Summary of Contents for Goldmund TELOS 2800
- Page 2 Since 1978, Goldmund has been dedicated to developing audio equipment of the highest quality and accuracy to immerse you in the most realistic audio experience possible. At Goldmund, we are committed to being at the forefront of the creation, development, and manufacture of the industry's most advanced technologies, including audio systems and music distribution.
- Page 3 All handling must be performed according to the following instructions to avoid impairing the amplifier’s performance. IMPORTANT PLEASE DO NOT CONNECT ANY CABLES OR MOVE ANY PARTS BEFORE READING THE FOLLOWING INSTRUCTIONS User Manual – TELOS 2800 - Mono Power Amplifier - 3 -...
- Page 4 User Manual – TELOS 2800 - Mono Power Amplifier - 4 -...
- Page 5 Please unpack the components with care. CAUTION Should you need to return the TELOS 2800 to the factory or your local representative for warranty repair, please be aware that it must be repacked using the original packaging. This packaging has been designed to specifically safeguard your TELOS 2800 during transit.
- Page 6 The TELOS 2800 amplifier, as all high quality amplifiers, generates a substantial amount of heat when operating at high levels and necessitates adequate ventilation. It is imperative to ensure adequate cooling for the heat sinks. Please refrain from placing the amplifier in poorly ventilated areas and avoid placing temperature-sensitive equipment on top.
- Page 7 If used with an analogue signal, connect the interconnect between the preamp and each power amp and set the TELOS 2800 in analogue mode. You may either use the RCA female socket or the XLR. The XLR socket, especially useful in professional installations, is wired as follows: 1.
-
Page 8: Important Note
S/PDIF input channel. Connect the speaker cables to the Left & Right red and black binding post terminals at the rear of the amplifier, or to the Left & Right 4B type connectors using Goldmund high-definition speaker cables. - Page 9 6.1 Manual Operation • On the front plate of the GOLDMUND TELOS 2800 amplifier you will find only two POWER Power On Process keys. • Progressive charge of high power • The two POWER keys have to be activated simultaneously to power the amplifier on. This capacitors to limit peak current on AC security feature is provided to avoid accidental POWER ON or POWER OFF.
- Page 10 Right button: to select the digital left/right input, the analogue input (RCA & XLR), adjust the gain for each input from -9dB to +9dB (in 3dB increments) and to mute/unmute the amplifier. User Manual – TELOS 2800 - Mono Power Amplifier - 10 -...
-
Page 11: Warm-Up Sonic Effect
It may require around 15 minutes for the amplifier to reach its optimal operating temperature, as the circuits need to warm up to approximately +55 degrees Celsius (equivalent to 131 degrees Fahrenheit). User Manual – TELOS 2800 - Mono Power Amplifier - 11 -... - Page 12 WARNING Always turn the power off before cleaning your amplifier. There are no user serviceable parts inside the TELOS 2800. Unauthorized servicing or alteration invalidates the product’s warranty. User Manual – TELOS 2800 - Mono Power Amplifier - 12 -...
-
Page 13: Power Supply
Max level before clipping, Analogue input: 1 Vrms • Max level before clipping, Digital input: -6 dBFS OUTPUT • Max level before clipping, 1 % THD, unloaded: 170 Vpp User Manual – TELOS 2800 - Mono Power Amplifier - 13 -... -
Page 14: Dynamic Range
44 W x 32 H x 46 D (cm) – 17.3 W x 12.6 H x 18.1 D (inch) • • 59 kg Information and product specifications contained in this manual are subject to change without prior notice. Visit our website at www.goldmund.com User Manual – TELOS 2800 - Mono Power Amplifier - 14 -...
