www.nordictrack.com
Model No. NTL61009.0
Serial No.
Write the serial number in the space
above for reference.
Serial Number
Decal
QUESTIONS?
If you have questions, or if parts are
damaged or missing, DO NOT CON-
TACT THE STORE; please contact
Customer Care.
iMPORTANT: Please register this
product (see the limited warranty
on the back cover of this manual)
before contacting Customer Care.
CALL TOLL-FREE:
1-888-825-2588
Mon.-Fri.
6 a.m.-6
p.m. MT
Sat. 8 a.m.-4
p.m. MT
ON THE WEB:
www.nordictrackservice.com
A UAL
Advertisement
Table of Contents
Related Manuals for NordicTrack T5zi NTL61009.0
Summary of Contents for NordicTrack T5zi NTL61009.0
- Page 1 Model No. NTL61009.0 A UAL Serial No. Write the serial number in the space above for reference. Serial Number Decal QUESTIONS? If you have questions, or if parts are damaged or missing, DO NOT CON- TACT THE STORE; please contact Customer Care.
- Page 2 ..• Keep cloth ng, fingers, and hair TREADMILL I SINOPERATION. • Neve_ t_y to adjusi or fix the belt while it is moving. athletic shoes wNle .Always wear operating treadmill. NordicTrack is a registered trademark of ICON IP, Inc.
- Page 3 14. To purchase a surge suppressor, informed of all warnings and precautions. your local NordicTrack dealer or call the tele- phone number on the front cover of this man- Use the treadmill only as described.
- Page 4 20. Never leave the treadmill unattended while it Inspect and properly tighten all parts of the is running. Always remove the key, unplug treadmill regularly. the power cord, and switch the reset/off cir- DANG ER: A ways the power unplug cuit breaker to the off position when the treadmill is not in use.
- Page 5 BEFORE YOU BEGIN Thank you for selecting the revolutionary NordicTrack ® ing this manual, please see the front cover of this man- T5zi treadmill. The T5zi treadmill offers an impressive ual. To help us assist you, please note the product selection of features designed to make your workouts model number and serial number before contacting us.
- Page 6 ASSEMBLY Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials. Do not dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking belt is coated with high-performance lubricant.
- Page 7 Make sure that the power cord is unplugged. With the help of a second person, carefully tip the treadmill onto its left side. Partially fold the Frame (55) so that the treadmill is more stable; do not fully fold the Frame yet. Cut the shipping tie securing the Upright Wire (87) to the Base (95).
- Page 8 Hold a Bolt Spacer (14) inside the lower end of the Right Upright (85). Insert a 3/8" x 4" Patch Bolt (7) with a 3/8" Star Washer (11) into the Right Upright and the Bolt Spacer. Repeat this step with a second Bolt Spacer (14), 3/8" x 4" Patch Bolt (7), and 3/8"...
- Page 9 Hold a Bolt Spacer (14) inside the lower end of the Left Upright (84). Insert a 3/8" x 4" Patch Bolt (7) with a 3/8" Star Washer (11) into the Left Upright and the Bolt Spacer. Repeat this step with a second Bolt Spacer (14), 3/8" x 4" Patch Bolt (7), and 3/8"...
- Page 10 Slide the Right Upright Cover (86) onto the Right Upright (85), Remove the tie from the bracket on the Right Handrail (83). Hold the Right Handrail (83) near the Right Bracket Upright (85), Insert the Upright Wire (87) through the bracket on the bottom of the Right Handrail.
- Page 11 11. Firmly tighten the four 5/16" x 1" Patch Bolts (3) and the two 5/16" x 1" Patch Bolts (4) (only one side is shown). Console Assembly With the help of a second person, hold the con- sole assembly near the Right Handrail (83) and the Left Handrail (not shown).
- Page 12 13. Hold the Right Upright Cover (86) against the console assembly. Align the holes in the Right Upright Cover with the holes in the Right Upright (85). Attach the Right Upright Cover with two #8 x 3/4" Screws (1). Attach the Left Upright Cover (80) to the Left Upright (84) in the same way.
- Page 13 15. Raise the Frame (55) to the position shown. Have a second person hold the Frame until this step is completed. Orient the Storage Latch (51) so that the large barrel and the Latch Knob (52) are oriented as shown. Attach the upper end of the Storage Latch (51) to the bracket on the Frame (55) with a 3/8"...
- Page 14 Outlet Box the right). To purchase a surge suppressor, /ll _J ] Adapter your local NordicTrack dealer or call the telephone number on the front cover of this manual and order Surge suppressor part number 146148, or see your local electronics store.
- Page 15 CONSOLEDIAGRAM U 21 INCLINE CALORIES TIME FEATURES OF THE CONSOLE phone number on the front cover of this manual. iFit cards are also available at select stores. The treadmill console offers an impressive array of features designed to make your workouts more effec- You can even listen to your favorite workout music or tive and enjoyable.
- Page 16 HOW TO TURN ON THE POWER HOW TO USE THE MANUAL MODE iMPORTANT: if the treadmill has been exposed to insert the key into the console. cold temperatures, allow it to warm to room tem- See HOW TO TURN ON THE POWER at the left. perature before turning on the power, if you do not...
- Page 17 Change the incline of the treadmill as desired. Speed display--This LJI"I display shows the speed loll To change the incline of of the walking belt. the treadmill, press the ,D. I SPEED Incline increase and de- crease buttons or one of INCLINE the numbered incline To reset the displays, press the Stop button, re-...
- Page 18 HOW TO USE A PRESET WORKOUT grammed for the next segment, the speed or in- cline setting will flash in the display to alert you. Insert the key into the console. The treadmill will then automatically adjust to the speed and incline settings for the next segment. See HOW TO TURN ON THE POWER on page 16.
- Page 19 HOW TO USE AN IFIT WORKOUT Start the walking belt. To purchase iFit cards at any time, go to www.iFit.com Press the Go button or the Speed increase button or call the telephone number on the front cover of this to start the workout.
- Page 20 THE iNFORMATiON MODE HOW TO USE THE STEREO SOUND SYSTEM The console features an information mode that keeps To play music or audio books through the console's track of the total number of hours that the treadmill has stereo speakers, you must connect your MP3 player, been used and the total distance that the walking belt CD player, or other personal audio player to the con- has moved.
- Page 21 HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE Before folding the treadmill, adjust the incline to the lowest position, if you do not do this, you may damage the treadmill when you fold it. Remove the key and unplug the power cord.
- Page 22 TROUBLESHOOTING Most treadmill problems can be solved by following the simple steps below. Find the symptom that applies, and follow the steps listed, if further assistance is needed, see the front cover of this manual. PROBLEM: The power does not turn on SOLUTION: a.
- Page 23 Remove the three #8 x 3/4" Screws (1) and care- fully pivot the Motor Hood (62) off. Locate the Reed Switch (73) and the Magnet (47) on the left side of the Pulley (48). Turn the Pulley until the Magnet is aligned with the Reed Switch. Make sure that the gap between the Magnet and 1/8 in.
- Page 24 PROBLEM: The walking belt is off-center or slips when walked on SOLUTION: a. If the walking belt is off-center, first remove the key and UNPLUG THE POWER CORD. If the walking belt has shifted to the left, use the hex key to turn the left idler roller bolt clockwise 1/2 of a turn;...
- Page 25 EXERCISE GUiDELiNES Burning Fat--To burn fat effectively, you must exer- , WARNING: Before beginning this cise at a low intensity level for a sustained period of time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.
- Page 26 PART LiST--Model No. NTL61009.0 R0809C To locate the parts listed below, see the EXPLODED DRAWING near the end of this manual. Key No. Qty. Description Key No. Qty. Description #8 x 3/4" Screw Storage Latch #10 x 3/4" Screw Latch Knob 5/16"...
- Page 27 KeyNo. Qty. Description KeyNo. Qty. Description Console Console Ground Wire Console Frame Audio Wire Left Tray 8" Blue Wire, M/F Right Tray 10" Blue Wire, 2F Console Clamp 12" Red Wire, M/F Console Base 10" Black Wire, M/F Crossbar User's Manual Access Door Note: Specifications are subject to change without notice.
- Page 28 EXPLODED DRAWING A--IVlodel No. NTL61009.0 R0809C I'--- [..,r,.- .,r.- ',,:d...
- Page 29 EXPLODED DRAWING B--Model No. NTL61009.0 Ro8o9c " 4_71 78-- 79--...
- Page 30 EXPLODED DRAWING C--Model No. NTL61009.0 Ro8o9c...
- Page 31 EXPLODED DRAWING D--Model No. NTL61009.0 Ro8o9c...
- Page 32 ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to pro- vide the following information when contacting us: o the model number and serial number of the product (see the front cover of this manual) o the name of the product (see the front cover of this manual) o the key number and description of the replacement part(s) (see the PART LIST and the EXPLODED DRAWING near the end of this manual)
