OPERATION
Ice and Water Dispenser
INTERNAL DISPENSER
The internal dispenser is designed to accommodate a 16-oz
pint glass. Larger containers may be used but may
(.5 L)
compromise the effectiveness of the dispenser.
Drops of water may collect in the removable water grille
located directly below the dispenser. Refer to the illustration
below.
FUNCTION
ICE Press and hold to dispense ice.
WATER Press and hold to dispense water.
WATER
ICE
WATER
GRILLE
Internal dispenser.
EXTERNAL DISPENSER
For large quantities of ice, a bulk ice dispenser is located
inside the refrigerator. Refer to the illustrations below.
Drops of water may collect in the removable water grille
located at the bottom of the glasswell. This is not a drain.
Do not pour water into the water grille.
FUNCTION
ICE Press and hold to dispense ice.
For metered ice, press and hold for 2 seconds.
Dispenser will meter and collect ice before
dispensing into the glass. If held longer, the cycle
repeats for more ice.
WATER Press and hold to dispense water.
LIGHT Press to cycle through lighting options; lights off,
lights on and control panel lights only.
Press and hold for 5 seconds to activate or deacti-
vate the dispenser lock. Lock indicator will be
illuminated when dispenser is locked.
BULK ICE Press and hold to dispense large quantities of ice.
ICE
WATER
LOCK
INDICATOR
LIGHT
WATER
GRILLE
External dispenser.
BULK ICE
Bulk ice dispenser.
|
