Installing and removingpreviouslyinstalled decoratorpanels.
Removing the Handles
In order to remove the decorator panels and replace with new panels you need to remove the handles. A T-20 Torxdriver
is neede_
_]I,oosen and remove tile 2 screws in the Top Trim.
[_I,oosen and remove the 2 s(rews in the bra(ket that atta( hes the Handle to tile top of the Door.
_] (;rip the Handle fixrely and slide upwards. The keyhole slots on the Handle slide off the buttons on
tile door.
[_] Open the door and slide out the de(orator panels.
Top Trim Screws
Bracket S crews
Bracket
Siots
Inserting the Door Panels
Before installing the decoretor panels, make sure they have been routed out in the proper areas as shown in the
beginning of this section. Sfide in the panels to perform a trial fit before fastening down the Handle and Top Trim.
Installing the Handles
Once the panels are fitted properly, install the Handle and Top Trim.
_] Slide tile keyhole slots on tile Handle down onto the buttons mounted to tile face of the door. Slide the
Handle dox_nward until the bracket at the top of the Handle fits flush on the top of the door.
[_ Repla(e the two screws in the bra(ket that atta(h the Handle to the top of the Door and tighten the
s(rews to 45 in-lbs torque.
_] Replace tile Top Trim
making
suI'e it fits ovei the Side Trim and that tile locating tabs fit the inside of
the Handle profile.
_] Repla( e the Top Trim s( rews and tighten to 30 in-lbs torque.
25
