Gas & electric hot plates
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

Enlarged version
U S E R S I N S T R U C T I O N S
TROUBLE - SHOOTING GUIDE
ABNORMAL OPERATION
Any of the following are considered to be abnormal operation and
may require servicing:
Yellow tipping of the hob burner flame.
Shooting up of cooking utensils.
Burners not igniting properly.
Burners failing to remain alight.
Burners extinguished by cupboard doors.
Gas valves, which are difficult to turn.
In case the appliance fails to operate correctly, contact the
authorised service provider in your area.Burners extinguished by
cupboard doors.
Gas valves, which are difficult to turn.
In case the appliance fails to operate correctly, call the number
on the data label located on the front of this manual.
BEFORE YOU CALL FOR SERVICING
A review of the following may save you a service call and if not
it may help you explain the malfunction to the service person.
Read the operating instructions carefully. Be sure you know how
to opera the appliance.
If base of cooking utensils show signs of carbon (soot) deposit,
this could indicate an incorrect burner flame. Please contact local
service number (refer to the data label on the front of this instruciton
manual).
THE BURNER DOES NOT LIGHT
• Check to ensure Hotplate cord is plugged into outlet. Check for
16
a blown fuse or tripped circuit breaker.
• Hotplate not properly grounded or polarized. This can effect
ignition on spark ignition models.
• Check for power wattage.
• Gas supply not connected or not turned on.
• A pan is sitting on the burner grate. This may partially clock the
free air flow needed for combustion. Remove the pan and try
again.
• Burners not adjusted properly.
• Food clogging burners or burner assembly misaligned. Make
sure that burner ports on side of burner are not clogged. Make
sure that burners are positioned correctly.
WHEN YOU CALL FOR SERVICE
When you call for service or order parts for you Hotplate be sure
to give:
1. MODEL
2. SERIAL NUMBER
3. COLOUR
4. PART NAME and/or description of problem
5. YOUR FULL NAME, ADDRESS, and HOME TELEPHONE
NUMBER and BUSINESS TELEPHONE NUMBER IF
APPROPRIATE
6."FOR NUMBER SERVICE CONTACT" SEE DATA LABEL
LOCATED ON BASE OF THE APPLIANCE
Maintenance schedule:
To ensure the appliance continues to operate at peak performance,
we recommend a routine service call every 2 years for the life of
the appliance.
INSTALLATION AND USER INSTRUCTIONS
NOTE TO INSTALLER: LEAVE THE OWNER'S GUIDE MANUAL WITH THE APPLIANCE.
(Keep For Future Reference)
- AU -
