Homelite UT40502 Repair Sheet page 5

HOMELITE 26cc MIGHTYLITE HEDGE TRIMMER – MODEL NUMBERS UT40502 AND UT40903
KEY PART
NO. NUMBER DESCRIPTION
1 638388001 Needle Bearing .................................................... 2
2 518561001 Left Handle .......................................................... 1
3 660468001 Screw (M5 x 25 mm) ........................................... 2
4 308794001 Clutch Drum Assembly ....................................... 1
5 678433001 Bellville Washer ................................................... 1
6 518559001 Handle (Rear Base) ............................................. 1
7 678022002 Compression Spring ........................................... 3
8 518553001 Gear Box ............................................................. 1
9 660934002 Screw (M5 x 60 mm) ........................................... 4
10 308789001 Gear & Pin Assembly .......................................... 1
11 660468003 Screw (M5 x 17 mm) ........................................... 1
12 518299001 Throttle Lock Pin ................................................. 1
13 518300001 Trigger ................................................................. 1
14 518301001 Throttle Lockout .................................................. 1
15 678037001 Torsion Spring ..................................................... 1
16 638177001 Retaining Ring .................................................... 1
PARTS LIST (FIGURE B)
KEY PART
QTY NO. NUMBER
17 671073001
18 760338001
19 678509001
20 660970005
21 638454001
22 638453001
23 570219001
24 220034001
25 308788001
26 678429001
27 610655001
28 660460001
29 660468002
30 901519001
5
DESCRIPTION
Compression Spring ........................................... 1
Switch ................................................................. 1
Hex Nut (M5) ....................................................... 4
Screw (M5 x 110 mm) ......................................... 1
Washer (M4.5) ..................................................... 1
Washer (M6) ........................................................ 4
Grommet ............................................................. 1
Gearbox Assembly
(Incl. Key Nos. 1, 4, 5, 8,19, 25, 29 and 30) ........ 1
Pinion Assembly (Incl. Key Nos. 26-28) .............. 1
Ball Bearing (609ZZ) ............................................ 2
Pinion .................................................................. 1
Screw (M6 x 33 mm) ........................................... 1
Screw (M5 x 12 mm) ........................................... 2
Blade Seal ........................................................... 1
QTY
