Figure F: Dual Fiberlinx Application With Vlan Ids - IMC Networks iMcV-FiberLinX Operation Manual

VLAN Environment - Transparency Mode Disabled
Host/Remote Application— VLAN IDs
The illustration below shows a typical application, followed by configu-
ration information, for deploying dual iMcV-FiberLinX units and assigning
VLAN IDs.

Figure F: Dual FiberLinX Application with VLAN IDs

Hardware SNMP
Configuration DATA Port
Host OFF
Remote OFF
VLAN Port OPTICS
Config. VLAN ID
Host N/A
Remote N/A
Enable this if the connected device is VLAN-compatible. If using VLAN func-
tionality, the connected device's VLAN ID must be the same as the iMcV-
FiberLinX's SNMP VLAN ID.
Since both the OPTICS port and the DATA port are enabled for VLAN
tags, define Data VLANs rather than entering a VLAN ID for the DATA and
OPTICS ports. Up to 10 VLAN IDs can be entered.
Data VLANs 1
ID # 9
SNMP SNMP
OPTICS EXT MGMT
Port Port
ON ON
ON OFF
EXT MGMT
DATA
Tag
Tags Tags
(see note)
Y Y Y
Y Y N
NOTE
2 3 4 5
67 25 33 56
8
Basic Host Remote
OFF ON OFF
OFF OFF ON
SNMP RDB
VLAN ID VLAN ID
55 57
55 57
6 7 8 9
12 17 6 304
10
48
