Harman TL2.0 Owner's Manual

Harman TL2.0 Owner's Manual

Non-catalytic, top load, wood burning room heater
Hide thumbs Also See for TL2.0:
Table of Contents

Advertisement

Quick Links

Owner's Manual
Installation and Operation
Model:
TL2.0
Non-Catalytic, Top Load,
Wood Burning Room Heater
Item #1-90-856000
•
Important operating and
maintenance instructions
included.
WaRNINg
PLEasE REad THIs ENTIRE MaNuaL
BEfORE INsTaLLaTION aNd usE Of
THIs WOOd-BuRNINg ROOM HEaTER.
faILuRE TO fOLLOW THEsE
INsTRuCTIONs COuLd REsuLT IN
PROPERTy daMagE, BOdILy INjuRy
OR EvEN dEaTH.
•
dO NOT sTORE OR usE gasOLINE OR OTHER
fLaMMaBLE vaPORs aNd LIquIds IN THE
vICINITy Of THIs OR aNy OTHER aPPLIaNCE.
• Do not overfire - if any external part
sTaRTs TO gLOW, yOu aRE OvERfIRINg.
CLOsE aIR CONTROLs. OvERfIRINg WILL
vOId yOuR WaRRaNTy.
• Comply with all minimum ClearanCes to
COMBusTIBLEs as sPECIfIEd. faILuRE TO
COMPLy May CausE a HOusE fIRE.
CauTION
TEsTEd aNd aPPROvEd fOR usE WITH dRy,
sEasONEd CORdWOOd ONLy. dO NOT BuRN
WET OR gREEN WOOd. BuRNINg aNy OTHER
TyPE Of fuEL WILL vOId yOuR WaRRaNTy.
Save These Instructions
NOTICE
dO NOT dIsCaRd THIs MaNuaL
•
Read, understand and
follow these instructions
for safe installation and
operation.
HOT, WILL CausE BuRNs.
• Do not touCh glass until it is CooleD
• never allow ChilDren to touCh glass
• Keep ChilDren away
• Carefully supervise ChilDren in same
• alert ChilDren anD aDults to hazarDs of
• Keep Clothing, furniture, Draperies anD
CHECk BuILdINg COdEs PRIOR TO INsTaLLaTION.
•
• Consult loCal builDing, fire offiCials or
3-90-08560
•
Leave this manual with
party responsible for use
and operation.
WaRNINg
HOT suRfaCEs!
gLass aNd OTHER suRfaCEs
aRE HOT duRINg OPERaTION
aNd COOL dOWN.
ROOM as fIREPLaCE.
HIgH TEMPERaTuREs.
HIgH TEMPERaTuREs May IgNITE CLOTHINg OR
OTHER fLaMMaBLE MaTERIaLs.
OTHER fLaMMaBLE MaTERIaLs aWay.
CauTION
INsTaLLaTION MusT COMPLy WITH LOCaL, REgIONaL,
sTaTE aNd NaTIONaL COdEs aNd REguLaTIONs.
auTHORITIEs HavINg juRIsdICTION aBOuT REsTRICTIONs,
INsTaLLaTION INsPECTION, aNd PERMITs.
Rev: 7
March, 2013

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TL2.0 and is the answer not in the manual?

Questions and answers

Related Manuals for Harman TL2.0

Summary of Contents for Harman TL2.0

  • Page 1 Owner's Manual Installation and Operation Model: TL2.0 Non-Catalytic, Top Load, Wood Burning Room Heater Item #1-90-856000 NOTICE dO NOT dIsCaRd THIs MaNuaL • • • Leave this manual with Important operating and Read, understand and party responsible for use maintenance instructions follow these instructions and operation.

  • Page 2: Tl2.0 Woodburning Stove

    With it's compact, steel-body construction, the TL2.0 features a heating capacity of 1600 to 1900 ft². The TL2.0 takes advantage of Harman’s 30+ years of stove design, technology and manufacturing. The Firedome Plus secondary combustion system provides for super-clean burning and minimal maintenance.

  • Page 3: Table Of Contents

    TL2.0 Woodburning Stove TaBLE Of CONTENTs section 1: Listing and Code approvals section 9: service & Maintenance A. Appliance Certifications A. Soot Formation (Removal) B. Mobile Home Approval B. General Maintenance Procedures C. Glass Specifications D. Electrical Rating section 10: Reference Materials E.

  • Page 4: Section 1: Listing And Code Approvals

    TL2.0 Woodburning Stove Listing and Code approvals a. appliance Certification e. btu & efficiency specifications Model: TL2.0 Woodburning Stove Particulate Emissions 2.6g/hr Avg Laboratory: OMNI-Test Laboratories, Inc. Rating: Report No. 135-S-29-2 *BTU Input: 9,600 - 31,800 / hr Type: Solid Fuel Room Heater / Wood Heating Capacity: 1,600-1,900 sq.

  • Page 5: Section 2: Special Warnings And Notes

    TL2.0 Woodburning Stove special Warnings and Notes Carbon monoxide, referred to as CO, is a colorless, CO detectors are very sensitive and may sound an alarm odorless gas that is produced during combustion of wood for fumes other than CO or CO from sources other than and other fuels.

  • Page 6: Considerations

    TL2.0 Woodburning Stove getting started a. design, Installation & Location B. fire safety Considerations Maintain the designated clearances to combustibles. Insulation must not touch the chimney. You must 1. appliance Location maintain the designated air space around the chim- Consideration must be given to safety, convenience, ney.

  • Page 7: Component Locator

    TL2.0 Woodburning Stove C. Component Locations Top Load Door Top Load Opening Bypass Damper Control Handle Front Load Door Bolt-Down Holes for Mobile Home Installations Air Control Ash Door Front Load Door Latch Ash Door Latch Save These Instructions Dry Seasoned Wood Only!

  • Page 8: Pre-Use Checklist

    TL2.0 Woodburning Stove d. Pre- use Check List WaRNINg Place the appliance in a location near the INsPECT aPPLIaNCE aNd COMPONENTs fOR daMagE. daMagEd PaRTs May final installation and follow the procedures IMPaIR safE OPERaTION. below: • dO NOT INsTaLL daMagEd COMPO- Open the appliance and remove all articles NENTs.

  • Page 9: Section 4: Dimensions & Clearances

    26.0" (660mm) 18.4" (467mm) Weight..........452 lbs Flue Size........6 inch The Harman TL2.0 meets the U.S. Environmental Protection Agency’s Log Length Recommended... 18" emission limits for wood heaters sold after July 1, 1990. Average Emissions.......2.6 Grams Per Hr. Outside Air size......4.5 inch I.D.

  • Page 10: Clearances To Combustibles

    TL2.0 Woodburning Stove b. Clearances to Combustibles vertical venting Configuration Location single-wall Pipe Double-wall pipe unit to side Wall 14" / 356 mm 14" / 356 mm unit to Back Wall 13" / 330 mm 7" / 178 mm vent Pipe to side Wall 24" / 610 mm 24"...
  • Page 11 TL2.0 Woodburning Stove vertical venting Configuration - horizontal exit Location single-wall Pipe unit to side Wall 13" / 330 mm unit to Back Wall 13" / 330 mm vent Pipe to side Wall 23" / 584 mm vent Pipe to Back Wall 18" / 457 mm vent Pipe to Ceiling 16"...

  • Page 12: Floor Protection

    TL2.0 Woodburning Stove C. floor Protection Requirements Minimum Size floor protection (USA) is 48" Deep By 32.5" Wide. floor Protection Inches Millimeters Requirements Sides- USA /CANADA * Front- USA /CANADA * Rear- USA Rear- CANADA Wall Wall * Floor protection dimensions for the front and sides are measured from the appliance door opening in The United States.

  • Page 13: Section 5: Chimneys And Venting

    It must be placement of your venting system. The Harman TL2.0 may be installed with a minimum cemented in place with refractory cement. This method (.6 mm) 24 gauge blue or black steel, chimney connector is illustrated on the next page.

  • Page 14: The Chimney

    TL2.0 Woodburning Stove Closest Non-combustible cover, one Combustible Minimum 2" (50mm) side only. If two covers are Material Clearance to Brick used, each must be mounted Hole with a minimum on non-combustible spacers clearance of 18" (450 mm) Minimum 12"...
  • Page 15 TL2.0 Woodburning Stove 1. existing masonry Chimneys If you plan on using a pre-existing masonry chimney, have it thoroughly inspected and cleaned. Any faults which make the chimney unsafe and unusable must be repaired prior to use. These can include improper height, structural defects, blockages, inadequate clearance to...

  • Page 16: Chimney Connector

    TL2.0 Woodburning Stove standard Ceiling Installation with factory Built Chimney Chimney Cap Chimney storm Collar sections Roof flashing Roof Radiation shield attic Radiation shield Minimum air space Chimney with Chimney support Listing Chimney Connector The Chimney Connector shall Not Pass Through an attic or Roof space, Closet or similar Concealed space, a floor or Ceiling.
  • Page 17 TL2.0 Woodburning Stove Cathedral Ceiling Installation with factory Built Chimney Chimney Cap Roof Radiation Factory-Built Shield Metal Chimney Sealed Storm Collar Roof Flashing Cathedral Style Chimney Support Finishing Collar Chimney Connector Save These Instructions Dry Seasoned Wood Only! 3-90-08560...
  • Page 18 TL2.0 Woodburning Stove Chimney breach fireplace Conversion with non-Combustible wall Minimum Clearance to unprotected Ceil- ing 16" Chimney Connector sealed at thimble flue Liner with Re- quired air space Three sheet Metal screws per joint of airtight Chimney Connector insulated Clean-out Mantel and Trim Pro- tection damper Closed and...
  • Page 19 TL2.0 Woodburning Stove Chimney Breach Fireplace Conversion with Combustible Wall Minimum Clearance from Chimney Connector to Un- protected Ceiling 16"** Flue Liner with Required Air Space Listed or Approved Thimble Assembly Combustible 1" Clearance for Complex- Wall ity Exterior Chimney 2"...

  • Page 20: Mobile Home Installation

    TL2.0 Woodburning Stove mobile home a. mobile home installation NOTE: The top sections of the chimney must be removable to allow a maximum clearance of 13.5 feet mobile home approval - u.s. only. (411cm) from ground level for transportation purposes. dO NOT INsTaLL IN a MOBILE HOME IN CaNada.

  • Page 21: Section 7: Appliance Set-Up

    TL2.0 Woodburning Stove appliance set-up a. Outside air attachment B. Leveling the appliance Parts and Supplies Needed: Kit #1-10-856082, 1 Use metal shim material under the pedestal base piece of metal flexible pipe, 4" X needed length. 1 where needed for leveling.

  • Page 22: Optional Blower Kit

    ONLy Blower Part #1-00-856002 With This appliance. The optional blower kit installs easily to the rear of the TL2.0. First, remove the air jacket shield from the rear of the stove. Use the same four bolts to attach the blower as shown.

  • Page 23: Section 8: Operating Instructions

    TL2.0 Woodburning Stove Operating Instructions B. general Operating Information CauTION: approved for use with wood fuel only. The use of any other fuel will void the product 1. draft Before you install and/or operate your warranty and may cause damage to the appliance wood stove, please read the entire contents of this and/or your home.

  • Page 24: Burning As A Fireplace

    TL2.0 Woodburning Stove D. the Combustion process 3. grates The unique grate system consists of one flat bottom Combustion in the firebox is precisely controlled and grate, and two front andirons. The bottom grate has is best explained in two parts. slots which allow the ash to fall into the ash pan by During a wood fire, combustion air enters at the bottom passing a poker back and forth across the grate.

  • Page 25: User Controls

    TL2.0 Woodburning Stove E. user Controls For low burn, slide the air control to the left. For medium burns, use notches 1 to 2. Maximum heat is Two important controls - the damper bypass handle attained with the air control all the way to the right. Do and the air control lever regulate the operation and not burn the stove continuously at the maximum setting.
  • Page 26 The TL2.0 is designed to provide access to the ash glow red. If you notice signs of overfiring, reduce the air pan without the need for opening the main door.

  • Page 27: Section 9: Service & Maintenance

    TL2.0 Woodburning Stove solid fuel burning spave heaters must be cleaned regularly, service & Maintenance as soot, ash and creosote may accumulate. seasonal cleaning Creosote- formation and Need for Removal; At least once per year, the stove, venting connectors When wood is burned slowly, it produces tar and other and chimney should be thoroughly cleaned.

  • Page 28: General Maintenance Procedures

    TL2.0 Woodburning Stove B. general Maintenance Procedures 2. door glass • frequency: As needed / Weekly 1. ash Removal • By: User • frequency: As needed / Every day or two • By: User Whenever the view of the fire is obstructed, or weekly, clean the glass using a soft cloth dampened with standard household glass cleaner.
  • Page 29 TL2.0 Woodburning Stove 3. firebox 5. Chimney Connector • frequency: As necessary / Yearly • frequency: As necessary / Yearly • By: User • By: Qualified Service Technician / User Cleaning the firebox and internal heat exchange surfaces is recommended to maintain thermal At the end of the burn season, brush and clean all efficiency.

  • Page 30: Section 10: Reference Materials

    TL2.0 Woodburning Stove Reference Materials Dry Seasoned Wood Only! 3-90-08560 Save These Instructions...

  • Page 31: Service Parts Listing

    TL2.0 service Parts Beginning Manufacturing date: sept 2011 Wood stove Ending Manufacturing date: active 1-90-856000-1 Black W/Pedestal part number list on following page. 02/13...
  • Page 32 TL2.0 service Parts Beginning Manufacturing date: sept 2011 Ending Manufacturing date: active IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement stocked parts for your appliance please provide model number and serial number. All parts listed in this manual may be ordered from an authorized dealer.
  • Page 33 TL2.0 service Parts Beginning Manufacturing date: sept 2011 Ending Manufacturing date: active IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement stocked parts for your appliance please provide model number and serial number. All parts listed in this manual may be ordered from an authorized dealer.

  • Page 34: Epa Hang Tag

    TL2.0 service Parts Beginning Manufacturing date: sept 2011 Ending Manufacturing date: active IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement stocked parts for your appliance please provide model number and serial number. All parts listed in this manual may be ordered from an authorized dealer.

  • Page 35: Warranty Policy

    Manufactured by: HeartH & HoMe tecHnologies, inc. Model: tl2.0 u.s. enviroMental Protection agency Meets EPA particulate matter (smoke) control requirements for noncatalytic wood heaters built on or after July 1, 1990. sMoKe grams Per Hour efficiency 100% Wood heaters with higher efficiencies cost less to operate.
  • Page 36 Hearth & Home Technologies LIMITEd LIfETIME WaRRaNTy Hearth & Home Technologies, on behalf of its hearth brands (”HHT”), extends the following warranty for HHT gas, wood, pellet, coal and electric hearth appliances that are purchased from an HHT authorized dealer. WaRRaNTy COvERagE: HHT warrants to the original owner of the HHT appliance at the site of installation, and to any transferee taking ownership of the appliance at the site of installation within two years following the date of original purchase, that the HHT appliance...
  • Page 37 WaRRaNTy CONdITIONs: • This warranty only covers HHT appliances that are purchased through an HHT authorized dealer or distributor. A list of HHT authorized dealers is available on the HHT branded websites. • This warranty is only valid while the HHT appliance remains at the site of original installation. •...
  • Page 38 TL2.0 Woodburning Stove service & Maintenance Log Date Of Service Performed By Description Of Service Save These Instructions Dry Seasoned Wood Only! 3-90-08560...
