Rear Panel

fig.2
1
1 AC IN
Connect the included power cable here.
2 WORD CLOCK IN/OUT Connectors
IN:
When supplying a sampling clock from an external device to the ADA-7000, input the
WORDCLOCK signal here. Use this when you want the reference clock to be another
device that outputs a high-precision sampling clock, or when synchronizing to a device
that has only a WORDCLOCK OUT.
fig.3.e
• If you have selected "WORD CLOCK" as the sampling clock of the ADA-7000,
• If the master clock of the device connected to the R-BUS connector is the word
3
2
4
To avoid malfunction, connect only the power supply cord that was supplied
with the unit.
Sampling Clock Master
Digtal Tape Recorder
WORD CLOCK OUT
TERMINATOR
WORD CLOCK IN
SWITCH: ON
ADA-7000
CLOCK SOURCE: WORD CLOCK
you must set the master clock of the connected device to the R-BUS to which that
ADA-7000 is connected.
clock signal, you must select "R-BUS" as the sampling clock of the ADA-7000.
Front and Rear Panels
5
6
9
