Summary of Contents for Goldmund TELOS 200
-
Page 1: User Manual
USER MANUAL GOLDMUND TELOS 200 Universal Power Amplifier... - Page 2 - networking and music distribution. The guiding principle at Goldmund is to produce a precise sound with the least possible loss of quality through the different stages. Goldmund will never adopt a technology before it is sufficiently developed to satisfy the high quality standards we set.
- Page 3 The installation instructions must be carried out in full and the mentioned precautions taken to get the expected result and to avoid impairing the amplifier’s performance. T ELOS 200 Universal Power Amplifier User manual - GOLDMUND TELOS 200 UNIVERSAL POWER AMPLIFIER...
- Page 4 C O N T E N T S UNPACKING CHOICE OF AMPLIFIER LOCATION AND COOLING LINE VOLTAGE ADJUSTMENT CONNECTIONS AMPLIFIER CONTROLS p 7 - 9 SAFETY FEATURES p 10 - 11 TECHNICAL DATA p 12 - 13 User manual - GOLDMUND TELOS 200 UNIVERSAL POWER AMPLIFIER...
-
Page 5: Choice Of Amplifier Location And Cooling
COVER. CHOICE OF AMPLIFIER LOCATION AND COOLING The GOLDMUND TELOS 200 amplifier, as all high quality amplifiers generates a large amount of heat when driven at high levels and must be vented properly. It is mandatory to allow a proper cooling of the heat sinks and vents. -
Page 6: L I N E V O Lta G E A D J U S T M E N T
GOLDMUND dealer for internal adjustment. ATTENTION On the 220V position, the GOLDMUND TELOS 200 amplifier will function properly for main line voltage between 190V and 245V. On the 110V position, the main line must deliver between 95 and 125V. If your main line is usually out of these tolerances, please consult your GOLDMUND dealer. - Page 7 Connect the speaker cable to one of the red and black terminals in the back of the amplifier, or, if you use a Goldmund High Definition speaker cable, you can connect directly from the speaker cable to one of the coaxial plugs on the back panel of the amplifier, bypassing the amplifier adapter module of the speaker cable.
- Page 8 Position 3: Power after 600ms Position 4: Power after 800ms Position 5: Power after 1s Position 6: Power after 1.2s Position 7: Power after 1.4s Position 8: Power after 1.6s Position 9: Power after 1.8s User manual - GOLDMUND TELOS 200 UNIVERSAL POWER AMPLIFIER...
- Page 9 A M P L I F I E R C O N T R O L S Manual Operation On the front plate of the GOLDMUND TELOS 200 amplifier you will find only one POWER key. When first connected to mains power the green Led will flash (equal time on and off) for around fifteen seconds whilst the amplifier goes through the POWER UP sequence.
- Page 10 The amp will remain OFF with the red Led on until the user intervenes. To unlock the amp from error mode, press the power key for >2 seconds. or restart the power sequence. User manual - GOLDMUND TELOS 200 UNIVERSAL POWER AMPLIFIER...
-
Page 11: Safety Features
S A F E T Y F E AT U R E S The GOLDMUND TELOS 200 amplifier provides features to protect the amplifier and the speakers against all mishandling or component failure. However precautions must be taken to avoid problems with a very high power amplifier. - Page 12 OFF by the protection circuit. If this happens, let the amplifier cool for some time. We strongly recommend investigating the cause of the temperature gain before operating the amp again. P 11 User manual - GOLDMUND TELOS 200 UNIVERSAL POWER AMPLIFIER...
-
Page 13: Technical Data
• Switch right or left channel selection from the Spdif input. SIZE AND WEIGHT • 24.05 cm W x 38 cm D x 19.15 cm H. • Weight: 30 kg net. WARRANTY • 3 years parts and labor. POWER P 12 User manual - GOLDMUND TELOS 200 UNIVERSAL POWER AMPLIFIER...
