Homelite UT40502 Repair Sheet page 7

HOMELITE 26cc MIGHTYLITE HEDGE TRIMMER – MODEL NUMBERS UT40502 AND UT40903
KEY PART
NO. NUMBER DESCRIPTION
1 309960002 Short Block Assembly
(Inc. Key Nos. 2-4 and 26) .................................. 1
2 901550001 Crankcase Cover Gasket.................................... 1
3 638337001 Crankcase Cover ................................................ 1
4 660925003 Screw (M4 x 12 mm) ........................................... 6
518726001 Upper Housing ................................................... 1
5
660466001 Screw (M4 x 18 mm) ........................................... 4
6
901551001 Intake Gasket...................................................... 1
7
518497001 Heat Dam ............................................................ 1
8
518690001 Heat Dam Deflector ............................................ 1
9
901552001 Carburetor Gasket .............................................. 1
10
308054002 Carburetor .......................................................... 1
11
518498001 Roto-Choke Base ............................................... 1
12
660454001 Bolt (M5 x 70 mm) .............................................. 1
13
660453001 Double Sided Hex Bolt ....................................... 1
14
518704001 Tube .................................................................... 1
15
900951007 Heat Shield Gasket ............................................. 1
16
308980001 Front Housing Assembly
17
(Inc. Key Nos. 21-22, 24-25 and 27-29) ............. 1
690969001 Washer ................................................................ 1
18
308674001 Flywheel Assembly ............................................. 1
19
650017001 Washer ................................................................ 1
20
PARTS LIST (FIGURE C)
KEY PART
QTY NO. NUMBER
660967001
21
638389001
22
638284002
23
518501001
24
638033001
25
638442004
26
308981001
27
900849002
28
518502001
29
638090001
30
300960002
31
660968001
32
850108001
33
901452004
34
308990017
35
660638003
36
638442002
37
660970003
38
660970001
39
270032003
40
308863002
41
7
DESCRIPTION
Screw (M4 x 14 mm) ........................................... 3
Pulley Retainer .................................................... 3
Spacer Tube ....................................................... 1
Starter Pulley ...................................................... 1
Spring & Container Assembly ............................. 1
Heat Shield (Crankcase) ..................................... 1
Lower Housing Assembly ................................... 1
Starter Rope ....................................................... 1
Pulley Handle ...................................................... 1
Washer ................................................................ 1
Clutch Assembly ................................................. 1
Screw (M4 x 19 mm) ........................................... 2
Ignition Module ................................................... 1
Muffler Gasket .................................................... 1
Muffler Assembly ................................................ 1
Screw (10-24 x 2-3/16 in. Shoulder) ................... 2
Heat Shield (Muffler) ........................................... 1
Screw (M4 x 20 mm) ........................................... 1
Screw (M4 x 16 mm) ........................................... 2
Throttle Cable ..................................................... 1
Lead Assembly ................................................... 1
QTY
