Unmanaged Modules - IMC Networks iMcV-DS3/E3/STS-LineTerm Operation Manual

2
iView supports the following platforms:
•
Windows 2000
•
Windows XP
•
Windows Vista
•
Windows 7
In addition, there are Java versions of iView² for any Java-capable operating systems
such as Linux.
Please see the SNMP Management Module installation guide for software
configuration options.

Unmanaged Modules

Before installing the module in an unmanaged chassis, manually configure all of the
desired DIP Switch selectable features.
DIP Switches
The iMcV-DS3/E3/STS-LineTerm DIP Switches are located at S1 and S2 on the PCB.
The S2 DIP Switches are factory configured and must not be changed. The S1 DIP
Switches provide control over the available iMcV-DS3/E3/STS-LineTerm features.
The location of the S1 DIP Switches is displayed in the following diagram:
3
