Cooper Wheelock SM87 Series Specification

Description:
These certified strobes have been designed for use in harsh
environmental conditions. The marine grade alloy enclosures
are suitable for use offshore or onshore, where light weight
combined with corrosion resistance and strength is required.
Units can be painted to customer specification and fitted with
identification labels.
A high temperature unit is available.
Architects and Engineers Specifications
Explosion-proof strobes shall be UL and cUL Listed for Class I, Division 1, Groups C&D, and Class I, Zone 1 hazardous
locations. The strobes shall be constructed of marine grade alloy with an epoxy paint finish and shall meet NEMA 4x,
NEMA6, IP 66 and IP 67 environmental requirements over a temperature range of -67°F to 158°F (-55°C to 70°C) in
hazardous and harsh environments.
The strobe shall be rated to flash at 1 Hz with 5 joules per flash. Rated current draw shall not exceed 320 mA at 24 vdc.
The strobe shall be capable of direct surface mounting in any direction.
Note: Due to continuous development of our products, specifications and offerings are subject to change without notice in accord-
ance with Cooper Wheelock standard terms and conditions.
ATEX
Strobe, 5 Joules, Explosion Proof
Features*:
UL Listed for USA and Canada:
★
– Class I, Div. 1, Groups C & D
– Class I, Zone 1 AExd IIB
CSA Certified
★
cUL Listed
★
ATEX Approved
★
NEMA 4x &6, IP66 and IP67
★
Certified temperature –67°F to +158°F (–55°C to
★
+70°C)
High temperature unit (up to 185°F/85°C) available
★
Various lens colors
★
Optional lens guard
★
4 wire monitored connection
★
24 & 48 VDC
★
110, 120, 240 & 254 VAC
★
Xenon
★
29 Candela with clear lens
★
*Depending on version
SM87
