Windows printing) allows you to install the PostScript or PCL printer driver and printer description files, and print from your computer to a particular print connection (Hold, Print, or Direct) on the Fiery EX2101. These instructions assume you have installed the TCP/IP protocol and Client for Microsoft Networks.
  • Page 39 Find Now. If you cannot locate your Fiery EX2101, contact your network administrator. 3. Double-click the name of the Fiery EX2101 to display enabled print connections. You may be promoted to enter a network password. If so, enter an arbitrary alphabet letter for Connect As and click OK.

  • Page 40: Setting Up Postscript Or Pcl Printing With Windows 2000/Xp/Server 2003

    Setting up PostScript or PCL printing with Windows 2000/XP/Server 2003 To set up the Fiery EX2101 as a PostScript or PCL printer, you must install the PostScript or PCL printer driver for Windows 2000/XP/Server 2003 and the corresponding printer description files. You must also configure the print connection between the computer and the Fiery EX2101.
  • Page 41 1-27 Setting up PostScript or PCL printing with Windows 2000/XP/Server 2003 4. Select LPT1: and click Next. 5. In the dialog box displaying lists of manufacturers and printers, click Have Disk. The Install From Disk dialog box prompts you for the disk. 6.
  • Page 42 8. In the Printers box, select the Fiery EX2101 printer driver for your printer and click Next. 9. Type a name for the Fiery EX2101 in the Printer name field and click Next. This name will be used in the Printers and queue windows.

  • Page 43: Configuring Installed Options

    After you have completed the printer driver installation, you must configure the Fiery EX2101 for the options installed on the copier. This allows the Fiery EX2101 to take advantage of the copier options. You can configure the options manually, or for TCP/IP network connections, you can use the Two-Way Communication feature to configure the options automatically.
  • Page 44 1-30 Installing User Software on a Windows Computer 5. Click Add to move the option to the Installed Options list. —Not Installed, Tray 6 (HCF) Tray 6 (HCF) —Not Installed, 2/4 Hole Punch Unit, 3 Hole Punch Unit Punch Options —Not Installed, Installed Booklet Tray Option —Not Installed, Installed...
  • Page 45 PRINTER DRIVER 1. Click the Start button, choose Settings, and then choose Printers. 2. Right-click the Fiery EX2101 icon and choose Print Settings from the File menu. 3. Click the Installable Options tab and specify the options installed on the Fiery EX2101.
  • Page 46 When the printer driver is first installed, the options have the default settings that were set up in Fiery EX2101 Setup. When you update the printer driver with the Two-Way Communication feature, you allow the Fiery EX2101 to complete the actual setting.

  • Page 47: Completing The Windows 2000/Xp/Server 2003 Printer Connection

    To print from Windows 2000/XP/Server 2003, you must: • Set up network servers, if any. • Set up the Fiery EX2101 to accept print jobs from your computer. • Configure a port on each Windows 2000/XP/Server 2003 computer for the network type.
  • Page 48 • Configure the computer for the TCP/IP connection. Before you continue, contact the system administrator for the IP address assigned to the Fiery EX2101, as well as the subnet mask and the gateway address, if they are used. The TCP/IP protocol should already be installed on the Windows 2000/XP/Server 2003 workstation.
  • Page 49 1-35 Setting up PostScript or PCL printing with Windows 2000/XP/Server 2003 5. Enter the IP address of the Fiery EX2101. 6. Click Next. The device is detected automatically. 7. Click Finish to close the Add Standard TCP/IP Printer Port Wizard dialog box, and then click Close in the Printer Ports dialog box.
  • Page 50 11. Enter the name of the print connection. For LPR, use print hold , or direct For Port 9100, manually enter the following port numbers for each print connection under Raw Settings: Fiery EX2101 default: 9100 direct: 9101 print: 9102 hold: 9103...
  • Page 51 Completing the Windows 2000/XP/Server 2003 IPX (Novell) connection Complete the setup for the IPX (Novell) connection as follows: • Configure the Novell network and file server for handling Fiery EX2101 print jobs. The file server should be configured with a print server and print connection for the Fiery EX2101.
  • Page 52 1-38 Installing User Software on a Windows Computer 5. If the NetWare server does not have a suitable driver for the Fiery EX2101, you may be prompted to set up the printer on your computer. Click Yes. 6. Click OK to install the Fiery EX2101 PostScript printer driver.
  • Page 53 SMB printing (also known as Windows printing) allows you to install the printer driver and associated files, and print from your computer to a particular print connection (Hold, Print, or Direct) on the Fiery EX2101. These instructions assume you have installed the TCP/IP protocol and Client for Microsoft Networks.
  • Page 54 5. Click Local Printer and click Next. 6. Click Create a New Port, and choose Local Port from the menu. Click Next. 7. In the Port Name dialog box, enter the name of the Fiery EX2101, followed by the printing connection, and then click OK.
  • Page 55 1-41 Setting up PostScript or PCL printing with Windows 2000/XP/Server 2003 Setting up IPP printing with Windows 2000/XP/Server 2003 With Internet Printing Protocol (IPP), print jobs are sent to the Fiery EX2101 over the Internet. IPP printing is supported directly for Windows 2000/XP/Server 2003 computers.

  • Page 56: Installing Fiery Ex2101 Software

    If you have already installed the printer driver on your computer, select the appropriate names from the lists of manufacturers and printers. 8. Click OK. 9. Specify whether you want to make the Fiery EX2101 the default printer and click Next. 10. Click Finish. Installing Fiery EX2101 software...

  • Page 57: Adobe Acrobat

    1-43 Installing Fiery EX2101 software The utilities are supported on Windows computers and must be separately installed on each user’s computer. The installation of each utility is similar. Before you begin each installation, determine where you want to install each item on your hard disk.

  • Page 58: Using Fiery Ex2101 Software For The First Time

    1. Click Start, choose Programs, and then choose Fiery. 2. Click FieryPrinterDeleteUtility. The Fiery Driver Uninstall Tool dialog box appears. If any Fiery EX2101 printer drivers are found on your computer, they are displayed. 3. To delete any of the displayed printers, select the printer name and click Delete.

  • Page 59: Configuring The Connection For Fiery Utilities

    The first time you start one of the Fiery utilities, you must configure the connection to the Fiery EX2101. Similar configuration is used for all Fiery utilities, so a change in one configuration affects all the other connections. Configuration for Fiery utilities is described in the procedures that follow.
  • Page 60 The Available Servers dialog box appears. All servers found in the local subnet are displayed. 3. If no Fiery EX2101 servers were found, click the Manual tab to search by DNS name or IP address. Click Add to add the server to the Available Servers list.
  • Page 61 IP addresses or the IP address and subnet mask. 5. Click Search. All available servers are displayed in the Available Servers list. 6. Select the Fiery EX2101 server you want to use and click Add. The selected Fiery EX2101 server is displayed in the Login Server dialog box.
  • Page 62 8. Select Administrator, Operator, or Guest and click Log In. Your computer is connected to the server. To modify the Command WorkStation connection to the Fiery EX2101, you must remove the server from the Login Server list and follow the preceding procedure for configuring the connection.
  • Page 63 1-49 Using Fiery EX2101 software for the first time 3. Enter the appropriate information for the Fiery EX2101. —Enter a name for the Fiery EX2101. This name does not have to match Nickname the actual Server Name of the Fiery EX2101.
  • Page 64 5. With the device name (EX2101) selected in the Devices list, click OK. The Fiery EX2101 is displayed in the list of available servers. The first line of the entry displays the nickname you gave the server, followed by the protocol you chose.

  • Page 65: Configuring The Connection For Fiery Vdp Resource Manager

    1. Click Start, choose Programs, and then click Fiery VDP Resource Manager in the Fiery folder. The Available Servers dialog box appears with all Fiery EX2101 servers in the local subnet displayed. 2. To locate a server by its IP address, click the Manual tab. Enter the IP address and click Add.
  • Page 66 1-52 Installing User Software on a Windows Computer 3. To locate the Fiery EX2101 either by a range of IP addresses or by the IP address and subnet mask, click the Auto Search tab and then click Advanced. 4. Click the IP Range tab or the Subnet tab.

  • Page 67: Configuring A Connection For Job Monitor

    On Windows XP, click Start and choose Printer and Faxes. On Windows Server 2003, click Start, choose Control Panel, and then choose Printer and Faxes. 2. In the Printers window, select the icon for the Fiery EX2101 PostScript printer driver. 3. Choose Properties from the File menu.
  • Page 68 Job Monitor opens a utility window on the screen and establishes a connection to the Fiery EX2101. If you have installed and configured printer drivers for more than one copier, Job Monitor automatically establishes connections to all the Fiery EX2101 engines.

  • Page 69: Installing The Printer Description Files For Windows

    PageMaker 5.0, 6.x, and 7.0 do not support automatic installation of printer description files from the Printers or Printers and Faxes Control Panel. To make the Fiery EX2101 available in the Print and Page Setup dialog boxes of this application, copy printer description files to the appropriate location.

  • Page 71: Chapter 2: Installing User Software On A Mac Os Computer

    • Install the PostScript printer driver and printer description file. Computer • Set up the Fiery EX2101 in the Chooser (Mac OS 9) and the Print Center (Mac OS X). • Install the Fiery utilities (Fiery Downloader, Fiery VDP Resource Manager, and Fiery Spooler).

  • Page 72: Setting Up Mac Os 9 Printer Drivers And Printer Description Files

    Setting up the Fiery EX2101 in the Chooser After you install the Adobe PostScript printer driver and printer description file, you must set up the Fiery EX2101 in the Chooser in order to take full advantage of its features. For details, see “Setting up the Fiery EX2101 as a PostScript printer”...
  • Page 73 2. Select the correct AppleTalk Zone, if necessary. 3. Click the AdobePS icon. The Fiery EX2101 is displayed in the Select a PostScript Printer list in the form of <server name>_<print connection>. Only the print connections (Direct, Hold, and Print) that have been enabled in Setup are displayed in the Chooser.

  • Page 74: Setting Up Mac Os X Printer Drivers And Printer Description Files

    2-4 Installing User Software on a Mac OS Computer 5. Select the icon that appears next to the newly installed Fiery EX2101 and click Setup. 6. Click Configure in the dialog box that appears. 7. In the Installable Options dialog box, choose the appropriate settings from the menus and click OK.
  • Page 75 Setting up the Fiery EX2101 in the Print Center After you install the printer description files, you must set up the Fiery EX2101 in the Print Center in order to take full advantage of its features. This section describes how to set up the Fiery EX2101 and configure installable options.
  • Page 76 3. Choose AppleTalk or IP printing from the menu. 4. For AppleTalk, choose the AppleTalk Zone, and then choose the name of the Fiery EX2101. If the zone is not listed as the Default Zone or one of the Recent Zones, select...
  • Page 77 2-7 Setting up the Fiery EX2101 as a PostScript printer For IP Printing, enter the IP address or DNS name of the printer for Printer’s Address, clear Use default queue on server, and then enter the print connection for Queue Name.
  • Page 78 3. Choose AppleTalk or IP printing from the menu. 4. For AppleTalk, choose the AppleTalk Zone, and then choose the name of the Fiery EX2101. If the zone is not listed as the Default Zone or one of the Recent Zones, select AppleTalk Network, and select the zone, and then click Choose.
  • Page 79 2-9 Setting up the Fiery EX2101 as a PostScript printer 5. For Printer Model, select Other. 6. In the Choose a File dialog box, select the appropriate language file from the left column (see the following table), and the Fiery EX2101 name from the right column. Language File name Dutch nl.lpro...
  • Page 80 2-10 Installing User Software on a Mac OS Computer O CONFIGURE INSTALLABLE OPTIONS 1. Double-click Print Center in ‘Utilities’ under Startup disk:Application. The Print Center starts. 2. Select your printer in the Printer List. 3. Choose Show Info from the Printer menu. 4.

  • Page 81: Installing Fiery Ex2101 Software And Fonts

    2-11 Installing Fiery EX2101 software and fonts Installing Fiery EX2101 software and fonts The Mac OS installers function essentially the same for each type of software. Before you begin each installation, determine where you want to install each item on your hard disk.

  • Page 82: Installing Mrj On Your Computer

    3. Click Install. 4. Click Quit. You are now ready to configure the connection to the Fiery EX2101. We recommend that you install the MRJ provided on the User Software CD and use it with the Fiery EX2101 software.

  • Page 83: Configuring A Connection For Fiery Spooler

    2-13 Installing Fiery EX2101 software and fonts OS R O UNINSTALL UNTIME FOR 1. Locate the System Folder on your hard drive. 2. Inside the Extensions folder, locate MRJ Libraries and remove or move it to another folder. If you find the “MRJ Enabler” file under Extensions, remove or move it to another folder.
  • Page 84 4. Enter the appropriate information for the Fiery EX2101. —Enter the IP address (or DNS name) of the Fiery EX2101. Name —Enter the name of the device that the Fiery EX2101 is connected New Device EX2101. This device name appears in the Printer Setup section of the...
  • Page 85 2-15 Installing Fiery EX2101 software and fonts 5. When you have entered all the information, click Add. 6. With the device name selected, click OK. The Fiery EX2101 is displayed in a list of configured servers. Fiery EX2101 name and device name (EX2101)
  • Page 86 The Fiery EX2101 is displayed in a list of available servers. Fiery EX2101 name and device name (EX2101) 8. With the Fiery EX2101 selected in the list of available servers, click OK to begin using Fiery Spooler. Modifying the configuration Edit the configuration whenever there is any change to your Fiery EX2101 or network,...

  • Page 87: Configuring A Connection For Fiery Downloader

    O SPECIFY AN IERY CONNECTION 1. Double-click the Fiery Downloader icon. 2. Select the AppleTalk zone in which the Fiery EX2101 is located from the AppleTalk Zones list. The available servers are displayed in the Servers list. Fiery EX2101 name and device name (EX2101) 3.

  • Page 88: Configuring The Connection For Command Workstation Le For Mac Os

    For information on how to use Fiery Downloader, see the Printing Guide. Configuring the connection for Command Workstation LE for Mac OS X The first time you start Command Workstation LE, you are prompted to configure the connection to the Fiery EX2101.
  • Page 89 The Available Servers dialog box appears. All servers found in the local subnet are displayed. 3. If no Fiery EX2101 servers were found, click the Manual tab to search by DNS name or IP address. Click Add to add the server to the Available Servers list.
  • Page 90 IP addresses or the IP address and subnet mask. 5. Click Search. All available servers are displayed in the Available Servers list. 6. Select the Fiery EX2101 server you want to use and click Add. The selected Fiery EX2101 server appears in the Login Server dialog box.
  • Page 91 8. Select a key for Administrator, Operator, or Guest. Your computer is connected to the server. To modify the Command WorkStation connection to the Fiery EX2101, you must remove the server from the Login Server list and follow the preceding procedure for...

  • Page 92: Configuring The Connection For Fiery Vdp Resource Manager

    2-22 Installing User Software on a Mac OS Computer Configuring the connection for Fiery VDP Resource Manager The Fiery VDP Resource Manager allows you to view and delete all global objects used in variable data printing. For more information, see the Printing Guide.
  • Page 93 The Available Servers dialog box appears with all Fiery EX2101 servers located in the subnet displayed. Fiery EX2101 name and device name (EX2101) 3. Click the Manual tab to locate a Fiery EX2101 server by its IP address. Enter the IP address and click Add.
  • Page 94 2-24 Installing User Software on a Mac OS Computer 4. Click the Auto Search tab and then click Advanced to search by either a range of IP addresses or the IP address and subnet mask. 5. Click Add and then click Search. All VDP servers located appear in the Available Servers dialog box.

  • Page 95: Fonts

    The Fonts installer on the User Software CD includes screen and printer fonts that correspond to the 136 built-in PostScript printer fonts on the Fiery EX2101. The Font installer copies both kinds of fonts to the SystemFolder:Fonts folder on your hard disk.

  • Page 97: Chapter 3: Fiery Webtools

    3-1 Setting up Fiery WebTools Fiery WebTools allow you to manage your Fiery EX2101 remotely from the Internet Chapter 3: or from your company’s intranet. The Fiery EX2101 has its own home page, from Fiery WebTools which you can select a variety of functions.

  • Page 98: Using The Installer Webtool

    3-2 Fiery WebTools Using the Installer WebTool The Installer WebTool allows you to download installers for printer drivers, user software, and user documentation directly from the Fiery EX2101 to your computer. O DOWNLOAD PRINTER DRIVER FILES WITH THE NSTALLER 1. Start your Internet or intranet browser and enter the DNS name or IP address of the Fiery EX2101.
  • Page 99 “To install the PostScript or PCL printer driver for Windows NT 4.0” on page 1-13 Windows 2000/XP/Server 2003 “To install the PostScript or PCL printer driver for Windows 2000/XP/Server 2003” on page 1-26 Mac OS “Setting up the Fiery EX2101 as a PostScript printer” on page 2-1...

  • Page 101: Chapter 4: Troubleshooting

    2. Make sure the connection is configured correctly for your site. To check the current configuration, start a Fiery utility and choose Open from the File menu. Select the Fiery EX2101 and click Modify to see current settings. If the settings are incorrect, change them in this dialog box.

  • Page 102: On Mac Os Computers

    4-2 Troubleshooting On Mac OS computers Setting up the Fiery EX2101 in the Mac OS 9 Chooser If Auto-setup does not work and you are prompted to select the printer description file, select the appropriate Fiery EX2101 file in your hard disk: SystemFolder:Extensions:Printer Descriptions folder, “Fiery EX2101 PS”.

  • Page 103: Setting Up The Fiery Ex2101 In The Mac Os X Print Center

    4-3 On Mac OS computers Setting up the Fiery EX2101 in the Mac OS X Print Center If Auto-setup does not work and you are prompted to select the printer description file, select the appropriate Fiery EX2101 file in your hard disk: System:Library: Printers:PPDs:Contents:Resources:language folder (for example, en.lproj) folder,...

  • Page 105: Index

    Index Index Adobe Acrobat EPS files xi for DocBuilder Pro 1-43 Ethernet 100BaseTX cable x installation 1-43 Ethernet, SNAP frame type x Adobe PageMaker for Windows, see PageMaker for Windows Fast Ethernet 100BaseTX cable x Adobe PostScript 3 fonts x Fast Ethernet 10BaseT cable x Adobe PostScript printer driver, see PostScript Fiery Downloader 1-42...
  • Page 106 I-2 Index WebDownloader xiii PostScript printer driver for WebLink xiii Mac OS X 2-5 WebSetup xiii screen and printer fonts 2-25 WebSpooler xiii software for Mac OS 2-11 fonts software for Windows 1-42 Adobe PostScript 3 x installing Adobe Acrobat 1-43 installer for Mac OS 2-25 IP address 1-50 installing 2-25, 4-2, 4-3...
  • Page 107 I-3 Index Print Center selecting the server in Mac OS X 2-5 NetWare client setup setting up server in Mac OS X 4-3 Windows NT 4.0 1-21 Printer Driver, installable options NetWare, network port with Windows 2000/XP 1-29 Windows 98/Me 1-9 Windows 98/Me 1-4, 1-16 printer drivers Oemsetup.inf file 1-2, 1-14, 1-27...
  • Page 108 I-4 Index Uninstalled Fonts folder 4-2, 4-3 uninstalling Mac OS software 2-11 unshielded twisted pair (UTP) cable x User Software CD contents (Mac OS) 2-1 contents (Windows) 1-42 installing from, for Mac OS 9 2-2 troubleshooting fonts 4-2, 4-3 Windows installing Fiery utilities 1-42 troubleshooting 4-1 Windows 2000/XP/Server 2003...

This manual is also suitable for:

Ex2101
