- Page 2 Since 1978, Goldmund has been dedicated to developing audio equipment of the highest quality and accuracy to immerse you in the most realistic audio experience possible. At Goldmund, we are committed to being at the forefront of the creation, development, and manufacture of the industry's most advanced technologies, including audio systems and music distribution.
- Page 3 All handling must be performed according to the following instructions to avoid impairing the amplifier’s performance. IMPORTANT PLEASE DO NOT CONNECT ANY CABLES OR MOVE ANY PARTS BEFORE READING THE FOLLOWING INSTRUCTIONS User Manual – TELOS 690 – Integrated Stereo Amplifier - 3 -...
- Page 4 User Manual – TELOS 690 – Integrated Stereo Amplifier - 4 -...
- Page 5 Please unpack the components with care. CAUTION Should you need to return the TELOS 690 to the factory or your local representative for warranty repair, please be aware that it must be repacked using the original packaging. This packaging has been designed to specifically safeguard your TELOS 690 during transit. Utilizing alternative packaging is likely to result in damage and invalidate warranty coverage.
- Page 6 To achieve optimal sound quality, position the TELOS 690 in a location on a shelf or piece of furniture where it is isolated from vibrations of mechanical components, including the transport mechanism of the player.
- Page 7 Goldmund dealer for expert support ATTENTION For the 220V model, the TELOS 690 amplifier is designed to function optimally with a mains voltage of 220V ±10%. In the case of the 110V model, it is imperative that the mains voltage be consistently maintained at 110V ±10%.
- Page 8 2), RCA Digital (Input 3), or RCA Analog (Inputs 4 to 8). WARNING: For safety reasons, connect all cables Once the input source is connected, link your TELOS 690 to speakers using the two speaker output between your sources and speakers to your connectors located on the unit's rear panel.
- Page 9 Muting/Standby level has been memorized. The mute function is controlled via the remote. To mute or unmute the TELOS 690, briefly press the MUTE/STDBY key. The orange LED will blink to indicate Mute mode. To enter Standby mode, press To recall the memorized volume, briefly press and hold the MUTE/STDBY key until the TELOS 690 switches to standby;...
-
Page 10: Warm-Up Sonic Effect
+55 degrees Celsius (equivalent to 131 degrees Fahrenheit). The TELOS 690 amplifier typically requires minimal maintenance. There are no user serviceable parts inside the TELOS 690. Unauthorized servicing or alteration invalidates the product’s warranty. Should maintenance ever become necessary, please get in touch with your authorized Goldmund dealer. -
Page 11: Power Supply
1 x Digital S/PDIF coaxial RCA 75 Ohms 5 x Analog RCA (left & right) • INPUT Max level before clipping, Analogue input: 1 Vrms • Max level before clipping, Digital input: -6 dBFS • User Manual – TELOS 690 – Integrated Stereo Amplifier - 11 -... - Page 12 44 W x 16.5 H x 44.5 D (cm) – 17.3 W x 6.3 H x 17.5 D (inch). • Information and product specifications 28 kg. • contained in this manual are subject to change without prior notice. User Manual – TELOS 690 – Integrated Stereo Amplifier - 12 -...
