Ken A Vision Vision Viewer 7890B Instruction Manual
Vision viewer
Hide thumbs
Also See for Vision Viewer 7890B:
- Instruction manual (8 pages) ,
- Specifications (1 page) ,
- Product catalog (28 pages)
Advertisement
Quick Links
Advertisement
Related Manuals for Ken A Vision Vision Viewer 7890B
Summary of Contents for Ken A Vision Vision Viewer 7890B
- Page 1 Vision Viewer Instruction Manual 7890B 7890P 7890UM...
- Page 3 Images captured by your camera will be transmitted directly to your TV/Monitor, Projector, or VCR (7890B or 7890P) or through your computer to a Projector, DVR, Flash drive or other digital device (7890UM).
- Page 4 Connecting the Vision Viewer™ to Output Device 7890B and 7890P (Analog/Video Device) Connecting the Video/Power Cable Your Video/Power cables are pre-attached to the Vision Viewer™ camera. Simply connect the video composite (RCA type) cable (yellow connector) into the "video-in" on your TV/Monitor, VCR or Projector (output device). Then connect the power supply to the power cable (black connector).
- Page 5 Vision Viewer™ camera (inside the knurled focusing ring). Note: Use only genuine Vision Viewer™ parts and accessories. All Ken-A-Vision parts provided are made specifically for the Vision Viewer™ and failure due to use of non-vision viewer parts will void the warranty!
- Page 6 Lighting: Your Vision Viewer™ operates using ambient, room light. If using camera in a severely darkened room, supplement the light entering the camera by using a penlight, flashlight or small lamp near the camera, so that there is more local input light for the camera to work with.
-
Page 7: Information To The User
Camera complies with Class A and B, part 15 of the FCC Rules. Use only Ken-A-Vision Video Flex parts. The Power Supply and Charger are made exclusively for the Video Flex. Failure to use non-Video Flex parts will void your warranty. - Page 8 Ken-A-Vision reserves the right to make design improvements and other changes in accordance with the latest technology. There is no obligation to make changes in products already manufactured. Patents Pending Copyright 2010 Ken-A-Vision Corporation 5615 Raytown Road • Kansas City, MO 64133 U.S.A.
