Specifications
Enclosure . ........................................................................... NEMA Type 1, or NEMA 3R, galvanized G90 steel w/ polyester powder coat
Main Breaker .......................................................................................................................................................................... 200 Amp
Generator Switch .................................................................................................................................................................... 125 Amp
4 of 4
Main breaker wire size ........................................................................................................................................# 1 to 300 mcm Cu-Al
Generator switch wire size .............................................................................................................................. # 2 to 1/0 Cu, 1/0-2/0 Al
Neutral Lug .................................................................................................................................................................. # 6 to 300 mcm
Ground Lug . ............................................................................................................................................................................# 14- 2/0
Maximum number of circuits
(standard 1" breakers / tandem breakers)
Protected circuits ...................................................................................................................................................................... 18/30
Non-protected circuits ...............................................................................................................................................................10/NA
Total circuits . ............................................................................................................................................................................. 28/40
Withstand rating Main bus (amps)............................................................................................................................................... 10,000
Meets NEC wire bending space . ........................................................................................................................................................ Yes
ETL listed . ......................................................................................................................................................................................... Yes
Seismically qualified to meet UBC code . ............................................................................................................................................ Yes
Weight – GenReady Basic w/o EZ Transfer Operator
(GenReady Advanced with EZ Transfer Operator) . ........................................................................................................45.5 lbs. (49 lbs.)
Operating temperature range ......................................................................................................................................... -20º F to 140º F
Installation Options
GenReady™ Basic
The GenReady load center is installed
without the EZ Transfer Operator. It replaces
the home's main load center. This option will
save the homeowner thousands in upgrade
costs when a generator is installed.
The GenReady load center is installed with
the EZ Transfer Operator. All fuel and electri-
cal lines (contractor supplied) are installed
to the planned generator site along with the
generator pad (if required). The home is
completely wired and ready for the addition
of a generator in the future.
The NEMA 3R GenReady installation is similar but is suitable for outdoor installations.
®
Generac Power Systems, Inc. • S45 W29290 HWY. 59, Waukesha, WI 53189 • generac.com
©2012 Generac Power Systems, Inc. All rights reserved. All specifications are subject to change without notice. Bulletin 0175200SBY-J Printed in U.S.A. 12/12/12
GenReady™ Load Centers and Transfer Swtich
GenReady™ Advanced
GenReady™ Complete
Everything included in the GenReady
Advanced level is installed along with an
automatic standby generator. The home's
selected circuits will be backed up by gen-
erator power whenever the utility is lost.
®
