Heatiator NEVO4236I Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Model(s):
NEVO4236I
NEVO3630I
• Important operating and
maintenance instructions
included.
WARNING
If the information in these instruc-
tions is not followed exactly, a
fi re may result causing property
damage, personal injury, or death.
• Do not store or use gasoline or other fl am-
mable vapors and liquids in the vicinity of
this or any other appliance.
• What to do if you smell gas:
- Do not try to light any appliance.
- Do not touch any electrical switch. Do not
use any phone in your building.
- Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
- If you cannot reach your gas supplier, call
the fi re department.
• Installation and service must be performed
by a qualifi ed installer, service agency, or
the gas supplier.
This appliance may be installed as an OEM installation
in manufactured home (USA only) or mobile home and
must be installed in accordance with the manufacturer's
instructions and the manufactured home construction and
safety standard, Title 24 CFR, Part 3280 or Standard for
Installation in Mobile Homes, CAN/CSA Z240MH.
This appliance is only for use with the type(s) of gas
indicated on the rating plate.
CAUTION
DO NOT DISCARD THIS MANUAL
Read, understand and follow
•
these instructions for safe
installation and operation.
• CAREFULLY SUPERVISE children in same room as
appliance.
• A l e r t c h i l d r e n a n d a d u l t s t o h a z a r d s o f h i g h
temperatures.
High temperatures may ignite clothing or other
fl ammable materials.
• Keep clothing, furniture, draperies and other combustibles
away.
This appliance has been supplied with an integral
barrier to prevent direct contact with the fi xed glass
panel. Do NOT operate the appliance with the barrier
removed.
Contact your dealer or Hearth & Home Technologies if the
barrier is not present or help is needed to properly install one.
In the Commonwealth of Massachusetts installation must
be performed by a licensed plumber or gas fi tter;
See Table of Contents for location of additional
Commonwealth of Massachusetts requirements.
Heatilator • Evolution • 4065-114 Rev. o • 11/11
Owner's Manual
Installation and Operation
Leave this manual with
•
party responsible for
use and operation.
WARNING
HOT SURFACES!
Glass and other surfaces are hot during
operation and cool down.
Hot glass will cause burns.
• Do not touch glass until it is cooled
• NEVER allow children to touch glass
• Keep children away
Installation and service of this appliance should be performed
by qualified personnel. Hearth & Home Technologies
suggests NFI certified or factory-trained professionals, or
technicians supervised by an NFI certified professional.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NEVO4236I and is the answer not in the manual?

Questions and answers

Related Manuals for Heatiator NEVO4236I

Summary of Contents for Heatiator NEVO4236I

  • Page 1 Owner’s Manual Installation and Operation Model(s): NEVO4236I NEVO3630I CAUTION DO NOT DISCARD THIS MANUAL Read, understand and follow Leave this manual with • Important operating and • • these instructions for safe party responsible for maintenance instructions installation and operation.

  • Page 2: Congratulations

    Read this manual before installing or operating this appliance. Please retain this owner’s manual for future reference. A. Congratulations This owner’s manual should be retained for future reference. We suggest that you keep it with your other important Congratulations on selecting a Heatilator gas fi replace, an documents and product manuals.

  • Page 3: Table Of Contents

    Safety Alert Key: • DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury. • WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury. • CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury. •...
  • Page 4 14 Finishing A. Mantel and Wall Projections B. Facing Material 15 Appliance Setup A. Remove the Packaging B. Remove the Shipping Materials C. Removing Fixed Glass Assembly D. Remove Glass Media Package E. Clean the Appliance Accessories G. Place the Glass Media H.

  • Page 5: Limited Lifetime Warranty

    B. Limited Lifetime Warranty Hearth & Home Technologies Inc. LIMITED LIFETIME WARRANTY Hearth & Home Technologies Inc., on behalf of its hearth brands (”HHT”), extends the following warranty for HHT gas, wood, pellet, coal and electric hearth appliances that are purchased from an HHT authorized dealer. WARRANTY COVERAGE: HHT warrants to the original owner of the HHT appliance at the site of installation, and to any transferee taking ownership of the appliance at the site of installation within two years following the date of original purchase, that the HHT appliance...
  • Page 6 B. Limited Lifetime Warranty (continued) WARRANTY CONDITIONS: WARRANTY EXCLUSIONS: This warranty is void if: LIMITATIONS OF LIABILITY: 4021-645C 12-29-10 Page 2 of 2 Heatilator • Evolution • 4065-114 Rev. o • 11/11...

  • Page 7: Listing And Code Approvals

    Listing and Code Approvals A. Appliance Certifi cation C. BTU Specifi cations Novus NEVO3630I NEVO4236I MODELS: NEVO4236I, NEVO3630I Max/Min Input Rate (NG) 20,000/10,000 25,000/12,500 LABORATORY: Underwriters Laboratories, Inc. (UL) Orifi ce Size (NG) 0.083 0.089 / #43 TYPE: Vented Gas Fireplace Heaters...

  • Page 8: R E Q U I R E M E N T S F O R T H E C O M M O N W E A L T H O F Massachusetts

    Inspection Note: The following requirements reference various The state or local gas inspector of the side wall horizon- Massachusetts and national codes not contained in this tally vented gas fueled equipment shall not approve the document. installation unless, upon inspection, the inspector ob- serves carbon monoxide detectors and signage installed H.

  • Page 9: User Guide

    User Guide Operating Instructions A. Gas Fireplace Safety • Install a physical barrier such as: A decorative fi rescreen. WARNING Adjustable safety gate. • Install a switch lock or a wall/remote control with child HOT SURFACES! protection lockout feature. Glass and other surfaces are hot •...

  • Page 10: Fan Kit (Optional)

    C. Fan Kit (optional) F. Fixed Glass Assembly If desired, a fan kit may be added. Contact your dealer to See Section 15.D. order the correct fan kit. G. Remote Controls, Wall Controls and Wall D. Clear Space Switches Follow the instructions supplied with the control installed WARNING! DO NOT place combustible objects in front of to operate your fi...

  • Page 11: Ipi Battery Tray/Battery Installation

    H. IPI Battery Tray/Battery Installation • Locate the module selector switch. (See Figure 2.3). The IntelliFire Plus system has a battery backup option. • Set the module selector switch to the OFF position. Battery longevity and performance will be affected by the •...

  • Page 12: Lighting Instructions (Ipi)

    K. Lighting Instructions (IPI) • For normal use, activate/deactivate your fi replace with the wall switch or remote control. • The IPI system may be operated with four AA-cell batteries. When using batteries, unplug the power supply. To prolong battery life, remove them when using the power supply. •...

  • Page 13: After Fireplace Is Lit

    L. After Fireplace is Lit Initial Break-in Procedure • The fireplace should be run three to four hours continuously on high. • Turn the fi replace off and allow it to completely cool. • Remove fi xed glass assembly. See Section 15.D. •...

  • Page 14: Maintenance And Service

    Maintenance and Service Doors, Surrounds, Fronts Any safety screen or guard removed for servicing must be Frequency: Annually replaced prior to operating the fi replace. Homeowner When properly maintained, your fi replace will give you Tools needed: Protective gloves, stable work surface many years of trouble-free service.

  • Page 15: Maintenance Tasks-Qualifi Ed Service Technician

    B. Maintenance Tasks-Qualifi ed Service Burner Ignition and Operation Technician Frequency: Annually The following tasks must be performed by a qualifi ed Qualifi ed Service Technician service technician. Tools needed: Protective gloves, vacuum cleaner, whisk Gasket Seal and Glass Assembly Inspection broom, fl...

  • Page 16: Installer Guide

    Installer Guide Getting Started A. Typical Appliance System NOTICE: Illustrations and photos refl ect typical installations and are for design purposes only. Illustrations/diagrams are not drawn to scale. Actual product may vary from pictures in manual Note: Dual venting confi gurations ARE NOT allowed.

  • Page 17: Design And Installation Considerations

    B. Design and Installation Considerations D. Inspect Appliance and Components Heatilator direct vent gas appliances are designed to op- • Carefully remove the appliance and components from erate with all combustion air siphoned from outside of the the packaging. building and all exhaust gases expelled to the outside. No •...

  • Page 18: Framing And Clearances

    Framing and Clearances A. Select Appliance Location NOTICE: Illustrations refl ect typical installations and are FOR DESIGN PURPOSES ONLY. Illustrations/diagrams When selecting a location for the appliance it is important are not drawn to scale. Actual installation may vary due to to consider the required clearances to walls (see Figure individual design preference.

  • Page 19: Construct The Appliance Chase

    B. Construct the Appliance Chase Walls, ceiling, base plate and cantilever fl oor of the chase should be insulated. Vapor and air infi ltration barriers A chase is a vertical box-like structure built to enclose the should be installed in the chase as per regional codes for gas appliance and/or its vent system.

  • Page 20: Clearances

    C. Clearances • Insulation and other materials must be secured to NOTICE: Install appliance on hard metal or wood surfaces prevent accidental contact. extending full width and depth. DO NOT install directly on carpeting, vinyl, tile or any combustible material other than •...

  • Page 21: Mantel And Wall Projections

    D. Mantel and Wall Projections WARNING! Risk of Fire! Comply with all minimum clearances to combustibles as specifi ed. Framing or fi nishing material clos- er than the minimums listed must be constructed entirely of non-combustible materials (i.e., steel studs, concrete board, etc). Mantels Note: All measurements...

  • Page 22: Termination Locations

    Termination Locations A. Vent Termination Minimum Clearances WARNING 6 in. (minimum) up to 20 in. 18 in. minimum Fire Risk. 152 mm/508 mm 457 mm Maintain vent clearance to combustibles as 20 in. and over 0 in. minimum specifi ed. Gas, Wood or Fuel Oil •...
  • Page 23 Fixed Openable Fixed Closed Closed GAS METER V TERMINATION CAP AIR SUPPLY INLET RESTRICTION ZONE (TERMINATION NOT ALLOWED) Measure vertical clearances from this surface Electrical Service Covered Alcove Measure horizontal clearances Clearances to Electrical Service Applications from this surface. Dimension Descriptions P 6”...

  • Page 24: Vent Information And Diagrams

    Vent Information and Diagrams A. Approved Pipe This appliance is approved for use with Hearth & Home Technologies DVP and/or SLP venting systems. Refer to Section 17.B. for vent component information. Vertical DO NOT mix pipe, fi ttings or joining methods from differ- ent manufacturers.

  • Page 25: Vent Diagrams

    E. Vent Diagrams Note: The NEVO series appliances can adapt to SLP series vent pipe when venting off the top of To replace the fi rst starter elbow with two 45° elbows, the appliance. You must use a DVP-SLP24 adapter refer to Figure 7.4.
  • Page 26 1. Top Vent - Horizontal Termination - (continued) Two 45° Elbows replacing One 90° Elbow 4 ft min. (1.22 m) 20 ft max. (6.10 m) Figure 7.4 min. max. max. H max. Two Elbows 0.46 1.83 0.61 3.35 3.35 0.76 5.49 5.49 0.91...
  • Page 27 1. Top Vent - Horizontal Termination - (continued) min. max. max. Three Elbows 0.61 7.32 5.79 0.61 6.71 5.79 Installed Vertically Figure 7.6 2. Top Vent - Vertical Termination No Elbow 12 ft (3.66 m) min. 60 ft (18.29 m) max. Figure 7.7 Heatilator •...
  • Page 28 Install Top Vent Flue Baffl e - No Elbow Confi gu- rations • Remove screws holding fl ue visor to fi rebox top. See Figure 7.7a. • Remove the fl ue visor. • Using the screws removed and the same holes, install the top vent fl...

  • Page 29: Three Elbows

    2. Top Vent - Vertical Termination - (continued) Three Elbows Maximum horizontal run is 100% of vertical, but cannot exceed 17 ft (5.18 m) 12 ft (3.66 m) min. 60 ft (18.29 m) max. Figure 7.8 Heatilator • Evolution • 4065-114 Rev. o • 11/11...
  • Page 30 2. Top Vent - Vertical Termination - (continued) Two Elbows 12 ft (3.66 m) min. 60 ft (18.29 m) max. Maximum horizontal run is 100% of vertical, but cannot exceed 17 ft (5.18 m) Figure 7.9 Heatilator • Evolution • 4065-114 Rev. o • 11/11...
  • Page 31 3. Rear Vent - Horizontal Termination No Elbow 18 in. (457 mm) max. Figure 7.10 One 45° Elbow NOTICE: To ensure proper operation of appliance, remove the pilot shield when the venting confi guration includes a single 45° elbow and horizontal termination. 18 in.

  • Page 32: H 1 +H

    3. Rear Vent - Horizontal Termination - (continued) max. min. max. Two Elbows 0.30 0.91 0.61 0.30 0.91 1.22 0.61 1.83 1.83 0.91 2.74 2.44 1.22 3.66 2.44 1.52 4.57 2.44 1.83 5.49 Figure 7.12 max. min. max. Three Elbows 0.30 0.91 0.61...

  • Page 33: Ft (3.66 M) Min

    4. Rear Vent - Vertical Termination One Elbow 0 min. 6 ft (1.83 m) max. 12 ft (3.66 m) min. 60 ft (18.29 m) max. Figure 7.14 Two Elbows 0 min. 12 ft (3.66 m) min. 6 ft (1.83 m) max. 60 ft (18.29 m) max.
  • Page 34 4. Rear Vent - Vertical Termination - (continued) Three Elbows 0 min. 6 ft (1.83 m) max. 12 ft (3.66 m) min. 60 ft (18.29 m) max. Maximum horizontal run is 100% of vertical, but can- not exceed 18 ft (5.49 m) Figure 7.16 Heatilator •...

  • Page 35: Vent Clearances And Framing

    Vent Clearances and Framing A. Pipe Clearances to Combustibles B. Wall Penetration Framing WARNING! Risk of Fire! Maintain air space clearance to Combustible Wall Penetration vent. DO NOT pack insulation or other combustibles: Whenever a combustible wall is penetrated, you must frame a hole for the wall shield fi...

  • Page 36: Install The Ceiling Firestop

    C. Install the Ceiling Firestop A ceiling fi restop MUST be used between fl oors and attics. • DVP pipe only - Frame an opening 10 in. by 10 in. (254 mm by 254 mm) whenever the vent penetrates a ceiling/fl oor (see ATTIC ABOVE Figure 8.3).

  • Page 37: Install Attic Insulation Shield

    D. Install Attic Insulation Shield WARNING! Fire Risk. DO NOT allow loose materials or insulation to touch vent. Hearth & Home Technologies Inc. requires the use of an attic shield. The National Fuel Gas Code ANSI Z223.1 and NFPA 54 requires an attic shield constructed of 26 gauge minimum metal that extends at least 2 in.

  • Page 38: Appliance Preparation

    Appliance Preparation A. Top Vent • Fold the center parts of the retaining band up and use to remove the vent cap. CAUTION! Risk of Cuts, Abrasions or Flying Debris. Wear protective gloves and safety glasses during installa- tion. Sheet metal edges are sharp. NOTICE: Once appliance is set up for top or rear venting, it CANNOT be changed at a later time.

  • Page 39: Rear Vent

    B. Rear Vent NOTICE: Once appliance is set up for top or rear venting, • Discard the vent cap, remove and discard the insulation it CANNOT be changed at a later time. basket. • Fold the tabs toward the center of the vent cap (90º) and remove the insulation gasket.

  • Page 40: Secure And Level The Appliance

    C. Secure and Level the Appliance WARNING! Risk of Fire! Prevent contact with: • Sagging or loose insulation • Insulation backing or plastic • Framing and other combustible materials Block openings into the chase to prevent entry of blown-in insulation. Make sure insulation and other materials are secured.

  • Page 41: Install Vent Pipe

    Install Vent Pipe A. Assemble Vent Sections (DVP Only) Attach Pipe to the Firebox Assembly Note: The end of the pipe sections with the lanced tabs will face towards the appliance. Attach the fi rst pipe section to the starting collar: •...

  • Page 42: Assemble Vent Sections (Slp Only)

    B. Assemble Vent Sections (SLP Only) C. Assemble Slip Sections To attach the fi rst vent component to the starting collars WARNING! Risk of Fire or Asphyxiation! Overlap pipe of the appliance sections at least 1 1/2 in. (38 mm). Secure slip sections •...

  • Page 43: Secure The Vent Sections

    D. Secure the Vent Sections E. Disassemble Vent Sections • Vertical runs of DVP pipe must be supported every 8 ft. • Rotate either section (see Figure 10.10) so the seams (2.44 m) after the 25 ft. (7.62 m) maximum unsupported on both pipe sections are aligned as shown in Figure rise.

  • Page 44: Install Decorative Ceiling Components (Slp Only)

    F. Install Decorative Ceiling Components (SLP only) Level A decorative ceiling thimble can be installed on a fl at ceil- ing through which the vent passes. The decorative ceiling Cathedral ceiling thimble is used to cover the fi restop. support box •...

  • Page 45: Install Metal Roof Flashing

    G. Install Metal Roof Flashing H. Assemble and Install Storm Collar • See minimum vent heights for various pitched roofs CAUTION! Risk of Cuts, Abrasions or Flying Debris. (Figure 10.14) to determine the length of pipe to extend Wear protective gloves and safety glasses during installa- through the roof.

  • Page 46: Install Vertical Termination Cap

    I. Install Vertical Termination Cap J. Heat Shield Requirements for Horizontal Termination • Attach the vertical termination cap by sliding the inner collar of the cap into the inner fl ue of the pipe section WARNING! Risk of Fire! To prevent overheating and fi re, while placing the outer collar of the cap over the outer heat shields must extend through the entire wall thick- fl...

  • Page 47: Install Horizontal Termination Cap

    K. Install Horizontal Termination Cap • When installing a horizontal termination cap, follow the cap location guidelines as prescribed by current WARNING! Risk of Fire! The telescoping fl ue section ANSI Z223.1 and CAN/CGA-B149 installation codes of the termination cap MUST be used when connecting and refer to Section 6 of this manual.

  • Page 48: Shrouds

    11 11 Shrouds A. HHT Shrouds • You may install a shroud with this fi replace. See Section 17.D. for a list of UL Listed shrouds. Follow the instructions included with these optional components B. Field Constructed Shrouds WARNING! Risk of Fire! Shrouds must be constructed as specifi...
  • Page 49 Mailbox Style Shroud (may be used with DVP-TV, DVP-TVHW, SLP-TVHW) Min. Base Dims. Min. Height 20 x 20 508 x 508 Min. Height Min. Base Dim Min. Base Dim Figure 11.2 Mailbox Style Shroud Dimensions Roofed Style Shroud (may be used with DVP-TV, DVP-TVHW, SLP-TVHW) Min.

  • Page 50: Gas Information

    Gas Information A. Fuel Conversion C. Gas Connection • Make sure the appliance is compatible with available • Refer to Reference Section 17.A. for location of gas line gas types. access in appliance. • Conversions must be made by a qualified service •...

  • Page 51: Electrical Information

    Electrical Information C. Optional Accessories Requirements A. Wiring Requirements • This appliance may be used with a wall switch, wall NOTICE: This appliance must be electrically wired mounted thermostat and/or a remote control. and grounded in accordance with local codes or, in the •...

  • Page 52: Electrical Service And Repair

    D. Electrical Service and Repair WARNING! Risk of Shock! Replace damaged wire with type 105° C rated wire. Wire must have high temperature WARNING! Risk of Shock! Label all wires prior to insulation. disconnection when servicing controls. Wiring errors can cause improper and dangerous operation.

  • Page 53: Junction Box Installation

    E. Junction Box Installation If the box is being wired from the OUTSIDE of the appli- Romex ance: Connector • Remove the cover plate located on the outer shell - right side (see Figure 13.2). 14/2WG • Install the supplied Romex™ connector in the cover plate.

  • Page 54: Finishing

    Finishing A. Mantel and Wall Projections WARNING! Risk of Fire! Comply with all minimum clear- ances to combustibles as specifi ed. Framing or fi nishing material closer than the minimums listed must be construct- ed entirely of non-combustible materials (i.e., steel studs, concrete board, etc).

  • Page 55: Facing Material

    B. Facing Material • Metal front faces may be covered with non-combustible Finish wall material may be materials only. combustible - Top and Sides • Facing and/or fi nishing materials must not interfere with air fl ow through louvers, operation of louvers or doors, or access for service.

  • Page 56: Appliance Setup

    Appliance Setup A. Remove the Packaging • Pull the four glass assembly latches out of the groove on the glass frame. Refer to Figure 15.2. Remove the shrink fi lm, corrugated top cap, bottom cap • Remove the glass assembly from the appliance. and column protectors from the appliance.

  • Page 57: Place The Glass Media

    G. Place the Glass Media • Open the bag of glass media and place on the burner/ hearth pan area. WARNING! Risk of Explosion! Follow glass media • Spread the glass media over the entire area. Make sure placement instructions. glass media is only one layer thick on top of the •...

  • Page 58: Replacing Fixed Glass Assembly

    H. Replacing Fixed Glass Assembly I. Air Shutter Setting • Set the glass panel on the lower two or four glass Air shutter setting should be adjusted by a qualifi ed in- assembly latches, ensuring the glass panel is centered staller at the time of installation.

  • Page 59: Troubleshooting

    Troubleshooting With proper installation, operation, and maintenance your gas appliance will provide years of trouble-free service. If you do experience a problem, this troubleshooting guide will assist a qualifi ed service technician in the diagnosis of a problem and the corrective action to be taken. This troubleshooting guide can only be used by a qualifi ed service technician. Con- tact your dealer to arrange a service call by a qualifi...
  • Page 60 Intellifi re Ignition System - (continued) Symptom Possible Cause Corrective Action 4. Pilot sparks, but Pilot will A. Gas supply. Verify that incoming gas line shutoff valve is “open”. Verify that inlet not light. pressure reading is within acceptable limits. B.

  • Page 61: Reference Materials

    17 17 Reference Materials A. Appliance Dimension Diagram Dimensions are actual appliance dimensions. Use for reference only. For framing dimensions and clearances refer to Section 5. Model NEVO3630 8 5/8 19 1/8 in. (486 mm) NEVO4236 14 5/8 1041 11 5/8 in. (295 mm) 31 1/2 in.

  • Page 62: Vent Components Diagrams

    B. Vent Components Diagrams Effective Height/Length 4-7/8 in. Pipe inches (124 mm) DVP4 10-1/2 in. DVP6 45° (267 mm) Effective DVP12 Height/Length DVP24 DVP36 DVP48 1219 DVP6A 3 - 6 76 - 152 10-7/8 in. DVP12A 3 - 12 76 - 305 (276 mm) DVP45 DVP Pipe...
  • Page 63 B. Vent Components Diagrams (continued) 31 in. (787 mm) 24-5/8 in. 13-1/4 in. (625 mm) (367 mm) 27-1/2 in. 24-5/8 in. 13-1/4 in. (698 mm) (625 mm) (367 mm) RF12M RF6M Roof Flashing Multi-pak Roof Flashing Multi-pak 13-3/4 in. 5 in. 11-7/8 in.
  • Page 64 B. Vent Components Diagrams (continued) 7-3/8 in. (187 mm) 1-1/2 in. 9 in. (38 mm) 12-1/2 in. (229 mm) 2-3/4 in. (317 mm) (70 mm) 11-1/2 in. 17-3/4 in. (280 mm) 14 in. (451 mm) (356 mm) 12-1/4 in. (311 mm) 16 in.
  • Page 65 B. Vent Components Diagrams (continued) Note: Heat shields MUST overlap by a minimum of 1-1/2 in. (38 mm). The heat shield is designed to be used on a wall 4 in. to 7-1/4 in. (102 mm to 184 mm) thick. If wall thickness is less than 4 in. (102 mm) the existing heat shields must be field trimmed.
  • Page 66 B. Vent Components Diagrams (continued) Fillers DVP-TRAP to DVP-HPC Side Filler Kit 8-1/8 in. 13 in. (206 mm) (330 mm) 15 in. (381 mm) DVP-HRC-SS Effective Length 5-1/2 in. 8-3/8 in. 5-3/4 to 8-3/8 in. 140 mm 213 mm 146 to 213 mm 3°...
  • Page 67 B. Vent Components Diagrams (continued) 6-1/2 in. 165 mm 6-1/2 in. 165 mm 6-1/2 in. 165 mm 8-3/4 in. 9-1/4 in. 222 mm 6 in. 235 mm 152 mm 6-5/8 in. 168 mm 6-5/8 in. SLP-45 - 45° Elbow 168 mm 9-7/8 in.
  • Page 68 B. Vent Components Diagrams (continued) 9 in. 12-1/2 in. (229 mm) 2-3/4 in. (317 mm) (70 mm) 11-1/2 in. (280 mm) 12-1/4 in. (311 mm) 16 in. (406 mm) PVK-80 SLK-SNKD SLP-CCS-BK (For use with IPI and DSI appliances only.) Snorkel Cathedral Ceiling Sup- Termination Cap...
  • Page 69 B. Vent Components Diagrams (continued) Optional Wire Harness 13-5/8 IN. DESCRIPTION PART NUMBER 346 mm EFFECTIVE LENGTH 32 IN. (813 mm) MIN. 10 ft. PV Wire Harness PVI-WH10 35 IN. (889 mm) MAX. 20 ft. PV Wire Harness PVI-WH20 40 ft. PV Wire Harness PVI-WH40 12-1/2 IN.

  • Page 70: Service Parts

    C. Service Parts NEVO3630i Novus Evolution IPI Appliance Beginning Manufacturing Date: Sept 2009 Ending Manufacturing Date:______ IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement parts for your appliance please provide model number and serial number. All parts listed in this manual may Stocked be ordered from an authorized dealer.
  • Page 71 NEVO4236i C. Service Parts Beginning Manufacutring Date: Sept 2009 Novus Evolution IPI Appliance Ending Manufacturing Date: ______ IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement parts for Stocked your appliance please provide model number and serial number. All parts listed in this manual may be ordered from an authorized dealer.
  • Page 72 NEVO3630I Orifi ce LP (.053) 4021-426 Orifi ce NG (#43C) 582-843 NEVO4236I Orifi ce LP (#54C) 582-854 **Fuse for battery pack can be sourced locally, not a warranty item. Specs are 500mA~10A 3/4” long Additional Service Parts on following page.
  • Page 73 Conversion Kit LP DCKVP-NEVO3630 Pilot Orifi ce NG 593-528 Pilot Orifi ce LP 593-527 Regulator NG NGK-DXV-50 Regulator LP LPK-DXV-50 NEVO4236I Conversion Kit NG Conversion Kit LP DCKVP-NEVO3630 Pilot Orifi ce NG 593-528 Pilot Orifi ce LP 593-527 Regulator NG NGK-DXV-50...

  • Page 74: Optional Components

    Description Model # Description NEVO3630I Top/rear direct vent, natural gas, Intellifi re NEVO4236I Top/rear direct vent, natural gas, Intellifi re Plus™ ignition system, 30 in. framing width, Plus™ ignition system, 42 in. framing width, 30 in. viewing glass 30 in. viewing glass...

  • Page 75: Contact Information

    E. Contact Information Please contact your Heatilator dealer with any questions or concerns. For the location of your nearest Heatilator dealer, please visit www.heatilator.com. Heatilator, a brand of Hearth & Home Technologies Inc. 7571 215 Street West, Lakeville, MN 55044 www.heatilator.com - NOTES - ________________________________________________________________________________...

This manual is also suitable for:

Nevo3630i

Table of Contents
