Page 1 Fiery X3e 31C-M Color Server CONFIGURATION GUIDE...
Page 2 ™ This manual is part of a set of Fiery X3e 31C-M Color Server documentation that About the includes the following manuals for users and system administrators: Documentation • The Quick Start Guide summarizes the steps for conﬁguring the Fiery X3e 31C-M Color Server and printing.
Page 3 Copyright © 2004 Electronics for Imaging, Inc. All rights reserved. This publication is protected by copyright, and all rights are reserved. No part of it may be reproduced or transmitted in any form or by any means for any purpose without express prior written consent from Electronics for Imaging, Inc.
Page 4 Pantone, Inc. is the copyright owner of color data and/or software which are licensed to Electronics for Imaging, Inc., to distribute for use only in combination with the products, or software of Electronics for Imaging, Inc. PANTONE Color Data and/or Software shall not be copied onto another disk or into memory except as part of the delivery of the Electronics for Imaging, Inc., products or software.
Page 5 Proprietary Rights You acknowledge and agree that all rights, title and interest, including all intellectual property rights, in and relating to the Software, Documentation and all modiﬁcations and derivative works thereof are solely owned by and shall remain with EFI and its suppliers. Except for the express limited license granted above to use the Software, no right or license of any kind is granted.
Page 6 U.S. Government Restricted Rights: Use, duplication, or disclosure of the Software by the United States Government is subject to restrictions as set forth in FAR 12.212 or DFARS 227.7202-3 - 227.7202-4 and, to the extent required under U.S. federal law, the minimum restricted rights as set out in FAR 52.227-14, Restricted Rights Notice (June 1987) Alternate III(g)(3)(June 1987) or FAR 52.227-19 (June 1987).
Page 7: Table Of Contents
Contents About the Documentation Introduction About this manual Chapter 1: Connecting to the Network Fiery X3e on the network Stages of installation on the network Quick path to installation Connecting network cable to the Fiery X3e 1-11 Back view of the Fiery X3e 1-11 Ethernet connection 1-12...
Page 8 viii Contents Fiery X3e on a network with UNIX workstations 2-17 Tips for experts—UNIX workstations 2-18 Important note about the remote printer name 2-18 Setting up the Fiery X3e on TCP/IP networks 2-19 Managing print jobs 2-21 Chapter 3: Preparing for Fiery X3e Setup Levels of access and control Fiery X3e print connections Passwords...
Page 9 ix Contents Color Setup options 4-50 PrintMe Setup options 4-54 Administrative functions in the Setup menu 4-55 Job Log Setup 4-56 Enable Options 4-58 Exit Setup 4-59 Engine Setup from the Control Panel 4-59 Chapter 5: Setting up the Fiery X3e from a Windows Computer Accessing Setup Remote Fiery Setup General Setup options...
Page 10 x Contents Chapter 7: Administering the Fiery X3e Administrator functions Setting passwords Passwords from the Control Panel Passwords Clearing the Fiery X3e Managing address books Printing a Conﬁguration page from the Control Panel Maintaining optimal Fiery X3e performance Shutting down, rebooting, and restarting the Fiery X3e 7-10 Shutting down and rebooting the Fiery X3e 7-10...
Page 11 xi Introduction This manual is intended for anyone who is responsible for integrating the Fiery X3e Introduction 31C-M Color Server into a business environment that includes networked personal computers. After setting up the Fiery X3e 31C-M Color Server and client workstations, individual users can print to the Fiery X3e 31C-M Color Server as a high-performance PostScript or PCL copier/printer.
Page 12: Xii Introduction
xii Introduction About this manual This manual covers the following topics: • Basic conﬁguration of the Fiery X3e to support printing over AppleTalk, TCP/IP, and IPX (Novell) networks • Administering network printing • Conﬁguring Novell and Microsoft Windows NT 4.0/2000/Server 2003 servers and UNIX systems to provide Fiery X3e printing services •...
Page 13: Chapter 1: Connecting To The Network
1-1 Fiery X3e on the network This chapter summarizes the stages in setting up the Fiery X3e, and includes diagrams Chapter 1: that refer you to other chapters or other manuals for completing your installation. Connecting to Check those references to ﬁnd the information you need quickly. the Network Fiery X3e on the network When the Fiery X3e is connected to a network, it behaves as a networked PostScript...
Page 14: Stages Of Installation On The Network
1-2 Connecting to the Network Stages of installation on the network Installation can be performed by a network or printing administrator. The stages of a successful installation are: • Physically connecting the Fiery X3e to a functioning network Prepare a network node for the Fiery X3e—obtain cable, route it to the location where the Fiery X3e will be installed, and attach the cable to the network interface.
Page 15 1-3 Stages of installation on the network Summary of Fiery X3e network installation ONNECTION Fiery X3e Prepare a network node. Connect the Fiery X3e to the network. If you use a computer running Command WorkStation software, connect it to the network. ERVER CONFIGURATION Network server Conﬁgure UNIX,...
Page 16: Quick Path To Installation
1-4 Connecting to the Network Quick path to installation The diagrams on the following pages show typical systems you can use to print and run Fiery software from remote workstations. Find the page with your preferred platform and network type, and then look up the setup procedures referenced in the “Key to setup”...
Page 17 1-5 Quick path to installation Mac OS environment with AppleTalk Key to setup: 1 Mac OS computer User Software Installation Guide 2 Fiery Setup Chapter 4 Fiery X3e installed in the copier/printer TCP/IP (http) for WebTools AppleTalk Mac OS computer Mac OS computer Mac OS computers can print directly Mac OS computer...
Page 18 1-6 Connecting to the Network Windows computers in a Novell environment Key to setup: 1 NetWare server page 2-14 2 Fiery X3e Setup Chapter 4 Another supported 3 NetWare client User Software Installation Guide protocol 4 Windows computer with SPX page 2-9 Fiery X3e installed in the copier/printer...
Page 19 1-7 Quick path to installation Windows NT 4.0/2000/Server 2003 Server environment Key to setup: 1 Windows Server page 2-3 2 Fiery X3e Setup Chapter 4 Another supported 3 Windows client page 2-6 protocol Windows NT 4.0/2000/XP/Server Fiery X3e installed in the 2003 Workstation or copier/printer Windows NT 4.0/2000/Server 2003...
Page 20 1-8 Connecting to the Network Windows computers using Windows printing Key to setup: 1 Windows computer User Software Installation Guide 2 Fiery X3e Setup Chapter 4 Another supported protocol Fiery X3e installed in the copier/printer TCP/IP (nbt) Windows computer Windows computer Windows computer For Windows printing Windows (SMB) printing enabled on the...
Page 21 1-9 Quick path to installation UNIX workstations and Windows computers on a TCP/IP network Key to setup: 1 UNIX server/host page 2-17 2 Fiery X3e Setup Chapter 4 Another supported 3 UNIX workstation page 2-17 protocol 4 TCP/IP client User Software Installation Guide, Chapter 4 5 Windows client page 2-6...
Page 22 1-10 Connecting to the Network Fiery X3e parallel port connection Key to setup: 1 Fiery X3e Setup Chapter 4 2 Windows computer Printing Guide A supported network protocol Parallel input Fiery X3e installed in copier/printer With the parallel port enabled, the Fiery X3e can accept and print jobs sent Protocol not directly to its parallel port...
Page 23: Connecting Network Cable To The Fiery X3E
1-11 Connecting network cable to the Fiery X3e Connecting network cable to the Fiery X3e In this section, the back panel of the Fiery X3e is illustrated, followed by information for connecting to the Ethernet board. Back view of the Fiery X3e Parallel Port RJ-45 Ethernet (10/100Base T) Power Switch...
Page 24: Ethernet Connection
1-12 Connecting to the Network Ethernet connection For Ethernet connections, the Fiery X3e supports cabling, deﬁned as Category 5 for use with 100BaseT; or as Category 3, Category 4, or Category 5 for use with 10BaseT. The cable uses an 8-pin RJ-45 connector that plugs into the RJ-45 socket on the Fiery X3e.
Page 25: Chapter 2: Setting Up Network Servers
2-1 Fiery X3e on a TCP/IP network with Windows NT 4.0/2000/XP/Server 2003 This chapter describes environments that typically include one or more network Chapter 2: servers—Novell NetWare servers and Windows NT 4.0/2000/Server 2003 servers— Setting up that share printing to the Fiery X3e. It describes setting up servers that use IPX/SPX Network Servers or TCP/IP protocols for communicating with the Fiery X3e.
Page 26: Tips For Experts-Windows With Tcp/Ip
2-2 Setting up Network Servers Typical system combinations are: • Print server running Windows NT 4.0/2000/Server 2003 Server; clients running Windows NT 4.0/2000/XP/Server 2003 Workstation and Windows 98/Me • Print server running Windows NT 4.0/2000/XP/Server 2003 Workstation and clients running Windows 98/Me With TCP/IP protocols loaded, you can run Fiery utilities and WebTools from a Windows computer.
Page 27: Conﬁguring A Windows Nt 4.0/2000/Server 2003 Server To Communicate With The Fiery X3E
2-3 Fiery X3e on a TCP/IP network with Windows NT 4.0/2000/XP/Server 2003 Conﬁguring a Windows NT 4.0/2000/Server 2003 server to communicate with the Fiery X3e To conﬁgure a Windows NT 4.0/2000/Server 2003 server to communicate with the Fiery X3e, follow these general steps. More detail is provided in subsequent sections in this chapter and in your Microsoft documentation.
Page 28 2-4 Setting up Network Servers Adding the Fiery X3e to the TCP/IP network If your TCP/IP network consists of Windows NT 4.0/2000/Server 2003 servers and Windows clients, follow the procedures in this section. If the network includes UNIX workstations, also see the procedures on page 2-19.
Page 29 2-5 Fiery X3e on a TCP/IP network with Windows NT 4.0/2000/XP/Server 2003 Installing the Fiery X3e as a shared printer The ﬁrst step in creating a printer is installing the printer driver ﬁles, which give your applications access to printer features. You can use the installation instructions in the User Software Installation Guide for every workstation that will print directly and independently to the Fiery X3e.
Page 30 2-6 Setting up Network Servers Conﬁguring clients of a Windows NT 4.0/2000/Server 2003 server Each client of a Windows NT 4.0/2000/Server 2003 server is already using a network protocol to communicate with the server. Each client can print to the Fiery X3e if it has been shared by a Windows NT 4.0/2000/Server 2003 server, or Windows NT 4.0/2000/XP/Server 2003 computer.
Page 31 2-7 Fiery X3e on a TCP/IP network with Windows NT 4.0/2000/XP/Server 2003 Conﬁguring Windows computers without a Windows NT 4.0/2000/Server 2003 server If your network does not have a Windows NT 4.0/2000/Server 2003 server, Windows workstations can still print to the Fiery X3e. This method of printing is called Windows, or SMB printing.
Page 32: Fiery X3E On A Netware Network
2-8 Setting up Network Servers Fiery X3e on a NetWare network The NetWise ™ features built into the Fiery X3e support the following network operating environments: • NetWare—NDS (Novell Directory Services) • Servers running NetWare in bindery emulation mode The term “Netware” is used to refer to Netware 4.x, 5.x, and 6.x. Setting up a NetWare environment correctly requires the presence and active cooperation of the Novell network administrator.
Page 33: Tips For Experts-Ipx Networks
2-9 Fiery X3e on a NetWare network Tips for experts—IPX networks Setting up the Fiery X3e is similar to setting up any other PostScript printer on the network. The Fiery X3e with IPX connections has the following characteristics: • A minimum connection to the Fiery X3e consists of a NetWare ﬁle server, a NetWare print server, and a NetWare queue.
Page 34: Conﬁguring A Netware Server For Printing
2-10 Setting up Network Servers You do not need to rerun Setup when you add or remove a NetWare queue; however, you should restart the Fiery X3e after you create or remove a queue. When the Fiery X3e is conﬁgured to connect to a NetWare server, it polls the NetWare server for jobs in each of its queues.
Page 35 2-11 Fiery X3e on a NetWare network Conﬁguring an NDS connection Abbreviations: FS = ﬁle server PS = print server PQ = print queue (on the NetWare server) In Setup from On NDS FS On client workstation Command WorkStation In NETADMIN: Port Setup Install user software.
Page 36 2-12 Setting up Network Servers Setting up an NDS connection In NDS, all NetWare entities (objects) are organized in a hierarchical tree structure. Objects have a name, properties, and a context that deﬁnes the location of the object in the directory tree. For the Fiery X3e, you are mainly concerned with deﬁning a printer, a print server object, and one or more print queue objects.
Page 37 2-13 Fiery X3e on a NetWare network Setting up a NetWare print queue for bindery For NetWare in emulation mode, the NetWare print server and print queue for the Fiery X3e are created and conﬁgured from NetWare Print Console (PCONSOLE), a NetWare utility that is stored in the NetWare PUBLIC directory.
Page 38: Fiery X3E On A Netware Network With Ndps
2-14 Setting up Network Servers Fiery X3e on a NetWare network with NDPS The Fiery X3e supports printing over a NetWare 5.x or later network running either the TCP/IP protocols or the IPX protocol. For pure IP printing, the Fiery X3e takes advantage of features in NDPS (Novell Distributed Print Services).
Page 39: Conﬁguring A Netware Server For Printing With Ndps
2-15 Fiery X3e on a NetWare network with NDPS Conﬁguring a NetWare server for printing with NDPS Before you begin The following procedure assumes NDPS has been installed during NetWare 5.x or later installation and that a Broker is running on the server. Unless you have manually unloaded the Broker, it loads and runs when you install NDPS.
Page 40 2-16 Setting up Network Servers 98/M O SET UP THE PRINTER DRIVER FOR INDOWS 1. Log on to the Novell ﬁle server as a superuser or Administrator. 2. In the SYS:ndps\resdir\Prndrv\Win9x/Me directory, create a folder called Fiery. 3. From the User Software CD, copy the contents of the ENGLISH\INSTALRS\PS_DRVR\WIN_9x/Me folder to the Fiery directory.
Page 41: Fiery X3E On A Network With Unix Workstations
2-17 Fiery X3e on a network with UNIX workstations 5. Under Gateway Types, select Novell Printer Gateway, and click OK. 6. In the Conﬁgure Novell PDS for Printer Agent dialog box, select “((NONE))”, and click OK. 7. In the Conﬁgure Port Handler dialog box, choose “Remote LPR on IP” as the connection type, and click Next.
Page 42: Tips For Experts-Unix Workstations
2-18 Setting up Network Servers Tips for experts—UNIX workstations Setting up the Fiery X3e in a UNIX environment has the same requirements as setting up any printer or new device: • A distinct IP address is required for the Fiery X3e as well as for each workstation on the network.
Page 43: Setting Up The Fiery X3E On Tcp/Ip Networks
2-19 Fiery X3e on a network with UNIX workstations Setting up the Fiery X3e on TCP/IP networks Every machine (host) on a TCP/IP network, including the Fiery X3e, must have a unique 32-bit internet address (IP address). Contact your network administrator to obtain an address for the Fiery X3e.
Page 44 2-20 Setting up Network Servers After the Fiery X3e is set up as a network printer, you can also ping the name you gave to the Fiery X3e: ping <hostname> The server should respond with a message such as Reply from <IP address> ... Some systems will respond with a continuous display of output from the IP address.
Page 45: Managing Print Jobs
2-21 Fiery X3e on a network with UNIX workstations Managing print jobs UNIX network administrators can use UNIX utilities for viewing the list of jobs, and for printing and removing jobs that are spooled on UNIX servers. If the network includes a Windows NT 4.0/2000/XP/Server 2003 workstation that has TCP/IP protocols loaded, you can use Command WorkStation or Fiery Downloader not only to view the list of jobs and to print and remove jobs but also to download fonts...
Page 47: Chapter 3: Preparing For Fiery X3E Setup
3-1 Levels of access and control To prepare for printing at your site, you must do some initial Fiery X3e conﬁguration, Chapter 3: or Setup, to specify the network environment and the kind of printing you will do. Preparing for Before you perform Setup, you must decide the levels of access you will implement for Fiery X3e Setup your site.
Page 48 3-2 Preparing for Fiery X3e Setup In addition, you can enable the Printed queue, which is a storage area for the most recent jobs from the Print queue. The Printed queue makes it convenient to reprint those jobs. In Setup, you can enable the Printed queue and specify the maximum number of jobs retained in the queue (see page 4-8).
Page 49: Passwords
3-3 Levels of access and control Passwords You can implement passwords as a means of controlling access to Fiery X3e functions. The Fiery X3e allows you to set the following passwords in Setup: • Administrator—remotely from Command WorkStation, or locally from the Control Panel •...
Page 50: Webtools
3-4 Preparing for Fiery X3e Setup WebTools The Fiery X3e supports Internet or intranet access with WebTools from Windows and Mac OS computers. To enable use of WebTools, you must do the following in Setup: • Enable TCP/IP. • Set an IP address, subnet mask, and gateway address for the Fiery X3e. •...
Page 51 3-5 Levels of access and control WebLink WebLink provides all users with a link to an address on the Internet. To change the WebLink Internet address, see page 6-3. This function requires the Administrator password, if one has been set (see “Passwords”...
Page 52: Control Level Scenarios
3-6 Preparing for Fiery X3e Setup Control level scenarios Typical scenarios of access and control, ranging from minimum control to maximum control, are described in this section. Choose the scenario that best matches your site requirements, and refer to the corresponding number in the following table for guidance on how to conﬁgure your system for those requirements.
Page 53: About Setup
3-7 About Setup 5. An administrator and an operator; operator controls all jobs; no WebTool access (Maximum control) Only an administrator can perform Setup, calibration, and other administrator functions, and only an operator or administrator can control jobs from the job management tools;...
Page 54: Network Server Setup Requirements
3-8 Preparing for Fiery X3e Setup The ﬁrst time you perform Setup, you must use the Fiery X3e Control Panel. Conﬁgure, at a minimum, Server Setup, Network Setup, and Printer Setup, in that sequence. After the initial Setup, you can change Setup options from the Control Panel (page 4-3) or Command WorkStation.
Page 55 3-9 About Setup O PREPARE FOR IERY E CONFIGURATION 1. Print a copier/printer Test Page to verify the copier/printer is functioning normally. 2. Turn off the copier/printer and connect the interface cable from the copier/printer to the Fiery X3e. 3. To conﬁrm this connection, turn on the copier/printer and the Fiery X3e, and print a Test Page from the Fiery X3e Control Panel.
Page 57: Chapter 4: Performing Setup From The Control Panel
4-1 Fiery X3e Setup from the Control Panel Setup is required the ﬁrst time the Fiery X3e is turned on after new system software is Chapter 4: loaded. In this initial Setup, you (or the service technician who loads the software) Performing choose the language for Fiery X3e Control Panel menus and messages.
Page 58 4-2 Performing Setup from the Control Panel There are two Control Panels for the Fiery X3e. One for the copier and one for the printer. Both are located on the front of the copier/printer and allow you to set options and view information about jobs printed to the Fiery X3e.
Page 59: Fiery X3E Control Panel
4-3 Fiery X3e Control Panel Fiery X3e Control Panel Use the Fiery X3e Control Panel supported at your site, either the copier or printer, to view status information, print special pages, and set up printing. While most elements in the Control Panel display have counterparts in Command WorkStation, you can view current functions on the Control Panel even when Command WorkStation is not connected to the server or is not running.
Page 60: Accessing Setup Options
4-4 Performing Setup from the Control Panel Accessing Setup options O ACCESS ETUP WHEN THE IERY E IS EADY 1. Make sure the information screen on the Control Panel reads Ready. If Printing or RIPping appears, the Fiery X3e is processing, and you must wait until the system ﬁnishes and reaches the Idle state.
Page 61: Types Of Setup Screens
4-5 Fiery X3e Control Panel Types of Setup screens There are two types of Setup options: Multiple choice You are given choices (for example, Yes or No, or a list questions of options from which to choose). Only one choice is displayed at a time.
Page 62: Server Setup Options
4-6 Performing Setup from the Control Panel Server Setup options The Server Setup menu lets you specify system information that pertains to the Fiery X3e and all users. To access the menu, follow the instructions on page 4-4. When you choose Server Setup, the options appear in sequence, as follows. Default values, where applicable, appear in square brackets.
Page 63 4-7 Server Setup options Use Character Set Macintosh/DOS/Windows [Macintosh] Specify whether the Control Panel and Command WorkStation should use the Macintosh, DOS, or Windows character set for displaying ﬁle names. This is important if ﬁle names include accented or composite characters (such as é or æ). For mixed-platform networks, choose the option that gives the best overall representation of the special characters you use.
Page 64 4-8 Performing Setup from the Control Panel Jobs Saved in Printed Queue 1-99 [10] Jobs to Save 1-99 [10] This option appears only if Enable Printed Queue is set to Yes. Specify the number of jobs to be stored in the Printed queue. Jobs in the Printed queue take up space on the Fiery X3e hard disk drive.
Page 65: Network Setup Options
4-9 Network Setup options Network Setup options When you perform Network Setup, you conﬁgure the Fiery X3e to receive print jobs over the network systems that are used at your site. In the Setup menu, choose Network Setup, where you specify network addresses and names to be used by workstations, servers, and the Fiery X3e when they communicate with each other.
Page 66 4-10 Performing Setup from the Control Panel The available network types, and the Setup areas that pertain to them, are summarized in the following table. For this Network or Use this Use this Protocol Setup Use this Service Setup Connection Type Port Setup AppleTalk over Ethernet Ethernet Setup...
Page 67: Port Setup Options
4-11 Network Setup options 6. When you have ﬁnished entering port settings, choose Exit Port Setup, and then choose Protocol Setup. 7. Enter the appropriate settings for the protocol or protocols you will use. 8. When you have ﬁnished entering protocol settings, choose Exit Protocol Setup, and then choose Service Setup.
Page 68 4-12 Performing Setup from the Control Panel Parallel Port Setup options You must enable the parallel port in order to enter the Parallel Port Setup options and print to the parallel port. Network Setup Port Setup Parallel Port Setup Enable Parallel Port Yes/No [No] Select Yes if you want to print through the parallel port.
Page 69: Protocol Setup Options
4-13 Network Setup options Protocol Setup options To conﬁgure the Fiery X3e, choose each protocol and enter the settings for that protocol. You can enable AppleTalk, TCP/IP, and IPX/SPX communication simultaneously. Network Setup Protocol Setup AppleTalk Setup Enable AppleTalk Yes/No [Yes] Select Yes if you have an AppleTalk network connected to the Fiery X3e.
Page 70 4-14 Performing Setup from the Control Panel TCP/IP Setup with Ethernet Network Setup Protocol Setup TCP/IP Setup Ethernet Setup Enable TCP/IP for Ethernet Yes/No [Yes] TCP/IP - Ethernet Yes/No [Yes] Select Yes if you have a TCP/IP network connected to the Fiery X3e over Ethernet cabling.
Page 71 4-15 Network Setup options Get Gateway Address Automatically Yes/No [Yes] Auto Gateway Addr Yes/No [Yes] Use this option to assign the gateway address automatically for printing with TCP/IP. IP Address [127.0.0.1] Enter the Fiery X3e IP address for Ethernet. This IP address, unlike an IP address set automatically, remains the same if you restart the Fiery X3e.
Page 72 4-16 Performing Setup from the Control Panel DNS Setup Network Setup Protocol Setup DNS Setup DNS Setup Enable DNS Yes/No [No] Select Yes to allow the Fiery X3e to resolve a name to an IP address. This option must be enabled to use PrintMe services. Get DNS Automatically Yes/No [No] Auto DNS IP?
Page 73 4-17 Network Setup options Security Setup options Use the IP Filtering and IP Port Setup options for Security Setup. Using IP Filtering options, you can set controlled access to the Fiery X3e by specifying IP address(es) that the Fiery X3e permits or rejects receiving. This prevents unlimited access to the Fiery X3e over your network and ensures network security in your environment.
Page 74 4-18 Performing Setup from the Control Panel Add Filter IP Filter Type IP Address/IP Range [IP Address] Select IP Address to permit or reject individual IP addresses. Select IP Range to specify a range of IP addresses to be permitted or rejected. Up to 16 IP addresses can be speciﬁed.
Page 75 4-19 Network Setup options 137-139 (NetBIOS) Enabled/Disabled [Enabled] Select Enable to enable the 137-139 (NetBIOS) ports. (SMB printing) 161-162 (SNMP) Enabled/Disabled [Enabled] Select Accept to enable the 161-162 (snmp) ports. (Command WorkStation) 515 (LPD/Fiery Tools) Enabled/Disabled [Enabled] Select Accept to enable the 515 (lpd) port. (Fiery WebTools and LPD printing) 631 (IPP) Enabled/Disabled [Enabled] Select Enable to enable the 631 (IPP) port.
Page 76 4-20 Performing Setup from the Control Panel For protocols other than IPX/SPX, the frame type is automatically enabled and does not require setup, as follows: This frame type is With this protocol And these printing services automatically enabled AppleTalk PAP (Printer Access Protocol) Ethernet SNAP TCP/IP with Ethernet LPD (Line Printer Daemon)
Page 77: Service Setup Options
4-21 Network Setup options Service Setup options PServer is a program in the Fiery X3e software that services the Novell print queues assigned to the Novell print servers set up for printing to the Fiery X3e. When you choose PServer Setup and enable PServer, you can set up NDS (Novell Directory Services), Bindery Services, or both.
Page 78 4-22 Performing Setup from the Control Panel Network Setup Service Setup PServer Setup NDS Setup Before entering NDS settings, make sure the Fiery X3e is connected to the network and that you have conﬁgured an NDS directory tree with a Printer, Print Server, and one or more Print Queue objects for Fiery X3e jobs (see page 2-13).
Page 79 4-23 Network Setup options Is user login needed to browse NDS tree? Yes/No [No] Login needed to browse Yes/No [No] Select No if no password is required to browse the tree. You can proceed to navigate to the Print Server object. Select Yes if network permissions require that you log in to browse the NDS tree and see the Print Server object you want to select.
Page 80 4-24 Performing Setup from the Control Panel Enter Password Enter the login password for the NDS tree, using the up and down arrow buttons to select characters, and the left and right arrow buttons to move the cursor. Choose OK (copier) or Set (printer).
Page 81 4-25 Network Setup options Server should look for print queues in: Entire NDS Tree/Specif. Subtree [Entire NDS Tree] Find queues in: Entire NDS Tree/Specif. Subtree [Entire NDS Tree] By default, the Fiery X3e searches the entire NDS tree for Fiery X3e print connections. This option lets you restrict the search for Fiery X3e print jobs to a subtree (the Print Queue root) in which the Fiery X3e print connections have been deﬁned.
Page 82 4-26 Performing Setup from the Control Panel With an object selected, choose OK (copier) or Set (printer) to travel down the tree, or choose “..” to go up the tree. When you select an object and choose OK or Set, that object is then displayed on the top line, and the second line lists objects contained within.
Page 83 4-27 Network Setup options Bindery Setup menu Because you can set up more than one Novell server to handle Fiery X3e print jobs, an additional menu is displayed for this purpose. The options are: • Add File Server—creates a new ﬁle server connection to the Fiery X3e. You can set up a maximum of eight ﬁle server connections.
Page 84 4-28 Performing Setup from the Control Panel Network Setup Service Setup PServer Setup Bindery Setup Add File Server This option gives you two ways to add a Novell NetWare ﬁle server. Select File Server From List/Search by Name [From List] You may select the ﬁle server from a scrollable list, or by a name search.
Page 85 4-29 Network Setup options File Server Login administrator/supervisor/Enter Login Name [supervisor] This option appears only if a password is required for login, or if there is no guest account, or the guest account is restricted. Choose Enter Login Name to enter your own login name and password or log in as a guest.
Page 86 4-30 Performing Setup from the Control Panel Network Setup Service Setup PServer Setup Bindery Setup View Server List Supported servers This option allows you to view the list of ﬁle servers currently connected to the Fiery X3e—that is, servers you have added in Bindery Setup. You are notiﬁed if there are none.
Page 87 4-31 Network Setup options Enter Your Print Server Password Print Servr Password This option appears only if your NetWare print server is password-protected. Enter your print server password. The Bindery Setup menu is displayed again. You can edit other connections, choose another Bindery Setup option, or choose Exit Bindery Setup.
Page 88 4-32 Performing Setup from the Control Panel Polling Interval options Network Setup Service Setup PServer Setup Polling Interval Whether you use NDS or Bindery services, choose Polling Interval from the main PServer Setup menu. If you do not reset the interval, the default value of 15 seconds is used.
Page 89 4-33 Network Setup options Use Automatic Configuration Yes/No [No] Use automatic config Yes/No [No] This option appears if you chose DHCP or BOOTP as the protocol for automatically obtaining the IP address of the Fiery X3e. Choose Yes and the Fiery X3e uses a WINS name server and automatically obtains its IP address.
Page 90 4-34 Performing Setup from the Control Panel WINS IP Address [127.0.0.1] This option appears only if you choose Yes for WINS Name Server. Change the default address to the correct IP address for the WINS Name Server. Obtain the correct address from your network administrator.
Page 91 4-35 Network Setup options Web Services Setup Network Setup Service Setup Web Services Setup Enable Web Services Yes/No [Yes] Select Yes to make the WebTools available to users (see page 6-1). TCP/IP must be enabled on the Fiery X3e and on user workstations. The WebTools include Status, WebLink, WebScan, WebDownloader, WebSetup, and Installer.
Page 92 4-36 Performing Setup from the Control Panel Port 9100 Setup Network Setup Service Setup Port 9100 Setup Enable Port 9100 Yes/No [No] This option enables applications to open a TCP/IP socket to the Fiery X3e at Port 9100 to download a print job. Port 9100 Queue Direct/Print Queue/Hold Queue [Print Queue] Specify the Fiery X3e print connection for downloading jobs to Port 9100.
Page 93 4-37 Network Setup options Enable Remote Diagnostics Yes/No [No] Remote Diagnostics Yes/No [No] Enabling this option allows the service technician to remotely run diagnostics through e-mail. Contact your authorized service/support center for more information. RD Outgoing Server 127.0.0.1 This option appears only if you have selected Yes to Enable Remote Diagnostics. RD Incoming Server 127.0.0.1 This option appears only if you have selected Yes to Enable Remote Diagnostics.
Page 94 4-38 Performing Setup from the Control Panel RD Admin User Name youremail This option appears only if you have selected Yes to Enable Remote Diagnostics. Enter the user name of the Administrator e-mail account. This is typically the part of the e-mail address that precedes the @ symbol.
Page 95 4-39 Network Setup options Fiery E-mail Domain Name Fiery Domain Name Enter the name of the domain in which the user has an account. This is typically the part of the e-mail address that follows the @ symbol. For example, in the address pat@test.com , the domain name is test.com...
Page 96 4-40 Performing Setup from the Control Panel The administrator authorizes a unique e-mail address to remotely administer Fiery E-mail Services via e-mail. If an error occurs while you are executing a job to e-mail, the e-mail service sends an error message to that administrator e-mail address. The administrator can authorize additional e-mail addresses as administrators from this e-mail address.
Page 97 4-41 Network Setup options Enable Proxy Setup No/Yes [No] Select Yes to enable the following proxy server setup options for security purposes when scanning to an FTP site. Selecting No returns you to the main Network Setup menu. Proxy Server IP Address 127.0.0.1 Enter the IP address of the proxy server on your network.
Page 98 4-42 Performing Setup from the Control Panel SNMP Setup Network Setup Service Setup SNMP Setup Enable SNMP Yes/No [Yes] This option enables the SNMP communication over a TCP/IP or IPX connection. Selecting No disables any access to remote Setup through Fiery WebSetup and Command WorkStation.
Page 99: Printer Setup Options
4-43 Printer Setup options For the two options above, a space at the beginning or end of the name is automatically deleted from the name entered. When an invalid character is entered or no name is speciﬁed, the default “public” is used for the community name. A name consisting only of spaces is invalid.
Page 100 4-44 Performing Setup from the Control Panel Publish Direct Connection Yes/No [Yes] Publish Direct Yes/No [Yes] This option allows users to print (or download) jobs to the Fiery X3e without spooling. Jobs printed to the Direct connection are not saved in the Printed queue. If you plan to download fonts to the Fiery X3e, you must publish the Direct connection.
Page 101: Postscript Setup Options
4-45 PostScript Setup options Save Changes Yes/No [Yes] Select Yes to activate any changes made in the Printer Setup; select No to return to the main Setup menu without making any changes. PostScript Setup options PS (PostScript) Setup allows you to set defaults for the Fiery X3e. Users can override most of these defaults on a job-by-job basis.
Page 102 4-46 Performing Setup from the Control Panel Color Mode CMYK/Grayscale [CMYK] Default Color Mode CMYK/Grayscale [CMYK] Specify whether to print color (CMYK) or Grayscale images to the Fiery X3e by default. CMYK gives you full color prints. Select CMYK as the Color Mode before performing calibration on the Fiery X3e.
Page 103 4-47 PostScript Setup options Allow Courier Substitution Yes/No [Yes] Allow Courier Subst. Yes/No [Yes] Specify whether to substitute Courier for fonts that are unavailable when you download ﬁles to the Fiery X3e, or when you print a document for which you do not have the corresponding printer font.
Page 104: Pcl Setup Options
4-48 Performing Setup from the Control Panel PCL Setup options PCL Setup allows you to set defaults to control printer output. These defaults can be overridden by the user from within an application, but they determine how a job will be printed in the absence of other information.
Page 105 4-49 PCL Setup options Paper Size A3/A3Wide/12x18/A3Wide+/12.25x18/Monarch/DL/C10/FLS4/FLS3/FLS2/FLS1/EXE/ 4x6/5.5x8.5/Letter/Legal/11x14/11x17/Hagaki/JIS B6/JIS B5/JIS B4/ISO B4/ISO B5 /A6/A5/A4 [Letter in the United States, A4 elsewhere] Specify the default paper size that the Fiery X3e uses to print PCL jobs. Default Orientation Portrait/Landscape [Portrait] Orientation Portrait/Landscape [Portrait] This option determines whether the text or image will be oriented along the short edge of the paper (portrait) or along the long edge of the paper (landscape).
Page 106: Color Setup Options
4-50 Performing Setup from the Control Panel Symbol Set ASCII/Roman-8/ECMA-94 L1/PC-8... [Desktop] This option lets you choose the symbol set that best matches the needs of users printing to the Fiery X3e. Font Source Internal/Softfont [Internal] Specify the font source to be enabled. Font Number 0-999 [0] The font number designates the default font for the Fiery X3e.
Page 107 4-51 Color Setup options O ACCESS OLOR ETUP OPTIONS In the following list of options, default values, where applicable, appear in square brackets. RGB Source Profile EFIRGB/sRGB (PC)/Apple Standard/None [EFIRGB] The RGB source is the color space used to control color for conversion from monitor to printed output.
Page 108 4-52 Performing Setup from the Control Panel CMYK Simulation Profile SWOP-Coated (EFI)/DIC (EFI)/Euroscale (EFI)/None [SWOP-Coated (EFI) in North America, Euroscale (EFI) elsewhere] CMYK Sim.Profile SWOP-Coated (EFI)/DIC (EFI)/Euroscale (EFI)/None [SWOP-Coated (EFI) in North America, Euroscale (EFI) elsewhere] CMYK simulation allows color correction to simulate printed output on a commercial press, so that the Fiery X3e output can be used for prooﬁng.
Page 109 4-53 Color Setup options RGB Separation Output/Simulation [Output] This option deﬁnes how the Fiery X3e processes RGB jobs. Select Output for RGB jobs that you print to the ﬁnal output device. Select Simulation to simulate an output device that is not the device to which you are printing. Pure Black Text/Graphics On/Off [On] Pure Black Text...
Page 110: Printme Setup Options
4-54 Performing Setup from the Control Panel PrintMe Setup options PrintMe Networks is a mobile and Internet printing technology that allows you to print to any PrintMe-enabled printer anywhere, anytime, and from any Internet-connected device. Mobile users use a PrintMe assigned ID number that allows them to send jobs to a specific printer from any location.
Page 111: Administrative Functions In The Setup Menu
4-55 Administrative functions in the Setup menu Administrative functions in the Setup menu The remaining choices in the Setup menu are intended to help you manage print jobs and color output, but are not required for printing. • allows you to specify whether the Fiery X3e prints and clears its log of Job Log Setup printed jobs automatically.
Page 112: Job Log Setup
4-56 Performing Setup from the Control Panel Job Log Setup The Job Log is a record of all jobs processed or printed on the Fiery X3e, whether they originate from a user workstation, a networked server, or the Fiery X3e. You can print the Job Log from the Control Panel or from the job management tools.
Page 113 4-57 Administrative functions in the Setup menu Auto Clear Job Log Every 55 Jobs Yes/No [No] Auto Clear Job Log Every 55 Jobs Yes/No [No] Use this option to specify whether to clear the Job Log after every 55 jobs. If you do not enable this option, and do not clear the Job Log from the Fiery X3e or from a remote workstation, the Fiery X3e saves a record of all jobs.
Page 114: Enable Options
4-58 Performing Setup from the Control Panel Enable Options In order to enable optional features, such as Spot-On ® , Hot Folders, and Auto Trapping, you must enter the Activation Password when prompted on the Fiery Control Panel. These features are available as optional upgrades. For more information, please contact your authorized service representative.
Page 115: Exit Setup
4-59 Engine Setup from the Control Panel Exit Setup Choose Exit Setup from the ﬁrst screen of the main Setup menu when you have ﬁnished making Setup changes. The Fiery X3e restarts and any changes you saved during the Setup take effect. Engine Setup from the Control Panel Once you have performed all other setup procedures and you have exited setup, the Control Panel displays Idle.
Page 117: Chapter 5: Setting Up The Fiery X3E From A Windows Computer
5-1 Accessing Setup After you perform initial Setup (Server, Network, and Printer Setup) from the Control Chapter 5: Panel, you can change most Setup options from a Windows computer. Setting up the Fiery X3e Accessing Setup from a Windows In addition to using the Control Panel, you can set up the Fiery X3e remotely. You can Computer perform remote Setup from a Windows computer using Command WorkStation.
Page 118 5-2 Setting up the Fiery X3e from a Windows Computer O ACCESS ETUP FROM OMMAND TATION 1. Start Command WorkStation. 2. Log on as Administrator. 3. Choose Setup from the Server menu. Regardless of how you access Setup remotely, the following dialog box appears. The interface of remote Setup from Command WorkStation and WebSetup is identical.
Page 119: General Setup Options
5-3 General Setup options General Setup options You can specify Fiery X3e system settings that affect all users, such as the name of the Fiery X3e, system date and time, passwords, and Job Log printing. —Specify a name for the Fiery X3e. This is the name that appears in the Server Name.
Page 120 5-4 Setting up the Fiery X3e from a Windows Computer —Specify whether to enable the Printed queue, a storage Enable Printed Queue. location on the Fiery X3e hard disk drive for recently printed jobs. You can reprint jobs from the Printed queue without resending them to the Fiery X3e. If the Printed queue is not enabled, jobs are deleted from the Fiery X3e hard disk drive immediately after they are printed.
Page 121: Job Log Setup
5-5 General Setup options Job Log Setup —Specify whether the Fiery X3e prints the Job Log Auto Print Job Log Every 55 Jobs. after every 55 jobs. The Job Log lists the last 55 jobs processed on the Fiery X3e, with accounting information about each one, including user name, document name, time and date printed, number of pages, and other job information.
Page 122: Network Setup
5-6 Setting up the Fiery X3e from a Windows Computer Network Setup Network Setup conﬁgures the Fiery X3e to receive print jobs over the networks used at your site. If the Fiery X3e is conﬁgured to enable more than one protocol, it automatically switches to the correct protocol when it receives a print job.
Page 123: Adapters/Ports
5-7 Network Setup Adapters/Ports Ethernet (Port Setup) —Select to connect the Fiery X3e to an Ethernet network. Enable Ethernet. —Choose Auto Detect if your network environment is mixed, or Transmission Speed. choose the speed of the network to which the Fiery X3e is attached (10 Mbps or 100 Mbps).
Page 124 5-8 Setting up the Fiery X3e from a Windows Computer Parallel Port (Port Setup) —Specify whether you want to print through the parallel port. Enable Parallel Port. You can connect a single Windows computer to the parallel port and print directly to the Fiery X3e.
Page 125: Protocols
5-9 Network Setup Protocols You can change AppleTalk, IPX/SPX, and TCP/IP protocol settings for the Fiery X3e. Change these settings on the Protocol1 and Protocol2 tabs.
Page 126 5-10 Setting up the Fiery X3e from a Windows Computer AppleTalk The current AppleTalk zone is displayed.
Page 127 5-11 Network Setup IPX/SPX Use this option to specify IPX/SPX frame types. The Fiery X3e supports the following Ethernet frame types for IPX/SPX: Ethernet 802.2, Ethernet 802.3, Ethernet II, and Ethernet SNAP. You can also allow the Fiery X3e to select the frame type automatically.
Page 128 5-12 Setting up the Fiery X3e from a Windows Computer DNS Setup You can enable DNS Setup to allow the Fiery X3e to use the Fiery X3e features and also to resolve a name to an IP address.
Page 129 5-13 Network Setup TCP/IP Specify TCP/IP settings. The current settings for IP address, subnet mask, and default gateway address are displayed. For information about setting up printing with TCP/IP, see Chapter 2. The Fiery X3e requires a unique, valid IP address. You can set a static address or specify that the Fiery X3e obtains the IP addresses automatically.
Page 130 5-14 Setting up the Fiery X3e from a Windows Computer To set the subnet mask, enter one of the following values: 255.0.0.0 if the IP address starts with a number less than 128 if the IP address starts with a number from 128 through 191 255.255.0.0 if the IP address starts with a number greater than 191 255.255.255.0...
Page 131: Services
5-15 Network Setup Services You can conﬁgure the following network services: • LPD Printing (TCP/IP)—enable or disable LPD print services. • NetWare Printing (PServer)—specify NDS and Bindery services (see page 5-17). • Windows Print Sharing (SMB)—enable or disable SMB print services. •...
Page 132 5-16 Setting up the Fiery X3e from a Windows Computer LPD Printing —Select to enable or disable LPD printing services. Enable LPD Print Services. —Select to enable or disable web services. Enable Web Services. —Select to enable or disable FTP services. Enable FTP Services.
Page 133 5-17 Network Setup NetWare Printing options Use this option to specify NDS and Bindery services. O SPECIFY THE TREE SETTING FROM REMOTE IERY ETUP 1. Select Enable NDS and click Change Trees. 2. In the NDS Conﬁguration dialog box that appears, double-click an NDS tree in the Available Trees list.
Page 134 5-18 Setting up the Fiery X3e from a Windows Computer 3. In the Select User Login window, select Use Default User Information or enter your password, and click Next. 4. Navigate to the NDS container, select it, and click Next. If necessary, enter the password.
Page 135 5-19 Network Setup 5. Select Use Default Print Queue Root or navigate to the Print Queue Root and click Finish.
Page 136 5-20 Setting up the Fiery X3e from a Windows Computer 6. Click OK. The NDS Conﬁguration dialog box appears, displaying information about the print server.
Page 137 5-21 Network Setup Bindery Setup Use this option to specify Bindery services. O ADD BINDERY CONNECTIONS FROM REMOTE IERY ETUP 1. Select Enable PServer mode from the Service1 tab. 2. Click Bindery Setup. 3. Select a ﬁle server from the Available Servers list. If the File Server User Name and Password dialog box appears, enter the appropriate user name and password to log on to the selected ﬁle server.
Page 138 5-22 Setting up the Fiery X3e from a Windows Computer 4. Select a print server from the list and click Finish. If necessary, enter the appropriate password in the Print Server Password dialog box to log on to the selected ﬁle server. The name of the newly added server appears in the Selected Servers list.
Page 139 5-23 Network Setup O REMOVE BINDERY CONNECTIONS FROM REMOTE IERY ETUP 1. Select Enable PServer mode from the Service1 tab. 2. Click Bindery Setup. The Novell Setup dialog box appears. 3. Make your selection in the Selected Servers list. 4. With the ﬁle server selected in the Selected Servers list, click Remove. 5.
Page 140 5-24 Setting up the Fiery X3e from a Windows Computer PServer Poll Interval Specify the polling interval (in seconds) for NetWare printing.
Page 141: Windows Print Sharing With Server Message Block (Smb)
5-25 Network Setup Windows print sharing with Server Message Block (SMB) To set up the Windows printing service, text ﬁelds may include uppercase letters, numerals, spaces, and the following characters: - _ . ~ ! @ # $ % ^ & ( ) { } \ ' , " Lowercase letters are not allowed, except in the Comment ﬁeld.
Page 142 5-26 Setting up the Fiery X3e from a Windows Computer —Select to enable SMB (Server Message Block), the Enable Windows Printing Service. ﬁle and printer sharing protocol built into Windows. Enabling SMB lists the Fiery X3e on the network so that Windows clients can print to a particular print connection (Hold, Print, or Direct) on the Fiery X3e without any other networking software.
Page 143 5-27 Network Setup —If you have already enabled Auto IP in Protocol Setup, and selected either Auto IP. DHCP or BOOTP as the protocol for obtaining an IP address, select this option to allow the Fiery X3e to obtain the IP address automatically for the WINS Name Server. If you do not select this option, use the following two options to specify whether to use a WINS Name Server and its IP address.
Page 144 5-28 Setting up the Fiery X3e from a Windows Computer Port 9100 printing —Enables applications to open a TCP/IP socket to the Fiery X3e at Enable Port 9100. Port 9100 to download a print job. —Allows you to attach Port 9100 to any of the published Fiery X3e Port 9100 Queue.
Page 145 5-29 Network Setup E-mail Service Setup —Enabling e-mail services is required for all e-mail client E-mail Service Setup. services. —If selected, print jobs sent via e-mail are accepted. If this Enable Print via E-mail. option is cleared, print jobs sent via e-mail are ignored. —Selecting this option allows the service technician to Enable Remote Diagnostics.
Page 146 5-30 Setting up the Fiery X3e from a Windows Computer —Specify the IP address or server name that communicates the Outgoing Mail Server. appropriate mail server and contact information to the Fiery X3e. You must deﬁne both an Incoming and Outgoing mail server. If an Outgoing mail server is not deﬁned, the E-mail Service assumes that the incoming and outgoing server names are the same.
Page 147: Printer Setup Options
5-31 Printer Setup options Printer Setup options From this dialog box, you can access the Printer Setup and Paper Setup tabs. In the following illustrations, “Device name” represents the model of the copier/printer connected to the Fiery X3e, which is 31C-M Printer connections Specify whether to publish the Print queue, Hold queue, or Direct connection.
Page 148: Ps (Postscript) Setup
5-32 Setting up the Fiery X3e from a Windows Computer PS (PostScript) Setup The options in the PS Setup menu in local Setup are located on the Paper Setup tab in remote Setup. In the following illustrations, “Device name” represents the model of the copier/printer connected to the Fiery X3e, which is 31C-M —Specify whether to convert paper sizes automatically to the...
Page 149 5-33 Printer Setup options —Specify whether to print a master document when it is created using Print Master. FreeForm. If you select Yes, when a user creates a master document, it is Ripped, held in the Fiery X3e Hold queue, and printed for your reference. If you select No, the master document is only Ripped and held in the Hold queue.
Page 150: Setting Up Printing Groups
5-34 Setting up the Fiery X3e from a Windows Computer Setting up printing groups The Fiery X3e administrator can arrange users into groups and allow members of a group to print only if they supply a password at print time. This method of printing is known as Printing Groups, or Member Printing.
Page 151: Exiting Setup
5-35 Exiting Setup O REMOVE PRINTING GROUPS AND PASSWORDS 1. Select Printing Groups from the Command WorkStation Server menu. 2. Select the printing group name in the Printing Groups Setup dialog box and click Remove. 3. Click OK. Exiting Setup When you have ﬁnished specifying Setup options, click OK and close the Setup dialog box.
Page 152: Printing The Conﬁguration Page
5-36 Setting up the Fiery X3e from a Windows Computer Printing the Conﬁguration page The Conﬁguration page lists the settings in effect for the current Setup. After you have performed Setup, print a Conﬁguration page to conﬁrm your settings. The other pages you can print from Command WorkStation include the test page, Job Log, color charts, and Font List.
Page 153: Chapter 6: Conﬁguring Fiery Webtools
6-1 Conﬁguring the Fiery X3e and clients for WebTools Fiery WebTools allow you to manage your Fiery X3e remotely from the Internet or Chapter 6: from your company’s intranet. The Fiery X3e has its own home page, from which you Conﬁguring can select a variety of functions, including Status, WebSetup, WebLink, Installer, Fiery WebTools...
Page 154: Setting Up Webtools
6-2 Conﬁguring Fiery WebTools O ACCESS OOLS 1. Start your Internet browser. 2. Enter the IP address or DNS name of the Fiery X3e. 3. Press Enter. The Fiery X3e home page appears. 4. Click the Fiery WebTools icon in the lower-left corner of the window. 5.
Page 155: Setting The Weblink Destination
6-3 Setting the WebLink destination Setting the WebLink destination You can change the pre-set WebLink destination; this function requires the Administrator password, if one has been set. O CHANGE THE INK DESTINATION 1. Start your Internet browser. 2. Enter the IP address or the DNS name of the Fiery X3e. The Fiery X3e home page appears.
Page 157: Chapter 7: Administering The Fiery X3E
7-1 Administrator functions This chapter provides tips on managing Fiery X3e printing. Chapter 7: Administering Administrator functions the Fiery X3e Administration features are included with the user software and are built into the Fiery X3e. The following table describes where to ﬁnd information on these features (page references refer to this manual).
Page 158: Setting Passwords
7-2 Administering the Fiery X3e For these operations And these tasks Controlling the job ﬂow Using WebTools, Command WorkStation and Fiery Printing Guide utilities and for managing job priorities, tracking current Job Management Guide jobs, canceling jobs, printing jobs in the Hold queue, and Release Notes reprinting from the Printed or Hold queue Job accounting...
Page 159: Passwords From The Control Panel
7-3 Setting passwords Passwords from the Control Panel For more information on Administrator access privileges, see page 3-3. For information on controlling print jobs with the job management tools, see the Job Management Guide. The Operator password can be set and changed only from Fiery WebSetup, local Setup, or Command WorkStation.
Page 160: Passwords
7-4 Administering the Fiery X3e Passwords You can set, change, and remove passwords for the Fiery X3e. These passwords, speciﬁc to the Server process, have different uses than the Windows Administrator and Operator passwords. Keep track of the passwords you set for each. —Controls access to Setup;...
Page 161: Clearing The Fiery X3E
7-5 Clearing the Fiery X3e O SET OR CHANGE A PASSWORD 1. Select the password you want to change. 2. Type the password in both the Enter New Password and Verify New Password ﬁelds. Passwords are case-sensitive and can be any combination of letters and numbers up to 19 characters.
Page 162: Managing Address Books
7-6 Administering the Fiery X3e Managing address books The E-mail Service feature allows an administrator to import a list of e-mail addresses to the Fiery X3e by sending e-mail messages to the Fiery X3e. E-mail messages can be sent only from an administrator account. The Fiery X3e supports the following address books: •...
Page 163 7-7 Managing address books The administrator can manage the address books by sending an e-mail to the Fiery X3e with command codes in the Subject and Message ﬁelds. The Fiery X3e responds by e-mail to these commands with information about each request. When managing address books, see the following table.
Page 164: Printing A Conﬁguration Page From The Control Panel
7-8 Administering the Fiery X3e Fiery e-mail Fiery e-mail Administrator subject Task Administrator message ﬁeld response subject response message ﬁeld ﬁeld ﬁeld To delete an #DeleteAddressFrom name name@domain Removed from Deleted Address 1 address of address book Address Book name Deleted Address 2 from an of address book...
Page 165: Maintaining Optimal Fiery X3E Performance
7-9 Maintaining optimal Fiery X3e performance O PRINT THE ONFIGURATION PAGE 1. Make sure the information screen on the Control Panel reads Idle. If Printing or RIPping appears, the Fiery X3e is processing, and you must wait until the system ﬁnishes and reaches the Idle state. 2.
Page 166: Shutting Down, Rebooting, And Restarting The Fiery X3E
7-10 Administering the Fiery X3e • Reduce unnecessary Two-Way Communication Large numbers of users running Fiery utilities, especially with frequent updates, may have a signiﬁcant effect on Fiery X3e performance. • Make sure you have adequate disk space on the Fiery X3e Periodically review the list of jobs in the Hold queue, and the number of jobs being retained in the Printed queue.
Page 167 7-11 Shutting down, rebooting, and restarting the Fiery X3e O SHUT DOWN THE IERY E COPIER 1. Make sure that no jobs are being processed or printed (conﬁrm that the status is Ready). 2. Press the Utility button on the copier Control Panel. 3.
Page 168 7-12 Administering the Fiery X3e O REBOOT THE IERY E COPIER 1. Press the Utility button on the copier Control Panel. 2. In the Touch Panel, press the Controller Detail button. 3. Press the Menu button. 4. Use the down arrow to scroll to Shut Down. 5.
Page 169: Restarting The Fiery X3E
7-13 Shutting down, rebooting, and restarting the Fiery X3e Restarting the Fiery X3e Restarting the Fiery X3e resets the Fiery X3e system software, but does not reboot the entire system. Network access to the Fiery X3e is temporarily interrupted and all currently processing jobs are aborted.
Page 171: Appendix A: Troubleshooting
A-1 Troubleshooting This chapter provides troubleshooting tips. Appendix A: Troubleshooting Troubleshooting the Fiery X3e Startup diagnostics are described in the Installation and Service Guide for service technicians. Contact your authorized service/support center if you see startup error messages on Command WorkStation or if the Fiery X3e does not reach the Idle state. Troubleshooting during Setup from the Control Panel The following section explains some error and alert messages you may see during Setup that might not be self-explanatory.
Page 172 A-2 Troubleshooting After this Setup screen This message Means Frame Type selection Invalid frame size. The network hub is not connected to a Novell server when (Network Setup>Protocol the Fiery X3e tries to bind. Setup>IPX/SPX Setup) Warning! IPX network No other IPX server can be found on the network, or the Enable NDS number is zero.
Page 173 A-3 Troubleshooting After this Setup screen This message Means Select File Server From List Error. Cannot open bindery Select this server through NDS setup or disable NDS and connection to NDS server. select it through bindery. (Network Setup>Service Setup >PServer Setup> No NetWare file No ﬁle server was found when Fiery X3e queried the Bindery Setup)
Page 174 A-4 Troubleshooting After this Setup screen This message Means Add Server, Enter Your Login No NetWare print No print server was found when Fiery X3e queried the ﬁle Name, Enter Your File Server server found. server you selected. Password You must conﬁgure a print server and a print queue for (Network Setup >Service every NetWare ﬁle server that will handle Fiery X3e print Setup >...
Page 175 A-5 Troubleshooting • The Novell network has been conﬁgured with at least one print server and queue for the Fiery X3e. • You have the appropriate permissions and login information, including user name and password, if necessary. • The Fiery X3e is conﬁgured with the correct frame types for communication with the desired Novell servers.
Page 176 A-6 Troubleshooting Novell error Cause Suggested action or exit Indicates other network errors Notify the Novell administrator and report the error when the Fiery X3e is already number. Notify IPX (Novell) connected to a ﬁle server. Administrator. The error screen exits to the PServer Setup screen. Something unexpected has happened and the user generally cannot recover...
Page 177: Runtime Error Messages
A-7 Troubleshooting Runtime error messages For error messages related to canceling jobs and printing, including the Disk Full message and alerts to load media, see the Job Management Guide. These messages are reported by the job management tools. You can turn on PostScript error reporting as a print option from Mac OS applications.
Page 178 A-8 Troubleshooting See the following table for the appropriate name. In this location For this item IPX/SPX networks TCP/IP networks Server Setup Server Name option Administrator deﬁnes Administrator page 4-6 name deﬁnes name Windows hosts ﬁle host name — DNS name page 2-1 (TCP/IP host name) Windows setup for...
Page 179 A-9 Troubleshooting Cannot connect to Fiery X3e with Fiery utilities If users cannot connect to the Fiery X3e, check the following: • Fiery X3e Setup—the appropriate network protocol must be enabled, with the correct parameters (for example, for TCP/IP, the IP address), and you must publish either the Print queue or Hold queue.
Page 181 Index Index Numerics AppleTalk Setup from Control Panel 4-13 100BaseT connector 1-12 from Control Panel, summary 4-10 10BaseT 1-12 from Windows computer 5-10 8-pin RJ-45 connector 1-12 AppleTalk zone 4-13, 5-10 Auto Clear Job Log Every 55 Jobs access level scenarios 3-6 option 4-57, 5-5 access to network and software 3-1 Auto Print Job Log Every 55 Jobs...
Page 182 I-2 Index Choose File Server for editing Bindery conﬁguring servers connection 4-30 from Control Panel 4-11 to 4-59 Chooser from Windows computer 5-1 to 5-35 AppleTalk 4-6, 5-3 preparing for 3-9 choosing a Bindery Server to connected Novell servers, Bindery 4-30 connect 4-28, 5-21 connecting Clear Frame Types, IPX/SPX Setup 4-20...
Page 183 I-3 Index Direct connection Enable TCP/IP for Ethernet described 3-1, 3-2 option 4-14, 5-13 publishing 4-44, 5-31 Enable Web Services option 4-35, 5-27 required for downloading fonts 3-2 Enable Windows Printing option 4-32, 5-26 disconnecting a Bindery ﬁle enabling server 4-27, 4-31 client utilities 4-14 disk space 7-10 Fiery WebTools 4-35, 5-27...
Page 184 I-4 Index Fiery E-mail Domain Name option, E-mail Hold queue 4-44, 5-31 Setup 4-39 described 3-1, 3-2 Fiery E-mail User Name option, E-mail host name 2-2, 2-3, 2-4, A-6 Setup 4-38 database 2-2 Fiery WebDownloader, described 3-5 Fiery WebLink 3-5 Ignore EOF Character option 4-12, 5-8 setting the destination 6-3 improving server performance 7-9...
Page 185 I-5 Index IPX/SPX polling interval 5-24 naming the server 4-6, A-6 protocol setup 4-19 NDPS (Novell Distributed Print selecting frame types 4-20 Services) 2-14 Setup 4-19 NDPS Manager 2-14 summary of Setup options 4-10 NDS (Novell Directory Services) 2-12, 4-21, 5-15 deﬁned 2-8 Java to support Internet browser 6-1 enabling 4-22...
Page 186 I-6 Index NetWare Print Server, Bindery 4-29, 4-30 Parallel Port Setup from Control changing the selection 4-27, 4-30 Panel 4-10, 4-12 connecting 4-29, 4-30 options 4-12 password 4-29 summary 4-10 NetWare Server Poll Interval 4-32 Parallel Port Setup, remote 5-8 NetWise, supported networking timeout setting 5-8 environments 2-8...
Page 187 I-7 Index PostScript Setup, see PS Setup printing groups Preview While Processing 5-4 deﬁning members of 5-34 Print Cover Page option 4-46, 5-33 deﬁning passwords for 5-34 Print queue 3-2, 4-7, 4-44, 5-31 editing printing groups and described 3-1, 3-2 passwords 5-34 publishing 4-44 removing printing groups and...
Page 188 I-8 Index RGB Source option 4-51 Server Setup 3-7 RJ-45 connector 1-12 exiting 5-35 root login 2-19 from Control Panel 4-6 from Windows computer 5-3 part of initial Setup 5-1 safety 4-3 Server Type option, E-mail Setup 4-38, 5-29 Save Changes Service Setup options 4-21, 5-15 Color Setup, Control Panel 4-53 setting up NDS connection 2-12...
Page 189 I-9 Index printing to color server 2-20 remote printer name A-7 TCP/IP setting up printing to color server 2-19 adding server to network 2-4 tips for experts 2-18 Ethernet Setup from Control Panel 4-14 Use Character Set option 4-7, 5-4 host name A-6 Use WINS Name Server option 4-33 http protocol 1-1...
