MMG130 Specifications Continued:
ELECTRICAL CONTROLS
•
Remote start / stop contacts located next to lug box
•
Lockable control box door with diagnostics window
•
Lockable lug box with safety switch
o Trips main breaker when lug door is opened
o Disables voltage regulator
•
Cable entry guides to the lug box
o Restricts access of foreign objects
•
Output ground connection lug inside lug box
•
Convenience receptacles with individual breakers (restricted use in high wye mode)
o (2) 120V 20 Amp GFCI duplex outlets (Nema 5-20R type)
o (3) 125 / 250V 50 Amp, 3 pole, 4 wire twistlock (Non-Nema 6369)
•
Panel mounted rheostat for voltage adjustment - +/- 10%
•
1000 CCA wet cell battery
ENCLOSURE
•
Generac Mobile Power decals
•
Aluminum, sound attenuated enclosure
o UV & fade resistant, high temperature cured, white polyester powder paint
o Insulated and baffled
o 68 dB(A) at 23 feet – prime power
•
Fully lockable enclosure including doors and fuel fill
•
Stainless steel hinges on doors
•
Emergency stop switch located on outside of enclosure
•
Central lifting point
•
Multi-lingual operating/safety decals
•
Document holder with operating manual including AC/DC wiring diagrams
TRAILER
•
DOT approved tail, side, brake, and directional lights
o Recessed rear lights
•
Transportation tie downs
•
Safety chains with spring loaded safety hooks
•
3" lunette ring hitch
•
(2) 6000 lb. axles with surge brakes
•
5000 lb. tongue jack with footplate
•
7.50x16E-6-W tubeless tires – 10 ply
WEIGHTS & DIMENSIONS
Skid mounted
•
Dry weight: 5444 lbs (2469 kg)
•
Operating weight: 7929 lbs (3596 kg)
•
144 x 50 x 77 in
(3.66 x 1.27 x 1.95 m)
Manufactured by Magnum Power Products LLC., a wholly owned subsidiary of Generac Power Systems, Inc.
Phone: 800-926-9768 Fax: 920-361-2214
www.m-p-llc.com
Page 3 of 5
06/12
