Homelite UT40502 Repair Sheet page 3

HOMELITE 26cc MIGHTYLITE HEDGE TRIMMER – MODEL NUMBERS UT40502 AND UT40903
KEY PART
NO. NUMBER DESCRIPTION
1 518557001 Front Handle ......................................................... 1
2 660468001 Screw (M5 x 25 mm) ............................................. 2
3 678341001 Flat Washer (M5) ................................................... 2
4 870174001 Spark Plug (Champion RCJ6Y) ............................ 1
5 308548006 Blade Assembly .................................................... 1
6 308675011 Fuel Tank with Cap Assembly (Incl. Key No. 7) .... 1
7 308680001 Fuel Cap ............................................................... 1
8 678022002 Spring ................................................................... 3
640111001 Brace .................................................................... 1
9
638383001 Bushing ................................................................. 1
10
640110001 Gear Box Cover .................................................... 1
11
660469001 Screw (M5 x 24 mm) ............................................. 4
12
518463002 Scabbard .............................................................. 1
13
PARTS LIST (FIGURE A)
KEY PART
QTY NO. NUMBER
940647010
14
940687003
15
940964006
16
120900010
17
660468003
18
518496001
19
678434001
20
678434002
21
678435001
22
660970002
23
987000041
3-09-10
(Rev:04)
3
DESCRIPTION
Choke Label ......................................................... 1
Logo Label ............................................................ 1
Warning Label ....................................................... 1
Starting Label ....................................................... 1
Screw (M5 x 17 mm) ............................................. 5
Roto-Choke Cover................................................ 1
Flat Washer ........................................................... 1
Wavy Washer ........................................................ 1
Lock Nut (M4) ....................................................... 1
Screw (M4 x 10 mm, Shoulder) ............................ 3
Operator's Manual (960639001)
QTY
