Failover System
The Boot and Diagnostic screens show two DSP Cores as DSP Core 1 and DSP Core 1A. The DSP core ID settings configure the des-
ignation. (See "General Settings" on page 9.) DSP Core 1 boots as the active core, DSP Core 1A is redundant. If DSP core 1A is not
detected during boot, the failover option will be disabled (grayed out) in the GUI.
The Failover switch (SH612) is controlled by the SC262 System Computer via a RS232-to-RS422 converter.
Failover System MADI connections
8
DF66 Guide
Console
System 5
Max Air
System PC Serial Port
COM 1
COM 3
