Summary of Contents for Inter-m PE-603
-
Page 1: Operation Manual
Operation Manual Chime & Siren PE-603... - Page 2 A personal welcome to you from the management and employees of Inter-M All of the co-workers here at Inter-M are dedicated to providing excellent products with inherently good value, and we are delighted you have purchased one of our products.
-
Page 3: Table Of Contents
CHIME & SIREN Contents Contents Unpacking ............................2 Installation Environment............................2 Important Safety Instructions......................2 Features ............................3 Front Panel ............................4 Rear Panel ............................5 Applications ............................6 Block Diagram ..........................7 Specifications ..........................8 Service Procedures............................9 Schematic ............................9 Parts List ............................9 Warranty ............................9 PE-603... -
Page 4: Unpacking
CHIME & SIREN Unpacking Unpacking Although your PE-603 is neither complicated nor difficult to operate, we recommend you take a few minutes to read this brief manual and familiarize yourself with the important information regarding product features, setup and operation. -
Page 5: Features
A variety of soft tones are available for your announcements, including two-tone, chime up and chime down. - SIREN Both steady and variable levels of siren tones are available for emergency announcements. - REMOTE CONTROL CAPABILITY Rear-panel terminals are provided for connecting a wired remote control to increase functionality. PE-603... -
Page 6: Front Panel
2. SIREN SWITCH These three switches activate the emergency siren tones: ~ : Oscillating siren tone. OFF : Turns off the siren tone. - : Steady siren tone. 3. SIREN LED RED : Oscillating siren tone. GREEN : Steady siren tone. PE-603... -
Page 7: Rear Panel
(-) side. 2. OUTPUT JACK This jack is provided for connecting to the input of a preamplifier, such as the Inter-M PP-613. 3. REMOTE CONTROL TERMINAL These terminals are provided for connection of a wired remote. -
Page 8: Applications
CHIME & SIREN Applications Applications REMOTE CONTROL PE-603 PP-613 PD-659 The shape of outlets can be different according to country requirements. PE-603... -
Page 9: Block Diagram
CHIME & SIREN Block Diagram Block Diagram PE-603... -
Page 10: Specifications
CHIME & SIREN Specifications Specifications PE-603 Siren Frequency 630 Hz Chime and Siren Output Level/Impedance 1V/10kΩ Unbalanced Operation Temperature -10°C ~ +40°C Power Source 24V DC Power Consumption 60mA Weight (SET) 4.4kg/9.7lb Dimensions (SET) 482(W)x88(H)x380(D)mm / 19(W)x3.5(H)x15(D)in * Specifications and design are subject to change without notice. -
Page 11: Service
To obtain specific warranty information and available service locations contact Inter-M directly or the authorized Inter-M Distributor for your specific country or region. - Page 12 Inter-M, Ltd. (Korea) began operations in 1983. Since then, Inter-M has grown to become one of the largest manufacturers of professional audio and commercial sound electronics equipment in the world. Inter-M has gained worldwide recognition for its own branded products, as well as private label manufacturing of electronics sold under other names (OEM).
