Connecting the Vision Viewer™ to Output Device
7890B and 7890P (Analog/Video Device)
Connecting the Video/Power Cable
Your Video/Power cables are pre-attached to the Vision Viewer™ camera.
Simply connect the video composite (RCA type) cable (yellow connector) into
the "video-in" on your TV/Monitor, VCR or Projector (output device). Then
connect the power supply to the power cable (black connector). Next connect
the other end of your power supply to a 110 volt (or 220 volt) electrical outlet.
Now push the "ON" switch to activate the camera. Video image from camera
should appear on your output device.
Note: If no "Video-in" is available, you may need an RF Modulator or a VCR
recorder.
7890UM (Digital Video Device)
Prior to connecting the USB cable, you must first install the supplied software.
Please see the Applied Vision Software booklet provided with the enclosed
software CD.
Once the software is loaded onto your computer, connect the USB cable to the
computer. Click on the desktop icon for the software, follow simple
instructions and the camera should show an image on your computer screen.
See Applied Vision Software Manual if there are any problems with an image.
You are ready to go!
Output from computer to Projector, VCR, DVR, Flash drive, CD's and/or DVD
will, most commonly, use VGA (15 pin) cables, but there are other possibilities
dependent upon your computer set up. See the owner's manual of the
computer for the operating procedures.
Note: The USB provides ample power to the camera, no separate power
supply needed
