Razer CHIMAERA Master Manual

Wireless gaming headset for xbox 360
Hide thumbs

Advertisement

Quick Links

The Razer Chimaera Wireless Gaming Headset for Xbox 360® has everything you need for up
to 12 hours of battling and smack-talking your friends in absolute comfort. Building on our
extensive expertise from PC gaming, this wireless headset is designed to provide a high
definition sound combined with an ergonomic design to maximize comfort.
The included base station doubles up as a charging dock and storage unit to keep your Razer
Chimaera ready to dominate everyone on Xbox LIVE.
MASTER GUIDE
CONTENTS

1. Package Contents

2. System & Hardware Requirements
1. PACKAGE CONTENTS
- Razer Chimaera Wireless Gaming Headset for Xbox 360®
- Charging Dock Base Station
- Cables:
RCA Cable
AC Adapter
2.5mm to 2.5mm Stereo Cable (For Controller Connection)
- 2 AAA Rechargeable Batteries
- Quick Start Guide
- Master Guide
2. SYSTEM & HARDWARE REQUIREMENTS
- Xbox 360®
- Composite Cable (or Component HD AV Cable)
OR
- PC

Advertisement

loading
Need help?

Need help?

Do you have a question about the CHIMAERA and is the answer not in the manual?

Questions and answers

Related Manuals for Razer CHIMAERA

Summary of Contents for Razer CHIMAERA

  • Page 1: Table Of Contents

    PC gaming, this wireless headset is designed to provide a high definition sound combined with an ergonomic design to maximize comfort. The included base station doubles up as a charging dock and storage unit to keep your Razer Chimaera ready to dominate everyone on Xbox LIVE.

  • Page 2: Key Features

    3. KEY FEATURES A. 2.0 Stereo Sound B. Left Button 1 – Outgoing Microphone Volume Up C. Left Button 2 – Outgoing Microphone Volume Down D. Right Button 1 – Volume Up E. Right Button 2 – Volume Down F. Left Button 3 – Microphone Mute G.
  • Page 3 H. Right Button 3 – Volume Mute I. Right Button 4 – Synchronization Button J. Microphone Jack K. Charging LED L. Standby LED M. Standby Button (On / Off) N. Synchronization Button O. Microphone Out P. Audio In Q. AC Connector...

  • Page 4: Technical Specifications

    4. TECHNICAL SPECIFICATIONS Wireless Headset Dimensions (in mm): 200 (W) x 204 (H) x 88 (D) HEADPHONES • Radio Frequency: 2.4GHz • Wireless Range: 32.8 Ft / 10m • Frequency Response: 20 - 20,000 Hz • Impedance: 32Ω at 1kHz •...

  • Page 5: Installation And Setup / Registration / Technical Support

    5. INSTALLATION AND SETUP / REGISTRATION / TECHNICAL SUPPORT BATTERY INSTALLATION For best results, fully charge the batteries before first time use of the Razer Chimaera. A depleted battery will be fully charged in about 3 hours. CAUTION: Use AAA batteries and the supplied adaptor only.
  • Page 6 POWER For US*, Japan and Taiwan - Voltage: 100-240V ~ 50/60/Hz * Please note that in the United States, a polarized plug is used. It can only be inserted one way. For France, Germany, Sweden, Switzerland and Korea - Voltage: 100-240V ~ 50/60/Hz For UK, Singapore, India and Hong Kong - Voltage: 100-240V ~ 50/60/Hz For Australia...
  • Page 7 SYNCHRONIZATION CONTROLLER...
  • Page 8 To minimize possible occurrences of wireless interference affecting Xbox LIVE connectivity, we recommend one of the following: 1. That you place the Razer Chimaera and your Xbox 360 at least 40 inches apart. 2. Setting a dedicated router channel for your Razer Chimaera. Do check out the user manual for your router for configuration details.
  • Page 9 * Not Included NOTE: When transitioning back from PC to Xbox usage, we advise you to remove the jacks connected to your PC. REGISTERING YOUR RAZER CHIMAERA Please visit www.razerzone.com/registration/ for online product registration. What you’ll get: • 1 year limited manufacturer’s warranty...

  • Page 10: Using Your Razer Chimaera

    6. USING YOUR RAZER CHIMAERA MUTING THE MICROPHONE Press Left Button 3. Twist the microphone upwards. POWER MANAGEMENT If the headset does not receive an audio signal for 10 minutes, the headset will automatically power down to conserve energy. If the power in the headset drops below a 10% charge, a beeping sound will be emitted from the...
  • Page 11 USING THE BUTTONS HEADSET Buttons On The Left Ear Cup • Press increase/decrease the microphone volume. • Press to mute the microphone. • Hold to power on/off the headset. Buttons On The Right Ear Cup • Press increase/decrease the audio volume. •...
  • Page 12 LED STATUS INDICATORS The Razer Chimaera has various LED status indicators on the headset and charging dock base station. HEADSET CHARGING DOCK STATION VOICE AND GAME VOLUME SETTINGS 1. On the Xbox Dashboard or in-game, press the Guide button. 2. Select Settings > Preferences > Voice.

  • Page 13: Legalese

    COSTS OF PROCUREMENT For the avoidance of doubt, in no event will Razer be liable for any costs of procurement unless it has been advised of the possibility of such damages, and in no case shall Razer be liable for any costs of procurement liability exceeding the retail purchase price of the Product.
