Parts List
RFID User Guide
For printer model:
TG3 Series
PN: 9001227(A)
Read this User Guide before and during usage of the above product.
Keep this document handy for future reference.
PN: 9001147D
www.satoamerica.com
www.satoamerica.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TG3 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SATO TG3 Series

Summary of Contents for SATO TG3 Series

  • Page 1 Parts List RFID User Guide For printer model: TG3 Series PN: 9001227(A) Read this User Guide before and during usage of the above product. Keep this document handy for future reference. PN: 9001147D www.satoamerica.com www.satoamerica.com...
  • Page 2 SATO Corporation reserves the right to change or improve this product and document without notice. Trademarks SATO is a registered trademark of SATO Corporation and/or its subsidiaries in Japan, the U.S and other countries. SATO America, Inc. 10350 Nations Ford Road Charlotte, NC 28273 Main Phone: (704) 644.1650...

  • Page 3: Engine Assembly

    P28005000 TENSION PLATE A P28095000 MOTOR PULLEY (22) P28132000 TENSION SHAFT A P28147000 SHAFT (CUT PULLEY B) P28158000 TENSION SHAFT C P28188010 SUPPORT SHAFT P28697000 SPRING (IDLE) R12492010 TENSION PLATE B ASSEMBLY TG3 Series Parts List PN 9001227A Page 1...
  • Page 4 PULLEY(69) ASSEMBLY R14231000 PULLEY (55/55) ASSEMBLY TG308 R14232000 PULLEY ASSEMBLY TG308 R14233010 CUTTER PULLEY (27/27) ASSEMBLY R14234000 CUTTER PULLEY (27) ASSEMBLY R14237000 PULLEY ASSEMBLY R14821000 PULLEY (55/83) ASSEMBLY TG312 R15137000 PULLEY ASSEMBLY TG312 TG3 Series Parts List 9001227A Page 2...
  • Page 5 P32002000 TIMING BELT TG308 TG312 P32003000 TIMING BELT TG308 TG312 P32004000 TIMING BELT TG308 TG312 P32005000 TIMING BELT TG308 TG312 P32006000 TIMING BELT TG312 P32007000 TIMING BELT TG312 P33345000 TIMING BELT TG308 TG3 Series Parts List PN 9001227A Page 3...
  • Page 6 TENSION SHAFT B P28158000 TENSION SHAFT C P28697000 SPRING (IDLE) PA3760500 SUPPORTER CLAMP R12497010 TENSION PLATE A ASSEMBLY R12498010 TENSION PLATE C ASSEMBLY R13886000 POWER ROUTE A ASSEMBLY R13887000 POWER ROUTE D ASSEMBLY TG3 Series Parts List 9001227A Page 4...

  • Page 7: Sensor Assembly

    P TIGHT SCREW ND0040030 E SNAP RING P28030000 SHAFT (SLIDE) P28039010 BRACKET B (S/H SEN) P28040010 BRACKET(C/H SENS) P28041000 SHAFT (SENSOR) P28042010 BRACKET (RACK C/H SENSOR) P28207000 LENS (I MARK) P28209000 RACK B (CENTER) TG3 Series Parts List PN 9001227A Page 5...
  • Page 8 BODY A (S/H SEN) ASSEMBLY R14168000 GAP & CENTER HOLE (U) SENSOR CABLE SET-LF R14174000 GAP & CENTER HOLE (L) SENSOR CABLE SET-LF R14178010 SIDE HOLE (L) SENSOR CABLE SET-LF R14236010 FRAME ASSEMBLY TG3 Series Parts List 9001227A Page 6...
  • Page 9 PAN HEAD P TIGHT SCREW MH1200522 FLAT HEAD P TIGHT SCREW MT1300522 HEXAGON NUT (2N3X0.5) ND0030030 E SNAP RING E350 ND0040030 E SNAP RING P25440010 SENSOR COVER (I MARK) P25546000 LOCK COLLAR (HEAD) TG3 Series Parts List PN 9001227A Page 7...
  • Page 10 COLLAR PE5A21700 HEAD OPEN KNOB R13583000 FEED LOCK ASSEMBLY R14169000 IM & EDGE SENSOR CABLE SET-LF R14171000 AF & J-HOLE (U) SENSOR CABLE SET-LF R14181000 LITTLUCH SENSOR CABLE SET-LF P40559000 SPRING (PAPER GUIDE) TG3 Series Parts List 9001227A Page 8...

  • Page 11: Head Assembly

    E SNAP RING ND0050030 E SNAP RING ND0060030 E RING P11232200 PR KNOB P22186000 POLY SLIDER P25492010 SPRING (HEAD ONE TOUCH) P27709030 SHAFT (HEAD PRESSURE C) P27715020 SHAFT (HEAD ADJUST) P27716010 SHAFT (HEAD MAIN) TG3 Series Parts List PN 9001227A Page 9...
  • Page 12 COLLAR (PRESSURE SHAFT) P32010000 PLASTIC WASHER P32069001 KNOB (HEAD PRESSURE) P34438000 PLASTIC WASHER Q02514000 STICKER(HEAD AJ) R12366010 HEAD TOP BR ASSEMBLY R12367010 HEAD BRACKET ASSEMBLY R14221020 HEAD FRAME ASSEMBLY R14238000 SHAFT ASSEMBLY (HEAD STAY) TG3 Series Parts List 9001227A Page 10...
  • Page 13 SPACER (LATCH HANDLE) P27882000 COVER (LATCH HANDLE) P27883000 COVER (PRESSURE SHAFT) P27884010 HANDLE_DANTUKINEJI P28000010 POWER ROUTE (BASE) B P31946000 SPRING (HEAD PRESS) C R14165000 POWER & HEAD CABLE SET-LF R14166000 HEAD CABLE SET-LF TG3 Series Parts List PN 9001227A Page 11...
  • Page 14 HEAD ASSEMBLY (PL3B) ITEM PART NUMBER PART DESCRIPTION R14222000 PRINT HEAD (8 DPMM)TG308 R14223000 PRINT HEAD (12 DPMM) TG312 R14238000 SHAFT ASSEMBLY (HEAD STAY) TG3 Series Parts List 9001227A Page 12...

  • Page 15: Cutter Assembly

    SHAFT (CUTTER SENSOR) P27784000 SENSOR BR (CUTTER) R18294000 CUTTER SENSOR BR SET (TG) R18228000 SENSOR COVER SET P27788010 CUTTER BRACKET P28172000 SENSOR COVER A(CUTTER) P31836010 POST SCREW P31920000 CUTTER ASSEMBLY PA2760100 SENSOR COVER TG3 Series Parts List PN 9001227A Page 13...
  • Page 16 CUT SENSOR COVER PE2680900 SPACER PL1760100 PULLEY PT9761000 PAN HEAD SCREW R14107000 CUTTER TAG SENSOR (L) SET-LF R14137000 CUT PCB SET-LF R14184000 CUTTER POSITION SENSOR CABLE SET-LF R14186000 CUTTER SENSOR (U) CABLE SET-LF TG3 Series Parts List 9001227A Page 14...

  • Page 17: Cutter Cover

    P25561010 BRACKET (CUT ROLLER) P27780000 SHAFT (CUTTER OKURI) P28811020 CUTTER COVER P29794010 SHAFT (CUTTER ROLLER) P31090010 CUTTER COVER PLATE P34471000 SHEET (THUNDERON) PC1760400 SPRING R14226000 CUTTER ROLLER ASSEMBLY R14227000 CUTTER PULLEY ASSEMBLY TG3 Series Parts List PN 9001227A Page 15...

  • Page 18: Feed Assembly

    P24998010 SHAFT (IDLE B) P27904000 PLATE (OPEN LOCK) P28057010 BRACKET (FEED ROLLER) P28058000 SHAFT (FEED ROLLER) P28205000 LENS (SIDE HOLE) R18311000 FEED ROLLER (UPPER) S/A P28219000 SENSOR BR (JUMP HOLE) P28338010 SHAFT (SUPPORT) TG3 Series Parts List 9001227A Page 16...
  • Page 19 SHAFT (PULLEY R) PE2730300 STOPPER COLLAR PL2720100 ADJUST COLLAR QC6A20200 PUSH LABEL R12486020 FEED COVER ASSEMBLY R14198000 SIDE HOLE (U) SENSOR CABLE SET-LF R14203000 AF & J-HOLE (U) SENSOR SUB CABLE SET-LF TG3 Series Parts List PN 9001227A Page 17...
  • Page 20 P TIGHT SCREW MH0300822 PAN HEAD P TIGHT SCREW P27904000 PLATE (OPEN LOCK) P28053000 PLATE (F/R POSITION) P28063000 SHAFT (LID LATCH) P28317010 RFID CASE P28331000 PAPER GUIDE (RFID) P28362000 PAPER GUIDE (LABEL SENSOR) TG3 Series Parts List 9001227A Page 18...
  • Page 21 RIBBON SENSOR-1 CABLE SET-LF R14173000 HEAD OPEN SENSOR CABLE SET-LF R14179000 EDGE (U) SENSOR CABLE SET-LF R14180000 RIBBON SENSOR-2 CABLE SET-LF R14185000 CUTTER SENSOR (L) CABLE SET-LF R14187003 AC LINE CABLE SET-LF TG3 Series Parts List PN 9001227A Page 19...

  • Page 22: Ribbon Assembly

    E SNAP RING ND0060030 E RING ND0080030 E-SNAP RING P00170000 ONE-WAY LIMITER P11283000 DISK PLATE TL P11305010 GRIP SHEET P11461000 ONE-WAY CLUTCH P13863010 TENSION ROLLER P22568000 SPRING (CLIP) P22892000 SPRING (RELEASE) P23675000 KNOB TG3 Series Parts List 9001227A Page 20...

  • Page 23: Ball Bearing

    SPRING (IDLE) P30322000 TORQUE LIMITER P32009000 TIMING BELT P32285000 SPRING (SLIDE) P37081000 GRIP SHEET PT1116060 BALL BEARING Q01840010 STICKER (LOCK) Q02428000 ACETATE TAPE R12492010 TENSION PLATE B ASSEMBLY R14231000 PULLEY (55/55) ASSEMBLY TG308 TG3 Series Parts List PN 9001227A Page 21...
  • Page 24 P00005000 TORQUE LIMITER PT1112060 BEARING, PLATEN ROLLER (INNER) P22505000 ONE-WAY CLUTCH FOR DISPENSER P27901000 FRAME (RIBBON) P27906000 BRACKET (RIBBON UW A) P28087020 RIBBON SHAFT A P28138000 RIBBON GEAR_I (20) P28139000 RIBBON GEAR_J (50) TG3 Series Parts List 9001227A Page 22...
  • Page 25 BF STOPPER RIBBON P28335010 SHAFT(GEAR PULLEY) P32845000 TIMING BELT PA1731000 ADJUST PLATE PA3760500 SUPPORTER CLAMP PE7720150 DISK PLATE(A) PT1112060 BEARING, PLATEN ROLLER (INNER) PT1116060 BALL BEARING PT1116080 BALL SUPPORTER PT9A20600 TORQUE LIMITER TG3 Series Parts List PN 9001227A Page 23...

  • Page 26: Frame Assembly

    PAN HEAD SCREW +SW +WL MD4401022 PAN HEAD SCREW +SW +WL P16092000 BEARING CLAMP P28028010 PAPER GUIDE A P28059000 PAPER GUIDE (FEED B) P28819000 LABEL COVER RH PT1116080 BALL SUPPORTER PV2760100 RUBBER FOOT R12496010 FRAME (LABEL)ASSEMBLY TG3 Series Parts List 9001227A Page 24...
  • Page 27 HEXAGON SOCKET HEAD CAP SCREW (W POINT) MT1300522 HEXAGON NUT ND0020030 E SNAP RING ND3160024 C-SNAP RING P16092000 BEARING CLAMP PT1112060 BEARING, PLATEN ROLLER (INNER) P32016000 TORQUE LIMITER P25491000 SPRING (SHIWAKE MARK) P25502000 SPRING (LABEL GUIDE) TG3 Series Parts List PN 9001227A Page 25...
  • Page 28 LABEL BOSS COVER P32745000 KNURLING SCREW M3*10 P32581000 BUSH P32582000 BUSH PE1740400 SENSOR BRACKET (TOP) PT1116080 BALL SUPPORTER PT1117050 BALL BEARING R14136000 KB PCB ASSEMBLY-LF R14253000 SOLENOID SET-LF R14326000 LCD COVER (SILK) TG TG3 Series Parts List 9001227A Page 26...

  • Page 29: Guide Rail

    HEX SOCKET SET SCREW (W-POINT) P11115000 GUIDE RAIL P11136100 COVER (OP.I/F) P27782000 SHAFT (CUTTER KNOB) P27783000 KNOB (CUTTER) P28813010 UPPER COVER P28814000 REAR COVER P28820010 LABEL COVER LH P28821010 LABEL REAR COVER TG3 Series Parts List PN 9001227A Page 27...

  • Page 30: Shield Plate

    SIMPLE INPUT DEVICE - CONTROL PCB-LF R14164000 SID CABLE SET_ST-LF R14167001 SENSOR CABLE (SEN) SET-LF R14175001 SENSOR CABLE (TAG)SET-LF R14183000 OPTION CABLE SET-LF R14213020 CONT BR ASSEMBLY R14217020 OPEN COVER B (SILK) R14287000 CONT PCB TG3XX TG3 Series Parts List 9001227A Page 28...

  • Page 31: Attachment Assembly

    ATTACHMENT ASSEMBLY Figure PL8, Attachment Assembly ATTACHMENT ASSEMBLY (PL8) ITEM PART NUMBER PART DESCRIPTION H00878000 POWER CORD (EX1) MH0300622 P TIGHT SCREW P28162010 LABEL ADAPTER TG3 Series Parts List PN 9001227A Page 29...
  • Page 32 TG3 Series Parts List 9001227A Page 30...
