" Sony Super HAD II CCD
1
3
12VDC/24VAC
NVD Bullet Cameras have an ultra-low Lux rating of 0.00006 allowing the
camera to see in almost total darkness.
Note: Products with model numbers that end with "Q" or that have a round green "Q" sticker are RoHS compliant.
DNR / DWDR / IR
NVD Bullet Camera
with 4-Axis Mounting Arm
Installation Manual
3 Cameras in 1:
EV-1726-NKGQ
EV-1726-PKGQ
EV-1726-NWGQ
EV-1726-PWGQ
(NTSC)
2.8~12mm
(PAL)
(NTSC)
6~50mm
(PAL)
OSD with service monitor port
600 TV lines
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SECO-LARM Enforcer EV-1726-NKGQ
Summary of Contents for SECO-LARM Enforcer EV-1726-NKGQ
- Page 1 DNR / DWDR / IR NVD Bullet Camera with 4-Axis Mounting Arm Installation Manual 3 Cameras in 1: EV-1726-NKGQ (NTSC) 2.8~12mm EV-1726-PKGQ (PAL) EV-1726-NWGQ (NTSC) 6~50mm EV-1726-PWGQ (PAL) ” Sony Super HAD II CCD OSD with service monitor port 12VDC/24VAC 600 TV lines NVD Bullet Cameras have an ultra-low Lux rating of 0.00006 allowing the camera to see in almost total darkness.
-
Page 2: Specifications
ENFORCER DNR / DWDR / IR NVD Bullet Camera with 4-Axis Mounting Arm Specifications: EV-1726-NKGQ (NTSC) EV-1726-NWGQ (NTSC) EV-1726-PKGQ (PAL) EV-1726-PWGQ (PAL) Type IR LED Bullet Camera Pickup Element ” Sony Super HAD II CCD Resolution 600 TV lines Lens (DC Auto Iris) 2.8~12mm 6~50mm # of Infrared LEDs... - Page 3 ENFORCER DNR / DWDR / IR NVD Bullet Camera with 4-Axis Mounting Arm Overview: Mounting screw Sunshield Hex screw Rubber grommet Mounting plate 4-Axis mounting arm BNC connector Service Zoom Mounting base monitor port Focus Connect DC Jack DC plug with OSD joystick service monitor terminal block...
-
Page 4: Troubleshooting
ENFORCER DNR / DWDR / IR NVD Bullet Camera with 4-Axis Mounting Arm Troubleshooting Check that the camera is powered up. Check that the power supply’s polarity is correct. The screen is blank. Check that the monitor is powered up. Check that the video cable connecting the camera to the monitor is connected properly.
