Summary of Contents for Inter-m IPC System+
- Page 2 Digital paging and broadcasting solution Inter-M provides leading digital broadcasting solution as one of leading companies in Korea. Oriented from the analogue audio system evolved into network based digital AV PA system based on world best technology and service for...
- Page 3 Contents IPC System Introduction Feature and Merit Model and Feature (Basic / Additional System ) System Application (Central, Local, Fiber, TCP/IP, Multi CH Amp) System Drawing Operation Software Introduction...
- Page 4 Using CAT5 cable to install easily, LCD touch screen and PC control is advantage of user operating IPC system for middle and small scale. Based on Inter-M transmission solution of fiber optic and TCP/IP, IPC system provides de-centralized system and multi channel control...
-
Page 5: Updated Information
Feature • 16 x 6 matrix, Max 160 zone paging address independently Max 160 zone, 16 x 6 simultaneous Broadcasting (BGM, Paging, EM, RM, MP3, CD) • Local MIC paging by PC Local control by PC and paging by MIC built in PC Mic input via network. •... -
Page 6: Basic System Configuration
IPC System..Basic System Configuration SI-100 System Integration Main Controller 8CH audio input combo THD ........below 1% (XLR and 55mm phone jack) jack applied SN over (720kHz, LPF) ....65dB 8CH remote Mic station support Frequency response ..100Hz~15kHz (SR-100 x 8) 12CH audio input input level Volume and 5band EQ control SM-100... - Page 7 Additional System Application (List package system with basic unit) SR-100KP Extension Keypad SR-100 key extension pad Keypad 1set provide 12zone extension FT/R-100M Fiber Optic Multi Mode Audio and Data transmission via Fiber optic Cable Maximum 2Km audio and data transmission FT/R-100S Fiber Optic Single Mode Audio and data transmission via Fiber optic cable...
-
Page 8: System Application
IPC System..System Application 1 (Single building – Basic configuration) In the case of single building or the distance in between building within 100m – – Elementary School, Office, Government office, Department store Application Explanation : The basic application of IPC system providing single size building which has cabling distance within 100m system application. - Page 9 System Application 2 (Single/Complex building and need fiber optic system configuration) Central and spread application within the building distance 15km – EX) University/Factory/Military Camp facilities System Explanation : IPC system provides fiber optic solution for wide range of application. It is very suitable for central control system required market such as university and etc.
- Page 10 The basic network connection is consist of AOE-212 network adaptor, and provide remote broadcasting by PC. IPC network connection developed based on Inter-M IT infrastructure and provide the best quality of wide area remote broadcasting solution.
- Page 11 System Application 4 (Central/Spread type building with multi CH amplifier) In the case of auto system restoration for system stability for certain purpose. – EX) Power Plant & Social major facilities System Explanation : The system auto restoration feature of IPC system could supply solution to power plant or other major social facilities for safety of system.
- Page 12 IPC System..System Application SM-100 Touch Screen for System Control Built-in monitor speaker Built-in Emergency manual microphone PC-9335AD DECK CD-660 6CD Changer TU-610 Stereo Tuner SI-100 Main controller 16x6 output matrix Sensor input 64CH CD/MP3 player included SP-100 6CHx60w output digital amplifier Individual CH Volume and EQ included PP-100A 6CH pre amp...
- Page 13 Adaptor DC 12V SR-100 #1 SR-100 #2 SR-100 #8 Fiber-optic cable (2KM) SPEAKER...
- Page 14 IPC System..Main Software/Explanation & Function 1. Main operation screen Sound source and zone control main screen. Built-in CD, MP3, Preset, grouping, EM/BGM/RM broadcasting. 2. Schedule setup Convenient date and schedule reservation of BGM and timer broadcasting by 100 different scenarios in a day and max 700 scenario in a week. 3.
- Page 16 Inter-M Corporation (IMK) 653-5 Banghak-Dong, Dobong-Ku, Seoul, Korea Overseas Sales Team Tel : +82-2-2289-8141~7 / Fax : +82-2-2289-8149 / E-mail : overseas@inter-m.com www.inter-m.com * Specifications and design subject to change without notice.
