- Page 1 Multifunction pyrolytic oven Installation instructions OB60S9DEP models User guide NZ AU GB IE SG...
-
Page 3: Table Of Contents
Contents Safety and warnings Installation instructions Introduction The control panel Setting the clock and first use Using your oven Oven functions Using the timer Automatic cooking Baking chart User preference settings Sabbath setting Care and cleaning Using the Self Clean function... -
Page 4: Safety And Warnings
Safety and warnings Installation Electrical Shock Hazard Always disconnect the appliance from the mains power supply before carrying out any maintenance or repairs. Connection to a good earth wiring system is essential and mandatory. Alterations to the domestic wiring system must only be made by a qualified electrician. - Page 5 Do not touch heating elements or interior surfaces of the oven. Heating elements may be hot even though they are dark in colour. Interior surfaces of an oven become hot enough to cause burns. During and after use, do not touch, or let clothing or other flammable materials contact heating elements or interior surfaces of the oven until they have had sufficient time to cool.
-
Page 6: Important Safety Instructions
Do not heat unopened food containers. They can build up pressure that may cause the container to burst and result in injury. Safe food handling: leave food in the oven for as short a time as possible before and after cooking. This is to avoid contamination by organisms which may cause food poisoning. Take particular care during warm weather. -
Page 7: Installation Instructions
Note: If installing a cooktop above the oven, ensure adequate clearance is provided for the cooktop as per the cooktop manufacturer’s instructions. *All height measurements include mounted feet. - Page 8 Important! Please take extra care not to damage the lower trim of the oven. It is important for correct air circulation and allows the door to open and close without obstruction. The manufacturer does not accept any responsibility for damage resulting from incorrect installation.
- Page 9 Connecting the oven to the mains power supply Important! This oven must be connected to the mains power supply only by a suitably qualified person. This oven must be earthed. Before connecting the oven to the mains power supply, check that...
- Page 10 Do not over-tighten the screws. Do not seal the oven into the cabinetry with silicone or glue. This makes future servicing difficult. Fisher & Paykel will not cover the costs of removing the oven, or of damage caused by this removal.
- Page 11 Turn the power to the oven on. The display should light up and show Turn the oven function dial to ‘Bake’ . Air should blow out of the vent at the top of the oven. Inside the oven cavity, the oven light should come on. After five minutes, open the oven door: the air inside should feel warm.
-
Page 12: Introduction
Introduction Congratulations on your new purchase. Your Fisher & Paykel multifunction pyrolytic oven has a number of features to make cooking a great experience for you: a choice of eight oven functions a convenient, no-mess, pyrolytic Self Clean function – see ‘Using the Self Clean function’... -
Page 13: The Control Panel
Scroll Locking the control panel You can lock the control panel to prevent unintended use (eg children playing with the oven). Doing so will disable the dials and all the buttons. To lock the control panel Make sure the oven is not in use (the function dial is turned to Off cooking nor the timer is set (no indicator is lit in the display). -
Page 14: Setting The Clock And First Use
Make sure you have set the clock. Slide in the shelves and the grill tray. See ‘Using your oven’ for instructions. If the sliding shelf supports are not already fitted, see ‘Care and cleaning’ for instructions on fitting them. Heat the oven for:... -
Page 15: Using Your Oven
- - - - - - Adjust the temperature. While the oven is heating up, the halo will glow red and the temperature indicator will alternately show the actual and set temperatures. -
Page 16: Oven Functions
Great for roasting vegetables too. Self Clean The Self Clean cycle takes care of the mess and grime that is traditionally associated with oven cleaning. See ‘Using the Self Clean function’ for details. Note: this is NOT a cooking function. -
Page 17: Using The Timer
You can use the timer at any time, even if you are not using the oven. If the time is more than an hour, the display will count down in minutes (hr:min). If it is less than an hour, it will count down in seconds (min:sec). -
Page 18: Automatic Cooking
Important! Safe food handling: leave food in the oven for as short a time as possible before and after cooking or defrosting. This is to avoid contamination by organisms which may cause food poisoning. Take particular care during warmer weather. - Page 19 Adjust the temperature. When automatic cooking is set The oven and the light will stay off, the halos will be unlit, but your oven is now set for automatic cooking. It will automatically turn on at the required time. In a few seconds, the display will show the time of day with the cooking time and stop time indicators lit.
-
Page 20: Baking Chart
Shelf positions are counted from the base up (1 is the lowest, 6 the highest). Position the flat oven shelf before you turn the oven on, then preheat the oven to the required temperature. Place items in the oven only when the long tone has sounded and the temperature dial halo has turned from red to white.*... -
Page 21: User Preference Settings
You can set your oven to: display the temperature in degrees Celsius or Fahrenheit give audio feedback (tones and beeps) or operate quietly display time as 12-hr or 24-hr operate with the display off have its light on or off during cooking operate in Sabbath setting (see ‘Sabbath setting’... - Page 22 * The timer tone and alert beeps will sound even if you save the ** With this option saved, you can still use the oven but the display will be unlit and the buttons will be unresponsive. To quit this option and enable the display, press and hold the cancel button.
-
Page 23: Sabbath Setting
No alert codes or temperature changes will be displayed. The oven light will stay on. If you want the oven light to be off during Sabbath setting, first select the ‘Light off’ option as described in ‘User preference settings’ , and only then set Sabbath setting. - Page 24 Sabbath setting. The default option is ‘Sabbath off’ . The display will flash. The display, indicators and dial halos will be unlit and unresponsive, but the oven will bake until you quit Sabbath setting. To quit Sabbath setting Press and hold the cancel turns off.
-
Page 25: Care And Cleaning
Don’t use cleaning products with a chlorine or acidic base. Don’t clean the oven seal (see ‘Introduction’ for illustration of this part) or use any oven cleaning products on it. Important! Don’t use oven cleaners or any... -
Page 26: Manual Cleaning
Wipe dry with a soft cloth. To clean stubborn, ‘baked on’ soiling or the whole oven cavity: use the Self Clean function. See ‘Using the Self Clean function’ for instructions. Grill tray Clean with a solution of mild Grill rack detergent and hot water. - Page 27 Care and cleaning Removing and refitting the side racks Use a flat-head screwdriver or a small coin to loosen the fixing screws in the front. When refitting the side racks, make sure that they are the right way up, as in the illustrations, and that you tighten the fixing screws.
- Page 28 Care and cleaning Removing and refitting the sliding shelf supports Important! Remove the side racks first to make removing the sliding shelf supports easier. The sliding shelf supports cannot be used on shelf positions 4 and 5. When refitting the sliding shelf supports, make sure that you fit: the side racks first the slides to the top wire of a shelf position (1,2,3 or 6) both sides of each pair of slides...
- Page 29 Removing and refitting the oven door You can remove the door to make wiping out the oven cavity or replacing the light bulb easier. Important! Take care, the oven door is heavy! To remove the door Open the door fully.
- Page 30 Care and cleaning Replacing the oven light bulb Note: oven bulb replacement is not covered by your warranty. Let the oven cavity and the grill element cool down. Important! Disconnect the oven from the power supply before continuing. Release the lamp cover by pulling the tab on its left side towards you.
-
Page 31: Using The Self Clean Function
The oven door will be locked during the Self Clean cycle (approximately 3 hours). If there are cracks or flaws on any of the oven door glass panes, if the oven seal is damaged or worn, or if the door does not close properly, do not start a Self Clean cycle. Call your Authorised Repairer or Customer Care. - Page 32 Self Clean cycle. The time will start counting down. For your safety, the oven door will automatically lock and remain locked during the cycle. Note: if the select button is not pressed within 15 seconds, the oven will automatically turn off.
- Page 33 When it has cooled down, the oven will turn off, the door will unlock, a long tone will sound and the display will show the time of day.
-
Page 34: Troubleshooting
The oven does not work and the display is dark. The oven does not work but the display is lit. The light does not come on when I open the oven door. The temperature indicator shows --- and the dials and buttons are unresponsive. - Page 35 I use Grill Possible causes This is normal: when heating up from cold, your oven is designed to initially heat to a temperature somewhat higher than what you have set. This is to provide optimal baking conditions right from the start.
- Page 36 The oven is beeping and the display shows Possible causes This is normal: the oven’s cooling fans operate at their highest speed. The door has not been properly closed. The oven door is locked because the oven is still too hot to be used for cooking.
-
Page 37: Alert Codes
Important! Do not turn off the mains power supply to the oven if you get an alert code, unless the instructions in the chart following specifically instruct you to. There are cooling fans within the oven which are needed to cool the oven’s components. - Page 38 You can now use the oven again. Turn the power to the oven off and on again. Wait approximately 10 seconds. This is to allow the door lock to return to its initial position.
-
Page 39: Warranty And Service
Warranty book for warranty details and your nearest Authorised Repairer, or contact us through our local website listed on the back cover. This oven has been designed and constructed in accordance with the following codes and specifications: In New Zealand and Australia:... - Page 44 www.fi sherpaykel.co.nz www.fi sherpaykel.com.au www.fi sherpaykel.co.uk www.fi sherpaykel.ie www.fi sherpaykel.com.sg Copyright © Fisher & Paykel 2010. All rights reserved. The product specifications in this booklet apply to the specific products and models described at the date of issue. Under our policy of continuous product improvement, these specifications may change at any time.
