- Page 1 RAZER BLACKSHARK V2 HYPERSPEED MASTER GUIDE ™ FO R G AM E R S. B Y G A M E R S .
- Page 2 Get the non-stop comfort you need for all-day competitive play with the Razer BlackShark V2 HyperSpeed—a wireless ultra-lightweight esports headset. Designed for maximum performance and minimal weight, experience a level of clarity and power that never gets in the way of your game.
-
Page 3: Table Of Contents
4. TECHNICAL SPECIFICATIONS ........................6 5. SETTING UP YOUR RAZER BLACKSHARK V2 HYPERSPEED..............7 6. USING YOUR HEADSET ......................... 13 7. CONFIGURING YOUR RAZER BLACKSHARK V2 HYPERSPEED VIA RAZER SYNAPSE ......21 8. SAFETY AND MAINTENANCE ........................ 34 9. LEGALESE .............................. 35 ™... -
Page 4: What's Inside
1. WHAT'S INSIDE ▪ Razer BlackShark V2 HyperSpeed Adjustable padded headband Volume knob Ultra-soft breathable memory foam Mic mute button ear cushions Headset indicator LED Razer SmartSwitch / EQ button Power button Razer HyperClear Super Wideband USB Type C port ™... -
Page 5: What's Needed
▪ Razer HyperSpeed Wireless dongle USB Type C port Dongle indicator LED ▪ USB Type A to USB Type C charging cable ▪ Important Product Information Guide 2. WHAT'S NEEDED PRODUCT REQUIREMENTS ▪ USB Type A port or devices with Bluetooth connectivity RAZER SYNAPSE REQUIREMENTS ▪... -
Page 6: Let's Get You Covered
3. LET'S GET YOU COVERED Register your product and score exclusive benefits razerid.razer.com/warranty Your product’s serial number can be found here. ™ F O R G A M E R S . B Y G A M E R S . -
Page 7: Technical Specifications
4. TECHNICAL SPECIFICATIONS HEADPHONES ▪ Frequency response: 12 Hz – 28 kHz ▪ Impedance: 32 Ω ▪ Sensitivity (@1 kHz): 100 dB SPL / mW at 1 kHz by HATS ▪ Drivers: Customized Dynamic 50 mm Driver ▪ Inner ear cup diameter: 62 x 42 mm / 2.44 x 1.65 in ▪... -
Page 8: Setting Up Your Razer Blackshark V2 Hyperspeed
5. SETTING UP YOUR RAZER BLACKSHARK V2 HYPERSPEED CHARGING YOUR HEADSET Connect your Razer BlackShark V2 HyperSpeed to a powered USB Type A port using the charging cable. For best results, please fully charge your headset before using it for the first time. A depleted unit will fully charge in about 4 hours. - Page 9 1. Connect the headset to any of the USB ports on your PC. Type A Type C 2. On your PC (if applicable), set the Razer BlackShark V2 HS USB as the default Output and Input device. Razer BlackShark V2...
- Page 10 B. Via Razer™ HyperSpeed Wireless (2.4 GHz) mode 1. Connect the wireless dongle to any of the USB ports on your PC using the USB Type A to USB Type C cable. Type A 2. Press and hold the Power button until the headset indicator LED briefly lights up.
- Page 11 (default) or low battery warning only from the Razer Synapse app. Learn how to customize the dongle indicator LED 4. On your PC (if applicable), set the Razer BlackShark V2 HS 2.4 as the default Output and Input device. Razer BlackShark V2 Razer BlackShark V2 HS 2.4...
- Page 12 C. Via Bluetooth mode 1. While powered on, press and hold the Razer SmartSwitch / EQ button for 7 seconds to activate pairing mode. Press and hold secs. BLUETOOTH MODE (Paring) PAIRING Alternatively, you can reactivate Bluetooth pairing mode by pressing and holding the power button while the headset is powered off.
- Page 13 PERSONALIZE YOUR EXPERIENCE Razer Synapse (PC)* Use the Razer Synapse app to customize your headset's EQ, toggle Do Not Disturb to block incoming calls while gaming, enable mic noise cancellation, and fine-tune other advanced features. Install Razer Synapse when prompted, or download the installer from razer.com/synapse...
-
Page 14: Using Your Headset
6. USING YOUR HEADSET LOW BATTERY WARNING The headset indicator LED will blink red twice in repeated intervals to indicate that its battery power is less than 8%. While in use, you'll hear a voice prompt when the headset needs to be recharged; during such time, the indicator will continue showing the battery level until you charge the headset. - Page 15 Other functions Other Power button functions are available and operate based on your device's current activity and may not apply to certain devices. Play/pause Accept an incoming call or end the current call* Single press Put a call on hold and accept an incoming call* End call and swap to on-hold call* Reject incoming call* Double press...
- Page 16 Learn more about the Audio Equalizer Reactivating Bluetooth pairing mode You can also use the Razer SmartSwitch / EQ button to reactivate Bluetooth pairing mode. While connected via Bluetooth, press and hold the Razer Smart Switch button for 7 seconds to reactivate Bluetooth pairing mode and connect your device to Razer BlackShark V2 HS BT as needed.
- Page 17 Switching between audio sources When powered on and connected to any audio source, double press the Razer SmartSwitch / EQ button to switch between the wireless dongle and Bluetooth audio source or vice versa. RAZER HYPERSPEED BLUETOOTH WIRELESS MODE MODE Using Bluetooth as the audio source will reconnect the headset to the last known device.
- Page 18 Understanding Razer Smartswitch With the Razer BlackShark V2 HyperSpeed simultaneously connected to a PC or gaming console (via wireless dongle) and a mobile device (via Bluetooth), you'll be able to use the headset for incoming/outgoing/conference calls from a connected Bluetooth device and switch back to the game audio without removing the headset.
- Page 19 Power on / off headset While powered off, press and Activate Bluetooth pairing mode hold for 5 seconds *Only available in Bluetooth mode. Razer SmartSwitch / EQ button Single press Cycle through EQ presets Double press Switch between audio sources...
- Page 20 Decrease volume RAZER HYPERCLEAR SUPER WIDEBAND MIC Bend the Razer HyperClear Super Wideband Mic until it is parallel to your mouth. Make sure the mic diaphragm is in front, and the air vent is facing away from your mouth.
- Page 21 MUTING / UNMUTING THE MICROPHONE Press the mic mute button to mute or unmute the microphone. ™ F O R G A M E R S . B Y G A M E R S .
-
Page 22: Configuring Your Razer Blackshark V2 Hyperspeed Via Razer Synapse
SYNAPSE TAB The Synapse tab is your default tab when you first launch Razer Synapse. This tab allows you to navigate the Dashboard subtab. Dashboard The Dashboard subtab is an overview of your Razer Synapse, where you can access all your Razer devices, modules, and online services. - Page 23 The Modules subtab displays all installed and available modules for installation. Global Shortcuts Bind operations or Razer Synapse functions to custom key combinations from any Razer Synapse- enabled device inputs, which apply across all device profiles. Learn more about Profiles Only Razer Synapse-enabled device inputs will be recognized.
- Page 24 AUDIO TAB The Audio tab is the main tab for your Razer BlackShark V2 HyperSpeed. From here, you can customize your device's settings to unleash its full potential. Changes under this tab are automatically saved to your system and cloud storage.
- Page 25 Profile A Profile is a data storage for keeping all your Razer peripherals' settings. By default, the profile name is based on your system's name. To add, import, rename, duplicate, export, reset or delete a profile, press the Miscellaneous button ( Stereo / THX Spatial Audio Toggle between Stereo audio and THX Spatial Audio.
- Page 26 ▪ THX Environmental Mode. For truly realistic acoustics that reflect your surroundings and localized enemy audio for better directional hearing. For an updated list of THX Game Profile-supported games, visit razer.com/thx-spatial- audio/game-list Volume Adjust the audio volume of the device. You may also access the Windows volume mixer of the current playback device, where you can proportionally adjust the system's overall volume or individually adjust the volume of each active application.
- Page 27 Do Not Disturb Block calls from your mobile device (via Bluetooth) while connected to the wireless dongle. This feature only works when the headset is connected to the wireless dongle and a mobile device simultaneously. Bass Boost Enhance the low-frequency response to improve the bass output of your headset. When enabled, you can adjust the bass output of the headset by adjusting the bass boost slider.
- Page 28 Microphone Control the mic volume and input for clearer mic audio or disable it entirely by toggling the Microphone option. Mic Volume Adjust the microphone input or mute the mic. Enhancements Improve the quality of the mic input further by enabling any of the listed features below and adjusting its intensity using its corresponding slider.
- Page 29 Mic Monitoring (Sidetone) Enable this setting to monitor the microphone's raw audio input through the headset with an additional option to increase or decrease the audio monitoring volume. ™ F O R G A M E R S . B Y G A M E R S .
- Page 30 Power The Power subtab allows you to customize what the indicator LED on the wireless dongle displays or set your device to enter sleep mode when idle for a certain amount of time. By default, the indicator LED on the wireless dongle displays the headset's battery status. ™...
- Page 31 PROFILES TAB The Profiles tab is a convenient way to manage all your profiles and link them to your games and applications. Devices View which games are linked to each device's profiles or which Chroma Effect is linked to specific games using the Devices subtab.
- Page 32 Razer device. To link games to connected Razer devices or Chroma Effects, click on any game from the list, and then click Select a device and its profile to launch automatically during gameplay to select the Razer device or Chroma Effect it will link with.
- Page 33 ) button on Razer Synapse, enables you to configure the startup behavior and display language of Razer Synapse, control the recommendations you see on the Dashboard, check the firmware version and master guide of each Razer device, or perform a factory reset on any connected Razer device.
- Page 34 Reset tab The Reset tab allows you to perform a factory reset on all connected Razer devices with on-board memory and/or reset Razer Synapse tutorials to acquaint yourself again with Razer Synapse's new features on its next launch. All profiles stored on the selected device's on-board memory will be erased when you reset a Razer device.
-
Page 35: Safety And Maintenance
The Razer BlackShark V2 HyperSpeed contains a Li-ion rechargeable battery. In general, the life expectancy of such batteries is dependent upon usage. If you suspect that the Li-ion rechargeable battery inside the Razer BlackShark V2 HyperSpeed may be drained (has a low charge), try charging it. ™... -
Page 36: Legalese
9. LEGALESE COPYRIGHT AND INTELLECTUAL PROPERTY INFORMATION ©2023 Razer Inc. All rights reserved. Razer, the triple-headed snake logo, Razer logo, and "For Gamers. By Gamers." are trademarks or registered trademarks of Razer Inc. and/or affiliated ™ F O R G A M E R S . B Y G A M E R S . - Page 37 Product. In no event shall Razer's liability exceed the retail purchase price of the Product.
