Using the EXT MGMT Port as a Serial Port
Although the iMcV-FiberLinX does not include a DB-9 serial port, the
supplied RJ-45 to DB-9 adapter can be used on the EXT MGMT port to
perform serial port configuration. This adapter uses an IBM-compatible
DB-9 serial connector.
To connect the iMcV-FiberLinX to a terminal/computer, use a straight-
through (pin-to-pin) cable. (If the computer/terminal has a COM port using
a connection not compatible with a DB-9 connector, use the pin connec-
tion chart for reference in making a cable.) The cable length should be
under 50 ft. (15.24 m). Plug one end of the cable into the DB-9 connec-
tor on the iMcV-FiberLinX and the other into the appropriate port on the
computer/terminal. Set the computer/terminal for VT-100 emulation. The
serial port on the computer/terminal should be set for: 38.4K baud, 8 data
bits, 1 stop bit, no parity and no flow control.
S A
E R I A L
RJ-45 Pin #
5
7
8
1-3 3 , 6
P C
D A P T E R I N O N N E C T I O N
DB-9 Pin # Function
2
Transmit (OUT)
3
Receive (IN)
5
Ground
1, 4, 6 - 9 9
Reserved
