Single iMcV-FiberLinX Application — No VLAN IDs
The illustration below shows a typical application, followed by configu-
ration information, for deploying a single iMcV-FiberLinX with no VLAN IDs
assigned.

Figure E: Single FiberLinX Application without VLAN IDs

SNMP
Hardware
DATA
Configuration
Port
Standalone OFF
SNMP SNMP
Optics EXT MGMT Basic
Port Port
ON OFF OFF
7
Host Remote
OFF OFF
