  • Page 1 USER MANUAL GOLDMUND TELOS 600 Universal Power Amplifier...
  • Page 2 - networking and music distribution. The guiding principle at Goldmund is to produce a precise sound with the least possible loss of quality through the different stages. Goldmund will never adopt a technology before it is sufficiently developed to satisfy the high quality standards we set.
  • Page 3 The installation instructions must be carried out in full and the mentioned precautions taken to get the expected result and to avoid impairing the amplifier’s performance. TELOS 600 Universal Power Amplifier User manual - GOLDMUND TELOS 600 UNIVERSAL POWER AMPLIFIER...
  • Page 4 AMPLIFIER CONTROLS p 7 - 9 SOUND QUALITY OPTIMIZATION p 10 - 11 SAFETY FEATURES p 12 - 13 MAINTENANCE p 14 TECHNICAL DATA p 14 - 16 SCHEMA p 17 User manual - GOLDMUND TELOS 600 UNIVERSAL POWER AMPLIFIER...

  • Page 5: Choice Of Amplifier Location And Cooling

    COVER. CHOICE OF AMPLIFIER LOCATION AND COOLING The GOLDMUND TELOS 600 amplifier, as all high quality amplifiers generates a large amount of heat when driven at high levels and must be vented properly. It is mandatory to allow a proper cooling of the heat sinks. Do not put temperature sensitive equipment on top of the amplifier.

  • Page 6: L I N E V O Lta G E A D J U S T M E N T

    GOLDMUND dealer for internal adjustment. ATTENTION On the 220V position, the GOLDMUND TELOS 600 amplifier will function properly for main line voltage between 190V and 245V. On the 110V position, the main line must deliver between 95 and 125V. If your main line is usually out of these tolerances, please consult your GOLDMUND dealer.
  • Page 7 Connect the speaker cable to one of the red and black terminals in the back of the amplifier, or, if you use a Goldmund High Definition speaker cable, you can connect directly from the speaker cable to one of the coaxial plugs on the back panel of the amplifier, bypassing the amplifier adapter module of the speaker cable.
  • Page 8 Position 3: Power after 600ms Position 4: Power after 800ms Position 5: Power after 1s Position 6: Power after 1.2s Position 7: Power after 1.4s Position 8: Power after 1.6s Position 9: Power after 1.8s User manual - GOLDMUND TELOS 600 UNIVERSAL POWER AMPLIFIER...
  • Page 9 A M P L I F I E R C O N T R O L S Manual Operation On the front plate of the GOLDMUND TELOS 600 amplifier you will find only two POWER keys. In the Manual Operation mode, the two POWER keys have to be activated simultaneously to power the amp on.
  • Page 10 To unlock the amp from one of the above status, press the 2 power keys simultaneously. If the perturbation has been removed, the red Led will stop and the yellow Led will glow again, the amp is now operating. User manual - GOLDMUND TELOS 600 UNIVERSAL POWER AMPLIFIER...

  • Page 11: S O U N D Q U A L I T Y O P T I M I Z At I O N

    Celsius (+131 degrees Fahrenheit). Speaker polarity Even if you have a phase inverter on your preamplifier (as on the GOLDMUND MIMESIS 2 or MIMESIS 22), and have carefully selected the proper line phase (see next paragraph below), there is a possibility to further increase the sonic quality of your speakers by reverting the polarity of the speaker cable amp termination.
  • Page 12 S O U N D Q U A L I T Y O P T I M I Z AT I O N The GOLDMUND exclusive "Mechanical grounding". In the GOLDMUND TELOS 600 amplifier, GOLDMUND has, as in other of its Ultimate Line components, fully implemented an optimized vibration evacuation path. This is called by GOLDMUND: "Mechanical Grounding".

  • Page 13: Safety Features

    S A F E T Y F E AT U R E S The GOLDMUND TELOS 600 amplifier provides sophisticated features to protect the amplifier and the speakers against all mishandling or component failure. However precautions must be taken to avoid problems with a very high power amplifier.
  • Page 14 To avoid Overload occurring, always switch OFF the amp before trying any manipulation of the speaker cables. There is no risk to leave the speaker terminals unconnected when the amp is ON. P 13 User manual - GOLDMUND TELOS 600 UNIVERSAL POWER AMPLIFIER...

  • Page 15: Frequency Response

    M A I N T E N A N C E The GOLDMUND TELOS 600 amplifier usually requires no maintenance. Always turn the power OFF before cleaning your amplifier. Use a clean, soft, damp cloth to clean the amplifier surface. Dampen the cloth with water or a mild detergent solution.

  • Page 16: Power Supply

    • Power used in standby: 120 W. • 8 toroidal transformers, 4 separated power supply. GROUNDING • Separated ground and earth. • Floating chassis connected to mains earth. • Possible link for optionally connecting both. P 15 User manual - GOLDMUND TELOS 600 UNIVERSAL POWER AMPLIFIER...

  • Page 17: Front Panel Controls

    SIZE AND WEIGHT • 33 cm (13") W x 47 cm (18.5") D x 27 cm (10. 5") H. • Weight: 65 kg net. WARRANTY • 3 years parts and labor. P 16 User manual - GOLDMUND TELOS 600 UNIVERSAL POWER AMPLIFIER...
  • Page 18 S C H E M A TELOS 600 Universal Power Amplifier | B a c k P a n e l P 17 User manual - GOLDMUND TELOS 600 UNIVERSAL POWER AMPLIFIER...
