Requirements

The iMcV-T1/E1/J1-LineTerm conforms to any T1/E1/J1-based environment.
Ensure all of the relevant information about the expected installation environment
is available before configuring the module. This information includes:
•
Line Type T1 or E1
•
Line Coding used on T1: either AMI or B8ZS
•
Distance of the copper run for DSX1 lines (655 feet MAX)
•
Required CSU line Buildout (0db to -22db)
•
Receiver BOOST for T1 and E1 applications
•
Fiber transceivers must be for appropriate fiber run, i.e. (SM or MM)
•
Management location must be at HOST unit
