Appendix B: Inlay and Template Routing Using the
Festool Metric Guide Bushing and Ring Set
To cut matching female recesses and male inlays using a female template, select the
offset desired and then use the lettered pair of the guide bushing and supplied rings
shown. For example, if you want a 15.3mm offset from the edge of your template to the
edge of the inlay select a 4mm bit and use the ring marked 4 to cut the male inlay and
the 26.6mm ring marked 8 to cut the female recess. You can use any lettered pair with
the router bit and guide rings shown to produce the offset indicated.
Marking on Diameter of
ring bushing or
Guide 10.6
bushing
only, no
ring
4 18.6
6-4 22.6
8 26.6
6 28.6
8 34.6
Resulting
offset from
edge of
template
57
Matches
with 8mm
ring bit
A
B
A
B
17.3
23.3
Matches Matches
with 6mm with 4mm
bit
C E
E
C D
D
14.3 11.3
20.3 15.3
bit
F
F G
G
19.3
