- Page 1 X-Treme Electric Moped Operation and Maintenance Instructions XM-3500Li Revised 10/15/08 We strongly recommend that you read this entire manual before using your vehicle for the first time...
-
Page 2: Table Of Contents
Contents Page General Instruction before riding Page 3 Point Inspection Page 4 Assembly Instructions Page 5 Technical Specifications Page 6 Parts List Page 7 Front Display Page 8 Ignition Key Positions Page 9 Handle Bar Controls Page 10 Power Boost Button Page 10 Accelerating &... -
Page 3: General Instruction Before Riding
General Instructions Before Riding 1) To ensure the vehicle is functioning correctly, do a quick check of the vehicle’s tires and check that the brakes are working. (For more detailed maintenance instructions see the Maintenance Schedule). Your vehicle has been thoroughly checked by our engineers before delivery but on the spot checks are equally important. -
Page 4: Point Inspection
Point Inspection before every use Item Action Front Brake Squeeze right hand brake and push the vehicle to see whether it rolls easily. If it does, then the brake must be tightened. Tighten the bolt until the vehicle will no longer move with the brakes applied. Rear Power/Disc Listen for any noticeable grinding or squealing from... -
Page 5: Assembly Instructions
Assembly Instructions Installing the mirrors 1. Mirrors can be easily fixed to the handle bars between the grips and the brake handle. 2. Screw in the mirror clockwise. The mirror that goes on the left controller is curved to the left and the mirror that goes on the right controller curves to the right. -
Page 6: Technical Specifications
Technical Specification Motor Power 3500W Brushless Hub Motor Battery DC 60V, 40AH with LFP lithium batteries Charger 10A,110V~250V/50 Hz ~60Hz ,with BMS Charging Time 4 Hours Life of Battery 2000 Deep Cycles Wheelbase 13 Inches Torque 160Nm (100 ft-lb) Top Speed 48 mph (77km/H) Single Charge 40Mile (65km) at TOP speed, and 70Mile (112km) at 35km/H... -
Page 7: Parts List
Parts List A. Horn B. Throttle and Front Brake Handle C. Rear View Mirror D. Head Lamp E. Dash Board F. Odometer (Kilometer/Mileage) G. Under seat storage H. Front storage box Tail Lamp J. Front Disk Brake K. Rear disc Brake L. -
Page 8: Front Display
Front Display Part Item Function Indicator Light is on when indicator is on Clock Show the time Head Lamp Light Light is illuminated when switch key and head lamp are ‘ON’ Speedometer Indicates speed Odometer Indicates mileage Critical Battery Red light is illuminated when the battery is discharged Low Battery Yellow light is on when battery is low Full Battery... -
Page 9: Ignition Key Positions
Ignition Key Position Description Position Key cannot be taken out when power is on. Key can be taken out when power is off Lock handle To prevent theft, turn the Handle Bar to the far left and turn the key into the lock position. The key can be taken out when handle bar is in the lock position. -
Page 10: Handle Bar Controls
Left handle bar controls Headlight Switch High Beam – Push switch up Low Beam – Push switch down Horizontal Switch Left Turn Signal – Slide switch to the left Right Turn Signal – Slide switch to the right Turning off Signal – Press central release button Horn Button Sounds Horn –... -
Page 11: Accelerating & Braking
Accelerating and Braking Throttle Tips 1. Turn the key to the ‘ON’ position, and turn the Throttle gradually to accelerate. 2. To prevent losing control of the vehicle, please turn the Throttle slowly until the speed increases. 3. Do not turn the Throttle until you are in the position to drive. 4. - Page 12 Battery Gauge and Charging Instructions Color Description Green While riding, when the battery is fully charged the gauge light will be green. Green (2 This light indicates that the battery is 75% of full charge Yellow When power is low (around 50%) the battery gauge will turn to yellow.
-
Page 13: Performance
Performance 1. A range of 70Mile (112km) has been recorded, yet the distance and speed depend upon various elements of the rider’s style and the road conditions. A 20mph constant speed will ensure the longest range but our figures include going flat out too. Other factors include weather, vehicle condition, and battery charge. -
Page 14: Maintenance
Maintenance This electric motorbike represents generation environmentally friendly two-wheeled transportation. Therefore, good maintenance will play a major role in keeping your vehicle in good working condition and prolonging the life of the batteries. Please follow these suggestions: To prevent rust always keep your vehicle dry and clean. ... -
Page 15: Maintenance Schedule
Maintenance Schedule Mileage 400 1000 2000 3000 4000 5000 6000 Maintenance Battery Charger Tire Pressure Tire Wear Brake System Brake Nuts Bolts Mileage 7000 8000 9000 10,000 11,000 12,000 Maintenance Battery Charger Tire Pressure Tire Wear Brake System Brake Nuts Bolts A: Adjust C: Check... -
Page 16: Frequently Asked Questions
The brushless motor is precisely that so there is never a need to change the brushes. 5. What about parts, is it a problem getting parts for the XM-3500Li ? I. ALL parts can be purchased directly from the supplier including batteries, tires, bulbs, body shells, seats etc. - Page 17 A. As with any electric vehicle, care should always be taken when washing. B. One should be careful never to pour water directly into the charger outlet, the controller and the internal battery set when washing or cleaning 7. Do you need to wear a helmet to drive the electric vehicle? A.
- Page 18 13. Why is this product the best available in the world today? It has a Brushless motor. We emphasize "brushless" not just because this is the latest technology, but because these permanent magnet motors are supremely reliable! These more expensive motors produce high torque at low speeds, keeping an acceptable balance of torque and energy across the whole speed range.
-
Page 19: Troubleshooting
Troubleshooting Problem Condition Check Solution When I turn my Power check the Fasten vehicle on nothing indicator light is off circuit breaker under connections. happens. while riding. the seat Indicating Check battery Recharge light on motor is not and motor battery. - Page 20 Check the fuse Unplug the in the charger box. charger and replace the fuse. Contact the supplier to order a new charger fuse/charger. Charger has Replace the blown a fuse. charger fuse. The fuse box is located on the floorboard, unscrew the two screws and open the fuse case, and...
- Page 21 For General Information or Parts Visit www.x-tremescooters.com For Technical Support or Assistance Visit www.x-tremescooters.com/support/...
