■ Programmable function keys

The following functions can be assigned to [P0], [P1], [P2]
and [P3] programmable function keys.
Consult your Icom dealer or system operator for details con-
cerning your transceivers programming.
CH UP AND DOWN KEYS
Push to select an operating channel.
SCAN A START/STOP KEY
Push to start or cancel a scan.
SCAN B START/STOP KEY
Push to start or cancel a scan.
When a scan started with the Power ON Scan or by pushing
this key, push to cancel it. If the scan is cancelled except
by pushing this key, the cancelled scan resumes after the
specified time period.
SCAN ADD/DEL (TAG) KEY
While scan is paused by a detected signal, on a channel
other than a priority channel, push this key to clear the chan-
nel from the scan list.
Depending on the preprogramming, the cleared channel is
added to the scan list again after the scan is cancelled.
PANEL DESCRIPTION
PRIO A/B KEYS
➥ Push to select Priority Channel A or B.
➥ To rewrite the operating channel as Priority A or Priority
B, hold down [Prio A (Rewrite)] or [Prio B (Rewrite)] for
1 second.
MR-CH 1/2/3/4 KEYS
Push to directly select memory channels 1 to 4.
MONI (AUDI) KEY
➥ Push to turn the CTCSS (DTCS) or 2/5-tone squelch Mute
ON or OFF.
• Only during LMR operation, hold down to open any squelch
functions, or deactivate any mute functions.
• Only during PMR operation, push to activate one or two of the
following functions* on each channel.
- Hold down to unmute the channel (Audible mode).
- Push to mute the channel (Inaudible mode).
- Push to send a 'reset code' after the communication is fin-
ished.
*Ask your dealer for details.
NOTE: After a specified period, the un-muted state ('Au-
dible' mode) may automatically return to the muted state
('Inaudible' mode), depending on the preprogramming.
➥ Hold down this key for 1 second to cancel a scan, depend-
ing on the preprogramming.
