Non-catalytic, top load, wood burning room heater

Advertisement

Owner's Manual
Installation and Operation
Model:
Oakleaf
Non-Catalytic, Top Load,
Wood Burning Room Heater
Item #1-90-797000
Important operating and
maintenance instructions
included.
pLEasE REad THIs ENTIRE MaNuaL
BEfORE INsTaLLaTION aNd usE Of
THIs WOOd-BuRNINg ROOM HEaTER.
f a I L u R E T O f O L L O W T H E s E
INsTRuCTIONs COuLd REsuLT IN
pROpERTy daMagE, BOdILy INjuRy
OR EvEN dEaTH.
dO NOT sTORE OR usE gasOLINE OR OTHER
fLaMMaBLE vapORs aNd LIquIds IN THE
vICINITy Of THIs OR aNy OTHER appLIaNCE.
• dO NOT OvERfIRE - If aNy ExTERNaL paRT
sTaRTs TO gLOW, yOu aRE OvERfIRINg. CLOsE
aIR CONTROLs. OvERfIRINg WILL vOId yOuR
WaRRaNTy.
• COMpLy WITH aLL MINIMuM CLEaRaNCEs TO
COMBusTIBLEs as spECIfIEd. faILuRE TO
COMpLy May CausE a HOusE fIRE.
CauTION
TEsTEd aNd appROvEd fOR usE WITH dRy,
sEasONEd CORdWOOd ONLy. dO NOT BuRN WET
OR gREEN WOOd. BuRNINg aNy OTHER TypE Of
fuEL WILL vOId yOuR WaRRaNTy.
www.harmanstoves.com
dO NOT dIsCaRd THIs MaNuaL
WaRNINg
NOTICE
Read, understand and
follow these instructions
for safe installation and
operation.
HOT, WILL CausE BuRNs.
dO NOT TOuCH gLass uNTIL IT Is COOLEd
NEvER aLLOW CHILdREN TO TOuCH gLass
kEEp CHILdREN aWay
CaREfuLLy supERvIsE CHILdREN IN saME
ROOM as fIREpLaCE.
aLERT CHILdREN aNd aduLTs TO HazaRds Of
HIgH TEMpERaTuREs.
HIgH TEMpERaTuREs May IgNITE CLOTHINg
OR OTHER fLaMMaBLE MaTERIaLs.
kEEp CLOTHINg, fuRNITuRE, dRapERIEs aNd
OTHER fLaMMaBLE MaTERIaLs aWay.
CHECk BuILdINg COdEs pRIOR TO INsTaLLaTION.
INsTaLLaTION MusT COMpLy WITH LOCaL, REgIONaL, sTaTE
aNd NaTIONaL COdEs aNd REguLaTIONs.
CONsuLT LOCaL BuILdINg, fIRE OffICIaLs OR auTHORITIEs
HavINg juRIsdICTION aBOuT REsTRICTIONs, INsTaLLaTION
INspECTION, aNd pERMITs.
3-90-798
Leave this manual with
party responsible for use
and operation.
WaRNINg
HOT suRfaCEs!
gLass aNd OTHER suRfaCEs aRE HOT
duRINg OpERaTION aNd COOL dOWN.
CauTION
Rev: 5
May, 2011

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OAKLEAF 1-90-797000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Harman OAKLEAF 1-90-797000

  • Page 1 Owner's Manual Installation and Operation Model: Oakleaf Non-Catalytic, Top Load, Wood Burning Room Heater Item #1-90-797000 • Important operating and maintenance instructions included. WaRNINg pLEasE REad THIs ENTIRE MaNuaL BEfORE INsTaLLaTION aNd usE Of THIs WOOd-BuRNINg ROOM HEaTER. f a I L u R E T O f O L L O W T H E s E INsTRuCTIONs COuLd REsuLT IN pROpERTy daMagE, BOdILy INjuRy OR EvEN dEaTH.
  • Page 2 Hearth & Home Technologies welcomes you to our tradition of excellence! By choosing a Harman appliance, you have become part of our commitment to meeting the heating needs of consumers with the most distinctive, powerful and responsible home heating products available. The Oakleaf has huge features in an elegantly small package.
  • Page 3: Table Of Contents

    Oakleaf Woodburning stove section 1: Listing and Code approvals A. Appliance Certifications B. Mobile Home Approval C. Glass Specifications D. Electrical Rating E. BTU & Efficiency Specifications section 2: special Warnings and Notes A. Carbon Monoxide Warnings & Considerations section 3: getting started A.
  • Page 4: Section 1: Listing And Code Approvals

    Listing and Code approvals a. appliance Certification Model: Oakleaf Woodburning Stove Laboratory: OMNI-Test Laboratories, Inc. Report No. 135-S-26-6.2 Type: Solid Fuel Room Heater / Wood Burning Type. Standard(s): UL1482-10, & ULC S627-00 This appliance is also approved for installation in a shop.
  • Page 5: Section 2: Special Warnings And Notes

    Oakleaf Woodburning stove special Warnings and Notes Carbon monoxide, referred to as CO, is a colorless, odorless gas that is produced during combustion of wood and other fuels. CO fumes are toxic and can be fatal. The Oakleaf is a natural draft system which relies on a properly designed chimney to remove CO and other combustion by-products from the stove.
  • Page 6: Considerations

    getting started a. design, Installation & Location Considerations 1. appliance Location Consideration must be given to safety, convenience, traffic flow, and the fact that the appliance will need a chimney and chimney connector. It is a good idea to plan your installation on paper, using exact measurements for clearances and floor protection, before actually beginning the installation.
  • Page 7: Component Locations

    Oakleaf Woodburning stove C. Component Locations Bypass Damper Control Handle d. flue direction Conversion The Oakleaf features an adjustable flue collar for rear or top exit. Follow these instructions for changing the direction. First, remove the upper rear heat shield by removing 8 tek screws that secure it. Reaching upward through the firebox and the open bypass damper, loosen the retainer bolts on each of the flue collar and the cast iron plate.
  • Page 8: Pre-Use Checklist

    E. pre- use Check List Place the appliance in a location near the final installation and follow the procedures below: Open the appliance and remove all articles packed inside. Inspect all items for shipping damage. Notify dealer of any missing or damaged goods.
  • Page 9: Dimensions And Clearances

    Oakleaf Woodburning stove dimensions & Clearances a. appliance dimensions 25"(635mm) 26.2" (665.5mm) Weight Flue Size Log Length Recommended Average Emissions Outside Air size The Harman Oakleaf meets the U.S. Environmental Protection Agency’s emission limits for wood heaters sold after July 1, 1990. Save These Instructions air Intake 29.2"...
  • Page 10: Clearances To Combustibles

    B. Clearances To Combustibles CLEaRaNCE TO COMBusTIBLEs: vertical venting Configuration Location unit to side Wall unit to Back Wall vent pipe to side Wall vent pipe to Back Wall for clearance reduction methods, refer to Nfpa 211 or Local Codes CLEaRaNCE TO COMBusTIBLEs: vertical vent, Horizontal Exit Location unit to side Wall...
  • Page 11 Oakleaf Woodburning stove CLEaRaNCE TO COMBusTIBLEs: Corner Installation, vertical vent Location shield Corner to Wall vent pipe to Wall *for clearance reduction methods, refer to Nfpa 211 or Local Codes CLEaRaNCE TO COMBusTIBLEs: Horizontal venting Configuration Location unit to side Wall unit to Back Wall vent pipe to side Wall Corner Installation...
  • Page 12: Floor Protection

    C. floor protection Requirements floor protection Requirements If the Oakleaf is being installed on a combustible floor, the bottom heat shield (part # 1-00-797058) must be installed along with proper floor protection material. (See page 25). Floor protection must be a minimum 3/8"...
  • Page 13: Section 5: Chimneys And Venting

    Oakleaf Woodburning stove Chimneys and venting a. draft Draft is widely misunderstood. It is important that you, the stove operator, realize that draft is a variable effect, not a given quantity. Stoves and chimneys do not have draft, yet draft is the key to your stove’s performance.
  • Page 14: The Chimney

    Hole with a minimum clear- ance of 18" (450 mm) be- tween connector and wall. AN APPROVED CANADIAN WALL PASS-THROUGH d. The Chimney This unit must be installed into a chimney approved for use with solid-fuel appliances. In the U.S., it must be connected to (1) a prefabricated chimney complying with the requirements for Type HT chimneys in the Standard for Chimneys, Factory-Built, Residential Type...
  • Page 15 Oakleaf Woodburning stove 1. Existing Masonry Chimneys If you plan on using a pre-existing masonry chimney, have it thoroughly inspected and cleaned. Any faults which make the chimney unsafe and unusable must be repaired prior to use. These can include improper height, structural defects, blockages, inadequate clearance to combustibles, unsealed openings into other rooms of the house, signs of creosote or smoke...
  • Page 16: Factory Built Chimney

    standard Ceiling Installation with factory Built Chimney Chimney sections attic Radiation shield Minimum air space with Chimney Listing Chimney Connector The Chimney Connector shall Not pass Through an attic or Roof space, Closet or similar Concealed space, a floor or Ceiling. Dry Seasoned Wood Only! Cathedral Ceiling Installation with Chimney Cap...
  • Page 17 Oakleaf Woodburning stove Chimney Breach fireplace Conversion with Non-Combustible Wall Minimum Clearance to unprotected Ceiling 16" Chimney Connector sealed at Thimble flue Liner with Required air space Three sheet Metal screws per joint of Chimney Connector Mantel and Trim protection floor protection* Combustible floor * floor protection in accordance...
  • Page 18 Oakleaf to flue fireplace Conversion (Minimum Nfpa 211 Liner Connection) flue Liner with Required air space stainless steel Chimney Connector Must Extend to flue Liner Minimum 8" Masonry Thickness in front of smoke Chamber use damper adapter or seal with Non- Combustible Material damper plate is Removed or...
  • Page 19 Oakleaf Woodburning stove full Relining fireplace Conversion: freestanding appliance uL1777 stainless steel Liner system or Other approved lining system follow liner manufacturer's instructions on insulation and support uL1777 Insulated stainless steel flex Liner or Other approved Lining system in Offsets. Listed fireplace Trim protection for Reduced Clearance damper plate Removed or...
  • Page 20 Chimney Breach fireplace Conversion with Combustible Wall Minimum Clearance from Chimney Connector to unprotected Ceiling flue Liner with Required air space Listed or approved Thimble assembly 1"Clearance for Complexity Exterior Chimney or 2" Clearance for Interior Chimney and 2" Clearance for Nfpa 211-Type approved Thimbles floor protection*...
  • Page 21: Mobile Home Installation

    Oakleaf Woodburning stove Mobile Home a. Mobile Home Installation Mobile home approval - u.s. only. dO NOT INsTaLL IN a MOBILE HOME IN CaNada. 1. An outside air inlet must be provided for combustion air, and must remain clear of leaves, debris, ice, and/or snow.
  • Page 22: Section 7: Appliance Set-Up

    appliance set-up a. Outside air attachment Parts and Supplies Needed: 1 piece of metal flexible pipe, 4" X needed length. 1 Rodent Screen, and aluminum tape. Plus, a trim ring for finishing around the pipe on the inside wall. 1. Determine an appropriate hole location, through the wall.
  • Page 23: Optional Blower Installation

    Oakleaf Woodburning stove d. Optional Blower Installation The optional blower kit #1-00-797032 installs easily to the rear of the Oakleaf. Hold the blower assembly into place and secure it with the two bolts provided. You'll need a 3/8" wrench or socket to tighten the bolts.
  • Page 24: Section 8: Operating Instructions

    Operating Instructions CauTION: approved for use with wood fuel only. The use of any other fuel will void the product warranty and may cause damage to the appliance and/or your home. WaRNINg "NEvER usE gasOLINE, gasOLINE-TypE LaNTERN fuEL, kEROsENE, CHaRCOaL LIgHTER fLuId, OR sIMILaR LIquIds TO sTaRT OR "fREsHEN up "...
  • Page 25: Combustion Process

    Oakleaf Woodburning stove 2. doors Your stove has a large glass-paneled door for loading and fire viewing, a separate smaller door for removing ashes and a top loading door. Front Door Before opening, always check for wood, embers, or ash that may be ready to fall out of the door. To open the glass door, open the bypass damper first, then turn the handle clockwise and pull out;...
  • Page 26: User Controls

    d. user Controls Two important controls - the damper bypass handle and the air control lever regulate the operation and output of the stove. To open the top or front loading door, you must open the damper bypass, or smoke will come in the room. In this mode of operation the combustion gases go directly from the main combustion chamber to the flue collar and exit into the chimney.
  • Page 27 Oakleaf Woodburning stove This will begin the highly efficient mode of operation where the exhaust gases get re-burned in the secondary combustion package. If you cannot achieve a charcoal bed within the first 15 to 20 minutes, your wood is likely too wet, and you may need to burn the fire longer and/ or hotter to compensate for the extra energy needed to drive out the moisture.
  • Page 28: Service And Maintenance

    service & Maintenance Creosote- formation and Need for Removal; When wood is burned slowly, it produces tar and other organic vapors which combine with expelled moisture to form creosote. The creosote vapors condense in the relatively cool chimney flue of a slow burning fire. As a result, creosote residue accumulates on the flue lining.
  • Page 29: General Maintenance Procedures

    Oakleaf Woodburning stove B. general Maintenance procedures 1. ash Removal • frequency: As needed / Every day or two • By: User Wear Leather gloves To prevent skin Burns! Open the ash removal door by lifting upward on the latch handle, then swing the door open. Pull the ash pan out of the firebox, using the lip on the front of the pan.
  • Page 30 3. firebox • frequency: As necessary / Yearly • By: User Cleaning the firebox and internal heat exchange surfaces is recommended to maintain thermal efficiency. Depending on the quality and quantity of fuel being used, you may want to perform this cleaning monthly.
  • Page 31: Section 10: Reference Materials

    Oakleaf Woodburning stove Reference Materials Save These Instructions 3-90-798 Dry Seasoned Wood Only!
  • Page 32: Service Parts Listing

    ((sept 2010 thru june 2011)--1-90-797000-2 (Charcoal), 1-90-797000-3 (goldenfi re)) part number list on following page. service parts Cast Iron Wood stove 1-90-797000-1 (Black), Oakleaf Beginning Manufacturing date: sept 2010 Ending Manufacturing date: active 12/11...
  • Page 33 IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement parts for your appliance please provide model number and serial number. All parts listed in this manual may be ordered from an authorized dealer. ITEM dEsCRIpTION Heat Shield-Upper Top Heat Shield-Upper Rear Oak Flue Collar Cover w/Gasket Gasket-3/8 Round LDPSA Oak Flue Collar...
  • Page 34 IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement parts for your appliance please provide model number and serial number. All parts listed in this manual may be ordered from an authorized dealer. ITEM dEsCRIpTION Door Assembly, Front Door Glass Handle Assembly Gasket-1/4 Round PSA, Glass Gasket Gasket-3/8 Round LD, Door Gasket...
  • Page 35: Heat Output

    Manufactured by: HarMan HOMe HeatInG MOdel: Oakleaf u.S. envIrOMental PrOtectIOn aGency Meets EPA particulate matter (smoke) control requirements for noncatalytic wood heaters built on or after July 1, 1990. SMOke Grams Per Hour effIcIency 100% Wood heaters with higher efficiencies cost less to operate. Heat OutPut 9,600 to 24,700 btu use this to choose the right size appliance for your needs.
  • Page 36: Warranty Policy

    Hearth & Home Technologies Inc., on behalf of its hearth brands (”HHT”), extends the following warranty for HHT gas, wood, pellet, coal and electric hearth appliances that are purchased from an HHT authorized dealer. WARRANTY COVERAGE: HHT warrants to the original owner of the HHT appliance at the site of installation, and to any transferee taking ownership of the appliance at the site of installation within two years following the date of original purchase, that the HHT appliance will be free from defects in materials and workmanship at the time of manufacture.
  • Page 37 WARRANTY CONDITIONS: • This warranty only covers HHT appliances that are purchased through an HHT authorized dealer or distributor. A list of HHT authorized dealers is available on the HHT branded websites. • This warranty is only valid while the HHT appliance remains at the site of original installation. •...
  • Page 38: Service & Maintenance Log

    Oakleaf Woodburning stove service & Maintenance Log Date Of Service Performed By Description Of Service Dry Seasoned Wood Only! 3-90-798 Save These Instructions...
  • Page 40 Proudly Printed On 100% Recycled Paper...
