Specifications - IMC Networks iMcV-DS3/E3/STS-LineTerm Operation Manual

Specifications

Standards Compliance (DS3, E3/STS, STS):
ANSI T1.102-1993
ANSI T1.107.1995
GR-820-CORE
DS3, E3/STS, STS Interface:
BNC coax 75 +/- 5% ohms
DS3 (44.736 Mbps +/- 20 ppm)
E3/STS (34.368 Mbps +/- 20 ppm)
STS (51.840 Mbps +/- 20 ppm)
Power Consumption (Typical):
0.550 Amps @ 5 V
Operating Temperature:
+32°F to +122°F (0°C to +50°C)
Storage Temperature:
-4°F to +158°F (-20°C to +70°C)
Humidity:
5% to 95% (non-condensing); 0 to 10,000 ft. altitude
Dimensions:
4.19" x .78" x 2.75"
(106.4 mm x 19.81 mm x 69.85 mm)
12
