INSTRUMENTS
Trim Meter
[standard equipment (LRTC
type)]
[optional equipment (SRTA and
LRTA types)]
TRIM METER
The trim meter indicates the relative
trim angle of the outboard motor.
Refer to the trim meter when using
the power trim/tilt switch to achieve
proper boat performance.
Tachometer
[standard equipment (LRTC
type)]
[optional equipment (other
types)]
TACHOMETER
The tachometer shows engine speed
in revolutions per minute.
Refer to the tachometer when using
the throttle and power trim/tilt
controls to achieve the best
performance from the boat.
CONTROLS AND FEATURES
Fuel Gauge
[standard equipment (Canadian
types)]
[optional equipment (American
types)]
A fuel gauge is built into the fuel
tank connector of the portable fuel
tank.
FUEL GAUGE
29
