Cooper Wheelock ROS-DC Specification

Description:
The Series ROS 32 Tone Audible Alarm can be used in appli-
cations such as security, general signaling and process alarms.
The wide operating voltage and range of tones available makes
this product adaptable to many uses.
Nominal Voltage: 12/24Vdc
Current Consumption
(tone dependant): Between 6 - 33mA
Sound Output
(tone dependant): Between 64dB - 111dB
Alarm Tones: 32
IP Rating: IP65
Color: Off White
Mounting: Wall
Approvals: LPCB, Vds & UL
273 Branchport Avenue
Long Branch, NJ 07740
Phone: (800) 631-2148
Fax: (732) 222-2588
www.cooperwheelock.com
Series ROS Multitone Audible Alarm
Features:
High Sound Output
Low Current Consumption
32 Tones User Selectable
Automatic Synchronization
Volume Control
Base Compatible with the Series CLR and FLS
Weatherproof
Specification and Ordering Information:
Model Order
Description
Number Code
ROS-DC 4064 Audible Alarm
WE ENCOURAGE AND SUPPORT NICET CERTIFICATION
U
L
®
3 YEAR WARRANTY
Made in USA
ROS 32 09/06
