INSTALLATION AND OPERATION MANUAL
BH/BA 2500, BH/BA 3000, BH/BA 3500, SH/BA 3500,
SH/BA 5000, SH/WO 3500, SH/WO 5000 & SH/WO 8000
FOR YOUR SAFETY:
DO NOT STORE OR USE GASOLINE
OR OTHER FLAMMABLE VAPORS OR
LIQUIDS IN THE VICINITY OF
THIS OR ANY OTHER
IMPROPER INSTALLATION, ADJUSTMENT,
ALTERATION, SERVICE OR MAINTENANCE
CAN CAUSE PROPERTY DAMAGE, INJURY,
OR DEATH. READ THE INSTALLATION,
OPERATING AND MAINTENANCE
INSTRUCTIONS THOROUGHLY
BEFORE INSTALLING OR
SERVICING THIS EQUIPMENT
Users are cautioned that maintenance and repairs must be performed by a Garland authorized service agent
using genuine Garland replacement parts. Garland will have no obligation with respect to any product that has been
improperly installed, adjusted, operated or not maintained in accordance with national and local codes or installation
instructions provided with the product, or any product that has its serial number defaced, obliterated or removed,
or which has been modified or repaired using unauthorized parts or by unauthorized service agents.
For a list of authorized service agents, please refer to the Garland web site at http://www.garland-group.com.
The information contained herein, (including design and parts specifications), may be superseded and is subject
to change without notice.
GARLAND COMMERCIAL INDUSTRIES
185 East South Street
Freeland, Pennsylvania 18224
Phone: (570) 636-1000
Fax: (570) 636-3903
Part # 4520899 Rev1 (09/04/08)
Part # 4520899 Rev 1 (09/04/08)
GARLAND RTCS TECHNOLOGY
TABLE TOP INDUCTION COOKERS,
MODELS: BH/BA 1500, BH/BA 1800,
86037
APPLIANCE
WARNING:
GARLAND COMMERCIAL RANGES, LTD.
1177 Kamato Road, Mississauga, Ontario L4W 1X4
CANADA
Phone: 905-624-0260
Fax: 905-624-5669
C
CM
PLEASE READ ALL SECTIONS OF THIS MANUAL
AND RETAIN FOR FUTURE REFERENCE.
THIS PRODUCT HAS BEEN CERTIFIED AS
COMMERCIAL COOKING EQUIPMENT AND
MUST BE INSTALLED BY PROFESSIONAL
PERSONNEL AS SPECIFIED.
INSTALLATION AND ELECTRICAL CONNECTION
MUST COMPLY WITH CURRENT CODES:
IN CANADA - THE CANADIAN ELECTRICAL
CODE PART 1 AND / OR LOCAL CODES.
IN USA – THE NATIONAL ELECTRICAL CODE
ANSI / NFPA – CURRENT EDITION.
ENSURE ELECTRICAL SUPPLY CONFORMS WITH
ELECTRICAL CHARACTERISTICS SHOWN ON
THE RATING PLATE.
© 2005 Garland Commercial Industries, Inc.
Enodis UK LTD.
Swallowfield Way, Hayes, Middlesex UB3 1DQ ENGLAND
Telephone: 081-561-0433
Fax: 081-848-0041
Page 1
Advertisement
Table of Contents
Related Manuals for Garland BH/BA 1500
Summary of Contents for Garland BH/BA 1500
- Page 1 Users are cautioned that maintenance and repairs must be performed by a Garland authorized service agent using genuine Garland replacement parts. Garland will have no obligation with respect to any product that has been improperly installed, adjusted, operated or not maintained in accordance with national and local codes or installation instructions provided with the product, or any product that has its serial number defaced, obliterated or removed, or which has been modified or repaired using unauthorized parts or by unauthorized service agents.
- Page 2 Page 2 Part # 4520899 Rev 1 (09/04/08)
-
Page 3: Important Information
IMPORTANT INFORMATION The instructions in this manual are fundamentally important and must be taken into account during assembly, operation Warning and maintenance. They must therefore be read very carefully Risk of fire or electric before installation and operation by the responsible shock specialist staff and the operator(s). - Page 4 Page 4 Part # 4520899 Rev 1 (09/04/08)
-
Page 5: Table Of Contents
Maintenance ....... 13 Single Unit BH/BA 1500, BH/BA 1800, TROUBLESHOOTING . . . . . . . . . . . . . . . . . . 14 BH/BA 2500, BH/BA 3000 And BH/BA 3500 . -
Page 6: Dimensions And Specifications
41º to 104ºF (5º to 40ºC) Storage 10%-90% Maximum Relative Humidity Of Air Function 30%-90% ELECTRICAL SPECIFICATIONS MODEL VOLTAGE Total KW Weight BH/BA 1500 120V 1.5 kW 19.8 lb (9kg) BH/BA 1800 120V 1.8kW 19.8 lb (9kg) BH/BA 2500 208/230/240 2.5kW 19.8 lb (9kg) -
Page 7: General Information
Components Supplied The unit is delivered complete and in working order. Product Overview Garland supplies several basic types of units with different performances and measurements. Built with a robust method of construction, they are compact and powerful with a revolutionary technology in a complete case of CrNi-steel. -
Page 8: Installation
INSTALLATION Siting Dimensions And Clearances Single Unit BH/BA 1500, BH/BA 1800, The cooker has to be set up on a even place like a table. The air inlet and air outlet must not be obstructed, the area must BH/BA 2500, BH/BA 3000 And BH/BA 3500 be able to withstand a loading of 88 lbs (40 kg). -
Page 9: Single Unit Sh/Ba 3500 And Sh/Ba 5000
INSTALLATION continued Single Unit SH/BA 3500 and SH/BA 5000 SH/WO 3500, SH/WO 5000 and SH/WO 8000 15.0" [380mm] 3.3" 3.0" 8.7" [85mm] [75mm] [220mm] 3.3" 3.0" 8.7" [85mm] [75mm] [220mm] exhaust exhaust Ceran plate WOK Ceran bowl Ø 11.8" [300mm] 15.0"... -
Page 10: Cooker Setup
INSTALLATION continued Cooker Setup 2. Turn the control knob ON (in a position between 1 and 12 (9)). The indicator will light will illuminate (green) and the The cookers are equipped with a mains cable. They have to water will be heated. be connected to a wall socket. -
Page 11: Operation
OPERATION Cooking Process Out Of Operation The induction cooker is switched on by turning the control If the cooker is not in use make sure that the control knob is in the “OFF” position. If you don’t use the cooker for a long ➯... -
Page 12: Unauthorized Reconstruction And Use Of Spare Parts
OPERATION continued Unauthorized Reconstruction • Do not insert any piece of paper, cardboard, cloth, etc. between the pan and the heating area, as this might And Use Of Spare Parts initiate a fire. Reconstruction of the cooker or changes to the cooker are • Since metallic objects are heated up very quickly when not allowed. Contact the manufacturer if you intend to placed on the heating area, do not place any other make any changes on the cooker. -
Page 13: Maintenance And Cleaning
MAINTENANCE AND CLEANING NOTE: ensure no liquid can enter the induction unit, do Ceran glass not clean the cooker with a jet of water . 1. The cleaning of the Ceran glass is identical to other Cleaning similar surfaces like glass. Do not use corrosive or abrasive cleaning agents, such as grill- and oven-sprays, stain- and Slight soiling, no burned residues rust-removers, scouring powder and rough sponges. -
Page 14: Troubleshooting
TROUBLESHOOTING The cookers may only be opened by authorized service NOTE: Stop any actions if the heating area (Ceran glass) is personnel. cracked or broken. The induction cooker must be switched off and disconnected from the electric supply. Don’t touch any parts inside the cooker. -
Page 15: Malfunction Without Error Code
TROUBLESHOOTING continued Malfunction Without Error Code Fault Possible Cause Action To Take By Operator Or Operating Personnel No heating No mains supply Check the electrical supply (cable plugged Operation indicator light onto the wall socket) is OFF (dark) Check preliminary fuses Control knob is in OFF-position Turn control knob ON Cooker is defective... - Page 16 TROUBLESHOOTING continued Fault Possible Cause Action To Take By Operator Or Operating Personnel After a long permanent Coil overheated, cooking area too hot Switch cooker off, remove pan and wait until operating time, the Empty pan the cooking area has cooled off heating switches off and Pan with overheated oil on within minutes...
-
Page 17: Waste Disposal Procedures
WASTE DISPOSAL PROCEDURES Avoid abuse: The symbol on the product or on its packaging indicates that this product may not be treated as household waste. Only persons with proper qualifcations may operate the Instead it shall be handed over to the applicable collection cooker. - Page 18 Page 18 Part # 4520899 Rev 1 (09/04/08)
- Page 19 Part # 4520899 Rev 1 (09/04/08) Page 19...
