Summary of Contents for Ken A Vision Vision Viewer 7890B
- Page 1 Vision Viewer Instruction Manual 7890B 7890P 7890UM...
- Page 3 Images captured by your camera will be transmitted directly to your TV/Monitor, Projector, or VCR (7890B or 7890P) or through your computer to a Projector, DVR, Flash drive or other digital device (7890UM).
- Page 4 Connecting the Vision Viewer™ to Output Device 7890B and 7890P (Analog/Video Device) Connecting the Video/Power Cable Your Video/Power cables are pre-attached to the Vision Viewer™ camera. Simply connect the video composite (RCA type) cable (yellow connector) into the "video-in" on your TV/Monitor, VCR or Projector (output device). Then connect the power supply to the power cable (black connector).
- Page 5 Focusing: The focusing ring located on the camera head is a rubber knurled focusing system with 6mm lens. Simply turn the focusing ring until you have obtained a crisp clear image. NOTE: The lens is permanently attached and may NOT be removed. Use care when reaching the optimal focal distance, do not use force, and avoid turning the focus ring to extremes in either direction.
- Page 6 Lighting: Your Vision Viewer™ operates using ambient, room light. If using the camera in a severely darkened room, supplement the light entering the camera by using a penlight, flashlight or small lamp near the camera, so that there is more local input light for the camera to work with. Never point your Vision Viewer™...
- Page 7 Camera complies with Class A and B, part 15 of the FCC Rules. Use only Ken-A-Vision Video Flex parts. The Power Supply and Charger are made exclusively for the Video Flex. Failure to use non-Video Flex parts will void your warranty. INFORMATION TO THE USER Changes or modifications not expressly approved by the party responsible for compliance could void the user's...
- Page 8 Ken-A-Vision reserves the right to make design improvements and other changes in accordance with the latest technology. There is no obligation to make changes in products already manufactured. Patents Pending Copyright 2010 Ken-A-Vision Corporation 5615 Raytown Road • Kansas City, MO 64133 U.S.A. Tel.: 816-353-4787 •...
