2008 / 2009 PERFORMANCE DATA
EVAPORATOR AIR EVAPORATOR TEMP.
TEMP. DEG. F
COOLING
PERFORMANCE
Discharge Temp.
DATA*
Air Drop F.
WS08B10A-D 55 25
WS08B10A-F 55 25
WS10B10A-D 52 28
WS14B10A-D 52 28
WS14B10A-E 52 28
WS10B30A-D 55 25
WS13B30B-E 50 30
WS13B30B-F 50 30
WS16B30A-D 52 28
WS16B30A-E 52 28
WE10B33A-C 53 27
WE10B33C-A 53 27
WE13B33B-D 50 30
WE13B33C-A 50 30
WE13B33B-E 50 30
WE16B33A-C 52 28
WE16B33C-A 52 28
WE16B33A-D 52 28
WY10B33A-C 53 27
WY10B33C-A 53 27
WY10B33A-D 53 27
WY13B33A-C 52 29
WY13B33C-A 52 29
WY13B33A-D 52 29
* Rating Conditions: 80 degrees F, room air temp. & 50% relative humidity, with 95 degree F, outside air temp & 40% relative humidity
Specifications
Cooling
Capacity
Model BTU/h
WALLMASTER
WS08B10A 8000
WS10B10A 10000
WS14B10A 13500
WS10B30A 10000/10000
WS13B30B 12500/12000
WS16B30A 15800/15000
WE10B33C 10000/10000 11000/9100 230/208
WE13B33C 12500/12000 11000/9100 230/208
WE16B33C 15800/15000 11000/9100 230/208
WY10B33C 10100/9800
WY13B33C 12500/12100 10400/10000 230/208
Sleeve / Chassis Dimensions
Model Height Width
16 3/4" 27"
WSC Sleeve
Chassis
15 3/4" 26 1/2"
6
DEG. F
CONDENSER
Discharge
TEMPERATURE
Temp
DEG. F
T(in) T(out)
55 55 127 165
55 55 125 179
53 51 128 176
52 52 128 179
52 52 128 179
53 57 131 179
52 50 131 180
52 50 131 180
51 53 121 154
51 53 121 154
54 52 126 180
54 52 126 180
52 50 131 180
52 50 131 180
52 50 131 180
51 53 121 174
51 53 121 174
51 53 121 174
54 52 126 180
54 52 126 180
54 52 126 180
52 51 127 180
52 51 127 180
52 51 127 180
E S models
®
NERGY TAR
Heating
Capacity Volts Cooling
BTU/h Rated Amps
— 115 6.8
— 115 8.7
— 115 12.0
— 230/208 4.6/5.0
— 230/208 6.3/6.7
— 230/208 7.8/8.5
4.6/5.0
6.3/6.7
7.8/8.5
8100/7800 230/208 4.6/4.8
6.4/6.8
Depth Minimum Minimum
with Extension Extension
Depth Front Into Room Outside
16 3/4" 23" 7 1/2" 9/16"
21" – – –
Suction Liquid Sub-
Super Heat
Temp Temp Cooling
Suction
61 102 18 25 87
74.5 102 18 25 87
68 105 16 24 79
63 99 14 28 82
63 99 14 28 82
68 106 16 23 77
61 103 13 24 81
61 103 13 24 81
54 99 18 32 74
54 99 18 32 74
82 99 16 31 82
82 99 16 31 82
61 103 13 24 81
61 103 13 24 81
61 103 13 24 81
57 100 18 30 74
57 100 18 30 74
57 100 18 30 74
66 99 16 31 82
66 99 16 31 82
66 99 16 31 82
64 103 16 29 80
64 103 16 29 80
64 103 16 29 80
Cooling Heating Heating
Watts Amps Watts
762 — —
954 — —
1415 — —
1005/996 — —
1404/1379 — —
1756/1705 — —
1005/996 16.0/14.7 3550/2950
1404/1379 16.0/14.7 3550/2950
1756/1705 16.0/14.7 3550/2950
1013/976 3.9/4.0 857/821
1389/1352 5.4/5.7 1182/1136
Thru-the-wall
Finished Hole
Height Width
17 1/4" 27 1/4"
– –
OPERATING
ELECTRICAL RATINGS
PRESSURES
Locked Rotor
Discharge Amps Cool Amps Heat
Amps
281 7.1 36.2
281 6.9 36.2
293 9.0 45.0
297 12.4 58.0
297 12.4 58.0
289 4.6 26.0
305 6.9/6.5 27.4
305 6.9/6.5 27.4
315 7.7 35.0
315 7.7 35.0
289 4.6 15.2 45.0
289 4.6 15.2 45.0
305 6.9/6.5 15.7 27.4
305 6.9/6.5 15.7 27.4
305 6.9/6.5 15.7 27.4
315 6.5 16.1 35.0
315 6.5 16.1 35.0
315 6.5 16.1 35.0
225 4.6 4 / 15.2 26.0
225 4.6 4 / 15.2 26.0
225 4.6 4 / 15.2 26.0
300 6.5 5.6 / 15.7 27.4
300 6.5 5.6 / 15.7 27.4
300 6.5 5.6 / 15.7 27.4
Energy
E ciency Moisture
Ratio Removal
EER Pints/Hr.
10.5 1.3
10.5 2.4
9.5 3.3
10.0/10.0 2.1
8.9/8.7 3.3
9.0/8.8 4.2
10.0/10.0 2.1
8.9/8.7 3.3
9.0/8.8 4.2
10.0/10.0 2.5
9.0/9.0 3.2
BREAKER
R-22 REF.
FUSE
Evap Motor
CFM RPM
Charge in 60 Hertz
OZ. Amps
20.5 257 1100 15
18.9 257 1100 15
22.0 248 1100 15
44.9 293 1300 15
44.9 293 1300 15
22.5 235 1100 15
36.5 288 1280 15
36.5 288 1280 15
47.6 292 1421 15
47.6 292 1421 15
38.0 225 1074 20
38.0 225 1074 20
36.5 288 1280 20
36.5 288 1280 20
36.5 288 1280 20
35.2 281 1305 20
35.2 281 1305 20
35.2 281 1305 20
38.0 225 1074 20
38.0 225 1074 20
38.0 225 1074 20
35.0 260 1200 20
35.0 260 1200 20
35.0 260 1200 20
Room Weight
Side Air Lbs.
Circulation Ship/Net
Sleeve
245 WSC 97/93
245 WSC 107/103
295 WSC 116/112
260 WSC 105/101
280 WSC 113/109
290 WSC 123/119
260 WSC 107/103
280 WSC 115/111
290 WSC 125/121
230 WSC 111/107
280 WSC 120/116
