Set theTimer Stop Time
AUTO FAN
The display shows a normal system. Press and hold the MIN button (Figure
4) for 3 seconds. Note the Timer start - stop times may be set even when
the system is in the Schedule mode.
Use the or button to adjust the hour. Press the TIMER SET button
(Figure 4) to advance to the Minutes section.
Use the or button to adjust the minutes. Press the TIMER SET
button (Figure 4) within 15 seconds to exit and save the setting. The timer
is now set to stop at 11:55 AM. The display returns to normal.
Turning the TIMER ON once the time and day, the start and top times
have been set:
TIMER
Press the button once and let go.
SCHEDULE
NOTE: See the following TIMER
18
16
F
SET POINT
FRR144
AM
OFF
FRR145
OFF
FRR146
ON/OFF scenarios.
Timer ON Scenarios
Scenario 1
AUTO FAN
The display shows a normal operating system.
If the Timer function is turned ON during the Timer's OFF time, the
illuminates. The control system immediately turns the unit OFF.
Scenario 2
AUTO FAN
The display shows a normal operating system.
AUTO FAN
If the Timer function is turned ON during the Timer's ON time, the
illuminates. The control system immediately turns the unit OFF.
F
SET POINT
FRR156
FRR157
F
SET POINT
FRR158
F
SET POINT
FRR159
icon
icon
