Fluke 430 Series
Three-Phase Power
Quality Analyzers
Pinpoint power problems
faster, safer and in greater detail
The Fluke 434 and 433 three-phase power quality
analyzers help you locate, predict, prevent and trou-
bleshoot problems in power distribution systems.
These easy-to-use handhelds are a "must have" for
any person who maintains or troubleshoots three
phase distribution. The new IEC standards for
flicker and power quality are built right in to take
the guess work out of monitoring.
•
Records all your necessary values in a three
phase system.
•
Minimal setup required with intuitive menus.
•
Highest safety rating in the industry.
•
Four voltage and four current channels.
•
Captures waveform data on all phases
simultaneously.
•
System-Monitor: Six power quality parameters
on one dashboard
•
Automatic Transient Display: Never miss an event.
•
Auto Trend: Don't waste time setting up recordings.
•
Rugged, handheld recorder.
•
Seven hours operating time per charge on NiMH battery pack.
•
Transfer data files to your PC for reporting and analysis using
FlukeView
software.
®
CAT IV 600 V and CAT III 1000 V safety rating
Designed to help protect you and your equipment against
electrical shock and fire, the Fluke 430 Series analyzers,
accessories and charger are all certified to meet the stringent
safety standards for use in CAT IV 600 V and CAT III 1000 V
environments. They are the first tools of their kind to carry
the CAT IV rating and therefore can be used at virtually all
power connections and outlets in a low-voltage power
distribution system.
Technical Data
