Ken A Vision Vision Viewer 7890UM Specifications

Digital
Vision Viewer
7890UM
Image Sensor
Camera
Pixel Count
Frame Rate
Field of View
OSD
Output Resolution
Output
RS232
USB Connection
USB Cable
Operating Temperature
Lighting
Power Source
Cross Platform OS
UVC Driverless
MSI support
Memory
Advance Imaging
Software
Average Set up time
Free Software Updates
IWB Compliant
Viewing Angle
Goose Neck
Lens
Digital Zoom
Controls
Focus
White Balance
Color/B&W
Gamma Adjustment
Negative/Positive
Image Rotation
Capture/Freeze
Audio Recording
Image Compression
Annotation
Light Control
Ken-A-Vision Mfg. Co., Inc.
www.ken-a-vision.com soultions@ken-a-vision.com
TM
Detailed Specifications (September 2012)
KAV 1/4" CMOS
ACT 1280(H) X 1024(V)
Yes Variable with selected screen size
Default 13 fps at max resolution of 1280 X 1024 (1.3)
VGA 30 fps at resolution of 640 X 480
11.5" X 7.5" / 29.21cm X 19.05cm
Yes Controlled by software buttons
Yes HD 720P
Yes VGA, RGB (DVI, HDMI depending on your computer's configuration)
Yes via Software interface of computer
Yes USB 2.0 compliant
Yes Factory installed 1.7 m USB 2.0
Use 0 C - 50 C
Yes Minimal greater than 20 lux NO ACCESSORY LIGHTS REQUIRED
N/A 5 VDC, 200 mA from USB port ONLY meeting green initiative
Yes Windows, Mac, LINUX
Yes Universal Video Class NO DRIVER required to operate
Yes installation, maintenance, and removal of software via Microsoft server
Yes Image / Video
Image Recording: 400 minimum* average 132,000 images per standard hard drive space
of 20GB at 1280 X 1024
Video Recording: 8 minutes minimum* OR 4 hours per standard hard drive space of 20
GB at AVI resolution 640 X 480
Yes For Science, Math or Geography Studies to include 3D rendering, measurement of varied
angles, counting, and much more
less than 5 minutes for 1 – 1,000 units using MSI for Cross platform software installations
N/A
Yes For the life of the product on software and hardware
Yes Interactive White Board Compliant for most current boards
Yes 60 degree: diagonal, 50 degree: Horizontal
Yes 360° X 180° Memory Free Surgical Flexible Neck with 5 year warranty on coating
Yes 6mm Lens
Yes Controlled by software buttons up to 16x
Manual Knurled Rubber focus ring
Yes Auto or manual controlled by software buttons
Yes Black and White controlled by software buttons
Yes Auto or manual controlled by software buttons
Yes Controlled by software buttons
Yes 360° in both directions controlled by software buttons
Yes Freeze image via software button
Yes Synchronized recording via software buttons
Yes JPEG
Yes in software or working with Interactive Whiteboard interfaces
Yes Low Light achieved through CMOS and varied through software with Memory Control
Specifications are subject to change without notice.
